  • Page 1 Manual Greenho use 20-03-2018...
  • Page 2 height 2,2 m any length multipple to 2m min 4m wight 2,0 m...

  • Page 3: Packages Contents

    Perform assembling and operation of the greenhouse in strict accordance with Description Greenhouse DUO is designed for creation microclimate favorable for growing garden crops on cottage and household plots. Greenhouse might have variable length depending on customers’ desire. Required length of greenhouse is provided by purchasing of packages with extending inserts.
  • Page 4 Detailed complectation of Greenhouse DUO Chart 3 Marking Name Quantity 1 package stand End balk 2к 2кк Ridge balk 2с Edge balk supports base stand 2 package 4вк top end arc 4в top arc bottom arc 4н 3 package bottom end strainer 9-1л...
  • Page 5 Detailed complectation of Greenhouse DUO Marking Name Quantity 4 package Door and small window loop Hook bracket Screw M4*8 Screw M4*14 Screw M4*25 Screw M4*35 Screw M4*40 Nut M4 Nut M6 washer Washer M6 Bolt M6*60 Special wrench Adhesive tape rotator Bending tube Top bandage...

  • Page 6: Operating Rules

    Technical certificate Operating rules Before use of greenhouse, assemble and install it in accordance with the manual. In winter, coverage of greenhouse should not be removed provided that snow load is limited. In winter Greenhouse DUO doesn’t need any control in the majority of the areas of Russia, including Moscow, Tver, St.Petersburg Ekaterinburg, Novosibyrsk and other regions with snow load index under 5 (according to SNIP 2.01.07-85).

  • Page 7: Warranty

    Warranty Warranty 1. Manufacturer is responsible for full completing frame elements of greenhouse. 2. Manufacturer is responsible for assemblability of the greenhouse in accordance with the manual. values of weather impact. 4. Warranty period – 12 months from date of purchase. Warranty conditions The warranty does not cover cases of: 1.

  • Page 8: Assembling Manual

    Assembling manual Assembling manual Introduction General view of the frame is given in Picture 1. Parts should be installed in such a way that side selves of the profile are facing the surface cover. The frame is assembled of numbered parts, some of which made prefabricated from multiple parts with the same number, but different indexes.
  • Page 9 Assembling manual General view of the frame of Greenhouse DUO 4вк 4в 2кк В 2к 4н 9-2л 2к 2с А 2с 9-2п 4н Е 2к 9-1л Г 9-1л Д Fig. 1 Б Elements 4 - Fig.4 Elements 2 - Fig.5 Elements 12...14 (door and window) - Fig.13,14 2к...
  • Page 10 Assembling manual General view of the frame of the greenhouse, extendable inserts «Greenhouse DUO», extended by any number of inserts. Fig. 2 General view of the insert for Greenhouse DUO. Each inset extends the greenhouse length by 2 m. 2к 2к...

  • Page 11: Installation Steps

    Assembling manual Installation steps Perform the assembly next to the installation site of the greenhouse. Perform the assembly in accordance with the pictures of assembly stages and the joints as shown in pic. 6…14. On the site selected for installation of the greenhouse, dig holes as shown by the scheme in Pic.
  • Page 12 Assembling manual The location of arcs and the longitudinal fittings greenhouses, extendable inserts Fig. 4 4н 4н 4н 4н 4н 4вк 4в 4в 4в 4вк 4н 4н 4н 4н 4н one «insert» Two «inserts» extend the greenhouse at 2 m extend the greenhouse for 4 m 2к...
  • Page 13 Assembling manual Installation steps 1 Step collect a power arc (or the required number of power arcs depending on the number of А inserts) of the elements 1, 3, 4в, 4н, 22, 23, 24, 25, 26 using screws М4х8, M4 nuts. If the В...
  • Page 14 Manual Installation steps 3 Step А А join the closest to the end arc elements 2K and 2 in accordance with Fig.5 and Fig. 8 depending on the availability of inserts. 4 Step А А В В to part, assembled at step 3, connect the end of the arc Fig.
  • Page 15 Manual Installation steps 6 Step 2кк А 4в 4н 2с Б 2кк 2с 2кк А 2кк Б to attach the second end of the arc. If the length of the greenhouse more than two meters, it’s necessary to attach the desired number of inserts consistently Fig.
  • Page 16 Manual Door and window assembly А Б А Б 13м 13м 13м 14м 14м 12фл 12фл 12фп 12фп 12фл В Г 13м 12фп 14м В Г 13м Fig. 13 13м Window, outside view Д Ж Д Ж 13м 13м 13м 14м...
  • Page 17 Manual allowence allowance threshold line for penetration into for penetration Into the ground the ground Door Left side of Right side the end of the end Window Fig. 15 Plan of cutting cellular polycarbonate with the installation on the Foundation. when installed on the ground Cut line side extend.
  • Page 18 Manual Fastening of coverage in Fig.15 is a diagram of cuttingt for installation of greenhouses on the Foundation. If the greenhouse is installed on the ground, the lower part of the sidewalls of the end, it is recommended to extend 200 mm for the corresponding deepening of the polycarbonate in the ground.
  • Page 19 Manual Fastening of coverage match elements 9-3 and 9-4 (pic.17) and install them according to pic.19. press the pieces of polycarbonate at the edges from the doors and Windows lining 9-3, 9-4 (pic.19), leaving holes for rotator. cut pieces of the coating to be installed above doorways, and under door openings, install it and fasten it Fig.17...
  • Page 20 Manual Fastening of coverage Washers and clamps on the end are set in accordance with pic.21. Б А rotator S h o r t clamp Long clamp rotator strap Washer Б А Fig. 21 Free of the hole remain In some elements. Do not put screws with the washers on them.
  • Page 21 Manual Fastening of coverage Rotator for locking doors and windows inserted into the holes of the uprights of the door opening direct end outside until it stops. Using the tube the bend of the inner rectilinear end of the arm up (Fig. 22). this design allows the rotator to elastically press the door and the window ends in closed position, being both outside and inside the greenhouse.
  • Page 22 Manual Fastening of coverage The polycarbonate should be installed with the strongly defined outer side (towards the sun), having a protective layer (always make sure when purchasing or before installation). The protective layer is usually on the side with inscriptions on the packaging film. On the other side of the sheet the film is clear.
  • Page 23 Assembling manual Крепление покрытия Do not fully tighten! х3 х3 adhesive tape х1...
  • Page 24 Assembling manual х2 х2 х2 х1 х1 х1 х2...
  • Page 25 Assembling manual L=1,05м х1 х3 х3...
  • Page 26 Assembling manual...
  • Page 27 Assembling manual Install the bracket with the hooks to lock the doors and vents in accordance with pic. 24. Б А Fig. 24 Б А...
  • Page 28 Assembling manual Installation of seals additional 5 package 5-й package (sealing profile) consists of door profile - ,5m; loop profile is 3.6 m; end profile - 12m. the sealing profiles are installed along the contour of the doors and vents in compliance with pic. 25...29. Element 9-1, 9-2 loop sealer Element 12...

  • Page 29: Contact Information

    Contact information Head office: Dancover A/S For more information Nordre Strandvej 119 G please visit: 3150 Hellebæk www.dancovershop.com Denmark National contact Denmark: 70 26 76 20 Spain: 911 436 828 denmark@dancover.com espana@dancover.com UK: 020 8099 7570 Italy: 02 479 21 198 uk@dancover.com...
