Spring V16 HC RW Quick Start Manual page 4

3 - Troubleshooting
4 - Controller Options
WFP Link - Radio Remote Control
The reel winder can be fitted with
a WFP Link. Each button on the
fob corresponds to a speed on
the controller.
Press and hold the desired speed
button on the fob to wind the
reel in. The LEDs on the fob will
light up according to which
button has been pressed.
The motor wires have been disconnected.
Check wiring, if message continues contact
distributor.
The hose has snagged because of an
obstruction.
An over current has been detected, the
controller has shut down the motor to
protect itself. Contact distributor.
Fob
Hard Wired Pendant Control
The reel winder can be fitted with
an external push button switch*
(pendant) to start/stop winding
further away from the controller.
To connect the external push
button switch disconnect the
controller from power and open
the enclosure. Wire the external
switch button through the empty
gland on the enclosure and to the
terminal block (shown below). It
does not matter which way round
the wires are fitted.
*Not supplied
