Wiring
Connect the pump controller in accordance with this diagram.
Spring solenoid valves come fitted with grey wires and can be fitted either way round.
ALWAYS DISCONNECT THE MAINS SUPPLY BEFORE OPENING UNIT.
ALWAYS DISCONNECT THE MAINS SUPPLY BEFORE CONNECTING THE PUMP.
230Vac Mains
Pump Socket
Outlet
Auto Flush Solenoid Valve
M BPC FL
