Installing the Balanced Body
The Konnector LITE is compatible with Balanced Body Studio
Reformers with wooden risers and removable shoulder rests
ONLY. If you aren't sure whether this system will work with your
equipment, please contact Balanced Body at 1-800-PILATES (US
and Canada), or +1-916-388-2838 (all other countries).
To view the installation podcast, please visit
www.pilates.com/instructions
TOOLS REQUIRED (NOT INCLUDED):
» 7/16" wrench or socket (recommended)
» Rag
» Pipe wrench or vise grips
PARTS LIST (INCLUDED):
ITEM
Konnector LITE Rope
Pulley Assembly
Tri-Loops (Black)
Flanged shoulder posts
Under Carriage Pulley Bracket
Hair Guard
1-1/2" Allen bolt
1/4" Washer
1/4-20 Hex nut
1/4-20 Nylock nut
Shoulder rest lockdown kit
5/32" Allen wrench
Spare shoulder post bolt
Spare shoulder post bolt spacer
1
2
INSTALL FLANGED SHOULDER POSTS
WARNING: Using the existing shoulder posts with a Konnector
system can cause the loops to fall off the posts during use
which may cause injury.
1. Wrap one shoulder post with a rag to protect it from the teeth
2. Tighten or clamp down the pipe wrench or vise grips over
Note: There is no need to remove the entire shoulder rest bracket
PART NO.
QTY
from the carriage, only the cylindrical shoulder post.
210-056
1
950-039
2
WARNING: Using the existing shoulder posts with a Konnector
210-055
2
system can cause the loops to fall off the posts during use
616-188
2
which may cause serious injury.
707-258
2
616-187
1
3. Thread the flanged shoulder posts onto the protruding screw.
GEN8333
2
GEN9952
4
GEN9056
2
GEN9008
2
950-004
1
GEN9282
1
GEN9235
2
GEN9162
2
3
4
Konnector
®
on the pipe wrench or vise grips.
the rag and turn counter-clockwise to loosen the shoulder
post. Continue unthreading the post by hand and remove
completely from the shoulder rest bracket. Repeat on the
other post. Set these posts aside, you will no longer need
them.
Tighten snugly (Figure A).
Figure A
WARNING: If you are only using some of the loops, the
unused loops MUST be stored on the flanged shoulder
posts.
LITE
™
Contact Us
1-800-PILATES | +1-916-388-2838
pilates.com | info@pilates.com
400-298 | 12.29.14
