Instructions for Allegro® 2 Reformer
Options and Accessories
INCLUDES INSTRUCTIONS FOR ALLEGRO 2:
» Foot Strap
» Extended Legs
» Wheel Kit
» Wall Security Strap
» 4th Side for Tower Push-thru Bar
» Tower Mat Conversion
I. INSTALLING THE ALLEGRO 2 FOOT STRAP
Page 1
Feed the loops of the footstrap between the frame and standing
Page 2
platform, through the footman's loops, and then around the hook
Page 3
plates on the underside of the standing platform as shown in
Page 4
Figure A.
Page 4
Page 4
Footman's
loop
Figure A: Shown from under Standing Platform.
For a long footstrap, place the
loops around the outer hooks.
For a short footstrap, place the
loops around the inner hooks.
For a medium length footstrap,
place one loop around the
outer hook and the other loop
around the inner hook. See
Figure A.
IMPORTANT SAFETY TIP:
The foot strap must be
checked for proper installation
before each use. An improperly
installed foot strap can lead to
serious injury.
Inner hook
Outer hook
Footstrap
Figure B: Footstrap shown from top of
standing platform.
Contact Us
1-800-PILATES | +1-916-388-2838
pilates.com | info@pilates.com
400-230 | 05.16.17
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Balanced Body Allegro 2 Reformer
Summary of Contents for Balanced Body Allegro 2 Reformer
- Page 1 Instructions for Allegro® 2 Reformer Options and Accessories INCLUDES INSTRUCTIONS FOR ALLEGRO 2: I. INSTALLING THE ALLEGRO 2 FOOT STRAP » Foot Strap Page 1 Feed the loops of the footstrap between the frame and standing » Extended Legs Page 2 platform, through the footman’s loops, and then around the hook »...
- Page 2 II. INSTALLING THE EXTENDED LEGS AND POSTS A. INSTALL LEGS IMPORTANT: INSTALL THE FOOTBAR FIRST! PARTS LIST 1. Move the footbar into the vertical position (for stability). Insert footbar locking pins. Description Part number Qty. 2. If you have a hard floor put a Pilates mat on the floor next to 5/8”...
- Page 3 B. INSTALL POST FOR LOOPS III. INSTALLING THE WHEEL KITS 1. Orient U-post as shown in Figure D. Kit includes wheel brackets for right and left legs and Allen wrench for assembly purposes. 2. Attach using provided 7/8” screws and hex wrench. Tighten securely.
- Page 4 Figure H IV. WALL SECURITY STRAP For additional safety, Balanced Body offers a Vertical Storage Strap (part# 101-000), which fastens the Allegro 2 (without Tower) to a wall when in standing position with wheels. Contact Us 1-800-PILATES | +1-916-388-2838 pilates.com | info@pilates.com...
