Technical Specifications - formlabs Form Cure L Installation And Usage Instructions

2.2

Technical specifications

Parameter
Unit
Installation surface
Minimum dimensions for convenient
access
(W × D × H)
Product dimensions (W × D × H)
Product weight
Turntable diameter
Curing volume
Operating environment
Power requirements
Maximum post-cure temperature
Light source
UV LED electrical power
UV LED radiant power (total)
UV LED radiant power by wavelength
Connectivity
Wi-Fi connectivity
Ethernet connectivity
USB connectivity
Sound emission
Unit control
Alerts
Unit
Form Cure L
Benchtop unit
90 × 85 × 55 cm
35.5 × 33.5 × 21.7 in
69 × 54 × 44.5 cm
27.2 × 21.3 × 17.5 in
24 kg
53 lb
39.5 cm
15.6 in
Cylinder 39.5 cm in diameter and 32 cm tall
Cylinder 15.6 in in diameter and 12.6 in tall
18–28 ºC
64–82 ºF
Input (NA): 100–120 VAC, 50–60 Hz, 15 A max
Input (EU): 220–240 VAC, 50–60 Hz, 8 A max
80 ºC
176 ºF
45 multi-directional LEDs (15 375 nm-LEDs, 15 405 nm-LEDs,
15 white LEDs)
70 W
36 W
16 W at 375 nm (15 LEDs)
20 W at 405 nm (15 LEDs)
Wi-Fi: 2.4 GHz
Ethernet: 100 Mbit
USB: 2.0
Protocol: IEEE 802.11 b/g/n
Frequency: 2.4 GHz
Supported security: WPA/WPA2
RJ-45 Ethernet (10BASE-T/100BASE-TX) LAN port
Connect with a shielded Ethernet cable (not included):
minimum Cat5, or Cat5e or Cat6.
USB (rev 2.0) B port with a USB A-B cable
Does not exceed 79.5 dB(A).
Interactive touchscreen
Touchscreen alerts
Introduction | 9
