Sound Skulptor MP573 Assembly Manual

MP573 Assembly guide MP573 Assembly guide MP573 Assembly guide MP573 Assembly guide
Safety warning Safety warning Safety warning Safety warning
The kits are main powered and use potentially lethal voltages. Under no circumstance should someone undertake the
realisation of a kit unless he has full knowledge about safely handling main powered devices.
Please read the "DIY guide" before beginning.
Print or open the following documents :
• MP573 Schematics
• MP573 Components layout
• MP573 Parts list
• MP573 Setup guide
Follow this guide from item number 1 till the end, in this order. The assembly order is based on components height, from
low to high profile, in order to ease the soldering process : The component you are soldering is always taller than the
previously assembled ones and it is pressing nicely against the work area foam.
Copyright ©2010 SoundSkulptor
Document revision 1.1 – Last modification : 07/01/15
www.soundskulptor.com
