Eclipse Console Table
Assembly Instructions
11
D
D
15
Attach panels [12] to panels [13] and [15] secure with 4x locking
nuts (D). Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3 12
D
D
13
12
E
15
I
E
M
3 12
Attach slide rail (I) and slide rail (H) to the underside of the side panels
as shown. Secure with 4x screws (E) and tighten with a screwdriver.
Attach 1 x handles (M) to panel [12] and secure with 1x screws (O).
Tighten with a screwdriver.
O
13
H
E
E
7
