www.gillathletics.com
800-637-3090
The light weight barrier seal moves up and down
with the barrier to prevent glare at all heights.
Copyright
2011 by Gill Athletics.
All rights reserved.
Approach Side View
The top of the barrier seal is supported
by a 1-5/16" diameter pipe.
The bottom of the barrier seal is weighed
down with a PVC pipe filled with sand.
Bottom Weighted PVC Pipe
WARNING: This product can expose you to Vinyl Chloride,
which is known to the State of California to cause cancer.
For more information go to www.p65warnings.ca.gov.
7401452XX - MESH BARRIER SEAL
Mesh barrier seal reduces glare
and is available in five colors
Color
Royal Blue
Red
White
Gray
Black
White w/ Graphic
D
INSTRUCTIONS
Tools needed:
Two people
One 9/16" wrench
PVC Glue
Sand
Part Number
740145202
740145203
740145204
740145209
740145212
740145204SP
6/1/2016
INST740145
Page 1 of 2
Advertisement
Table of Contents
Related Manuals for Gill 740145202
Summary of Contents for Gill 740145202
- Page 1 6/1/2016 WARNING: This product can expose you to Vinyl Chloride, INST740145 Copyright 2011 by Gill Athletics. which is known to the State of California to cause cancer. All rights reserved. Page 1 of 2 For more information go to www.p65warnings.ca.gov.
- Page 2 Fill the PVC pipe with sand and glue the other cap on. 4. Slide the assembled pvc pipe into the bottom pocket of the barrier seal and let it drape into the water pit. 6/1/2016 INST740145 Copyright 2011 by Gill Athletics. All rights reserved. Page 2 of 2...
