Hinge Door & Inline Panel
With Side Panel
INSTALLATION GUIDE
M082-02
Advertisement
Related Manuals for MERLYN Arysto GHH900HL
Summary of Contents for MERLYN Arysto GHH900HL
- Page 1 Hinge Door & Inline Panel With Side Panel MERLYN Merlyn Showering Unit 8, Purcellsinch Industrial Park, Dublin Road, Kilkenny, Ireland. Tel: 00353 56 779 1555 Fax: 00353 56 779 1576 www.merlynshowering.com To download the Declaration of Performance (DOP) for this product please use the link below.
- Page 2 SP010SP281000 ×1 Door assembly tool 8S1300511 MGVC27 ×1 ×1 Note:Extra components have been supplied to make this product suitable for left or right hand configuration and therefore some parts will be surplus to requirements. Cover cap A06S0046 MG6x30PLUG B-head ST4×30 SP08SCU12320 ×2 ×4...
- Page 3 Step 1 IMPORTANT! Whether fitting on a tray or on a tiled Wetroom the tray or floor must be 100% level ！ 100% level Step 2 Mark 64 mm in from the edge of the tray. Hinge fixing side only Part No.
- Page 4 Step 3 Step 4 Remove profile and drill holes for wall brackets with diameter 8mm masonery bit and Note the position of the labels on the wall profile.Make sure Label 'T' is to the top Ensure wall plugs are flush with tile. insert wall plugs.
- Page 5 Step 7 Step 9 Before assembling the brackets make sure panels are orientated the correct Position brackets 8mm inwards from edge of tray Mark wall through slot. Drill way. Measure hole centres from top and bottom to determine correct orientation 6mm diameter hole centre of slot and fix bracket both sides.
- Page 6 Step 11 Step 13 Fix wall brackets loosely ensuring fixing holes are to the inside of glass panel. Fix wall brackets to the pre drilled holes.Do not fully tighten,leave enough slack for adjustment.Secure top bracket first. Note: Hold glass panel and gently tap profile back tight against wall using MDF tool provided, working from bottom to top.
- Page 7 Step 17 Step 15 The side of the hinge that has the fixing bolts must be to the inside of the moving Using 4mm hex key fully tighten bracket to glass. panel. Hinge should be fitted in centre of cutout for maximum adjustment later. Fully tighten bolts.
- Page 8 Step 22 Step 24 Place locating aids and spacers on threshold, one each side of opening. Loosely fix back plate to hinges ensuring washers are in position and hinges are level. locating aids Tip! Hold both locating aids in position with masking tape. Step 23 ,and retain door into position using top Step 25...
- Page 9 Step 28 Step 26 Remove top holding strip.To remove door positioning aids open door outwards.When Fit bottom door seal keeping longest fin to inside.Notch fin where it meets the closing seal to ensure door closes fully . positioning aids have been removed check gap beneath door is even. INSIDE INSIDE INSIDE...
- Page 10 Step 30 Fix the top rails. Step 31 Adjusting fixed and hinged panels If after fitting doors and fixed panels and you still need adjustment to align doors etc ,you can achieve this by loosening the screws fixing the bracket to the wall and the bolts clamping the hinge to the glass.
- Page 11 Step 34 Sealing your enclosure. Step 32 Additional adjustment Make sure all surfaces are thoroughly cleaned and dry before applying sealant. Where an angled bracing bar is fitted additional adjustment can be made by: Only seal the outside of the enclosure(red line). Do not seal the inside. 1) Loosen the 2 screws clamping the glass.
