_ USING THE CONCORD PROTECTOR (FROM 9 TO 18 KG)

P1 Attachment hooks
P2 Harness guide
P3 Stabilisers
WARNING!
• The CONCORD PROTECTOR may only be used in conjunction with the
CONCORD TRANSFORMER XT-PRO.
• The CONCORD TRANSFORMER can be used without the CONCORD
PROTECTOR, once the child has reached about 4 years of age or
approx. 15 kg body weight.
Mount the CONCORD TRANSFORMER on the vehicle seat as described in the user
manual.
42
Place your child onto the seat of the
CONCORD TRANSFORMER as far back
as possible.
Place the CONCORD PROTECTOR onto
the CONCORD TRANSFORMER so
that the stabilisers (P3) are level with the
harness guides (03) of the CONCORD
TRANSFORMER.
Push the restraining body backwards until
the stabilisors (P3) are flush with the red
markings on the harness guide.
CAUTION!
• Ensure that the stabilisors (P3) are positioned correctly in the harness guides (03)
of the CONCORD TRANSFORMER!
• The CONCORD PROTECTOR must not be attached at an angle, askew
or back to front!
