TRAP-SHUFFLE: Game Simulator
What's in the box?
1 x TRAP-SHUFFLE-TX
Random Flush / All Release / Single Release.
·
User selectable FLUSH from 1 to 100 clays.
·
Variable speed control in real time.
·
Controls up to 4 traps on 4 receivers.
·
1 receiver per trap.
·
Range up to 4km (line of sight).
·
Waterproof to IP68.
·
Quick Start Guide
QS-TRAP-SHUFFLE-R1
4 x TRAP-SHUFFLE-RX
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RF SOLUTIONS QS-TRAP-SHUFFLE-R1
Summary of Contents for RF SOLUTIONS QS-TRAP-SHUFFLE-R1
- Page 1 User selectable FLUSH from 1 to 100 clays. · Variable speed control in real time. · Controls up to 4 traps on 4 receivers. · 1 receiver per trap. · Range up to 4km (line of sight). · Waterproof to IP68. · QS-TRAP-SHUFFLE-R1...
- Page 2 The transmitter LEDs will flash together to confirm pairing then go back to an alter- nating flash. You may now repeat from step 4 to pair another trap to the transmitter To exit pairing mode press the Grey multi release button. Continued... QS-TRAP-SHUFFLE-R1...
- Page 3 The receiver unit requires the following connections to operate: - 12V supply (Brown wire as supplied) - OV Supply (Yell/GRN wire as supplied) When the Receiver unit has power connected the Power LED will illuminate. This must be ‘on’ for the system to operate. QS-TRAP-SHUFFLE-R1...
- Page 4 Check the Wiring required for your Trap: The TRAP-SHUFFLE-RX is capable of switching nearly any trap type, however wiring conventions vary between manufacturers. The relays on the TRAP-SHUFFLE-RX can switch up to 24V DC or 230V AC @ 5A. QS-TRAP-SHUFFLE-R1 QS-TRAP-SHUFFLE-R1...
- Page 5 You can find an instruction video with pairing instructions at the link below or via the QR code. https://www.youtube.com/watch?v=ihe98aBVF7Y This system is not compatible with the standard TRAP systems as it uses specifically designed firmware for the flush functionality in both the transmitters and receivers. QS-TRAP-SHUFFLE-R1...
- Page 6 TRAP-SHUFFLE: Game Simulator BLANK PAGE QS-TRAP-SHUFFLE-R1...
- Page 7 TRAP-SHUFFLE: Game Simulator BLANK PAGE QS-TRAP-SHUFFLE-R1...
