Specifications
Normal Load*
Typical Shaft output at 550 V [kW]
Typical Shaft output at 575 V [hp]
Typical Shaft output at 690 V [kW]
Enclosure IP21
Enclosure IP54
Enclosure IP20
Output current
Continuous (at 550 V) [A]
Intermittent (60 s overload) (at 550 V) [A]
Continuous (at 575/690 V) [A]
Intermittent (60 s overload) (at 575/690 V) [kVA]
Continuous kVA (at 550 V) [kVA]
Continuous kVA (at 575 V) [kVA]
Continuous kVA (at 690 V) [kVA]
Max. input current
Continuous (at 550 V) [A]
Continuous (at 575 V) [A]
Continuous (at 690 V) [A]
Max. cable size: line power, motor, brake and load
share, mm (AWG)
Max. external electrical fuses [A]
Estimated power loss at 575 V [W]
Estimated power loss at 690 V [W]
Weight, enclosure IP21, IP54 lbs [kg]
Weight, enclosure IP20 lbs [kg]
Efficiency
Output frequency
Heatsink overtemp. trip
Power card ambient trip
*Normal overload=110% current for 60 s
Table 10.3 Line Power Supply 3 x 525–690 V AC
The typical power loss is at nominal load conditions and expected to be within ±15% (tolerance relates to variety
in voltage and cable conditions).
The losses are based on the default switching frequency. The losses increase significantly at higher switching
frequencies.
The options cabinet adds weight to the adjustable frequency drive. The maximum weight of the D5h–D8h frames
is shown in Table 10.4.
Frame size
Description
D5h
D1h ratings+disconnect and/or brake chopper
D6h
D1h ratings+contactor and/or circuit breaker
D7h
D2h ratings+disconnect and/or brake chopper
D8h
D2h ratings+contactor and/or circuit breaker
Table 10.4 D5h–D8h Weights
®
VLT
Refrigeration Drive Instruction Manual
N250
NO
200
300
250
D2h
D2h
D4h
303
333
290
319
289
289
347
299
286
296
400
3719
3848
®
MG16J122 - VLT
is a registered Danfoss trademark
N315
NO
250
350
315
D2h
D2h
D4h
360
396
344
378
343
343
411
355
339
352
2x185 (2x350 mcm)
500
4460
4610
275 [125]
275 [125]
0.98
0–590 Hz
230°F [110°C]
167°F [75°C]
Maximum weight, lbs [kg]
255 [116]
285 [129]
440 [200]
496 [225]
N400
NO
315
400
400
D2h
D2h
D4h
418
460
400
440
398
398
478
408
390
400
550
5023
5150
10
10
10-3
