- Page 1 BY CU STO M EQUIPMENT LLC MAINTENANCE & TROUBLESHOOTING MANUAL SUPO-726 PUSH AROUND AERIAL WORK PLATFORM REV A HB-P3.6 SERIES I...
-
Page 2: Notes
The operation and safety manual is considered a part of the work platform and contains instructions and operating procedures essential to properly and safely operate the Custom Equipment Hy-Brid Lift. Users must read and understand all information in the Safety and Operations Manual before operation. -
Page 3: Table Of Contents
6.2 | TROUBLESHOOTING FLOWCHART: ELEVATING ......................26 6.3 | TROUBLESHOOTING FLOWCHART: LOWERING ......................28 SECTION 7 | PARTS ..................................30 SECTION 8 | WARRANTY ................................ 32 NOTES ......................................34 BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE & TROUBLESHOOTING SUPO-726 MAINTENANCE & TROUBLESHOOTING SUPO-726 HB-P3.6... -
Page 4: Section 1 | Safety
The maintenance lock must be placed into position whenever the machine is being serviced in the raised or partially Although Custom Equipment, LLC conforms to specified EN 280 Standards, it is the responsibility of the owner to raised position. Serious injury and/or death could result if maintenance lock is not used properly. -
Page 5: Section 2 | Maintenance
For best battery life, leave charger plugged in until machine will be used again. The charger will maintain the battery charge WARNING DO NOT OPERATE UNIT WHILE CHARGING. DO NOT DISABLE CHARGER INTERLOCK. CAUTION NEVER ADD ACID TO BATTERY! BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE & TROUBLESHOOTING SUPO-726 MAINTENANCE & TROUBLESHOOTING SUPO-726 HB-P3.6 REV A HB-P3.6... -
Page 6: Lubrication
CHARGING READY Green LED Red LED Green LED (ON) (OFF) (ON) BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE & TROUBLESHOOTING SUPO-726 MAINTENANCE & TROUBLESHOOTING SUPO-726 HB-P3.6 REV A HB-P3.6... -
Page 7: Section 3 | Maintenance Checklists
Pothole guards deploy and lock when platform is elevated. □ □ □ Lift does not elevate when pothole guards are blocked. Date: Inspected By: BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE & TROUBLESHOOTING SUPO-726 MAINTENANCE & TROUBLESHOOTING SUPO-726 HB-P3.6 REV A HB-P3.6... -
Page 8: Predelivery / Frequent / Annual Inspection Checklist
□ □ □ □ □ □ Proper placement quantity Battery Charger Secure / Operational COMMENTS: Date: Inspected by: BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE & TROUBLESHOOTING SUPO-726 MAINTENANCE & TROUBLESHOOTING SUPO-726 HB-P3.6 REV A HB-P3.6 REV A... -
Page 9: Section 4 | Technical References
SECTION 4 | TECHNICAL REFERENCES SECTION 4 | TECHNICAL REFERENCES 4.1 | HYDRAULIC SCHEMATIC BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE & TROUBLESHOOTING SUPO-726 MAINTENANCE & TROUBLESHOOTING SUPO-726 HB-P3.6 REV A HB-P3.6 REV A... -
Page 10: Electrical Schematic
THIS DRAWING IS CONFIDENTIAL AND PROPRIETARY TO CUSTOM, EQUIPMENT AND IS LOANED IN EXPECTATION THAT IT WILL BE KEPT CONFIDENTIAL AND USED ONLY FOR THE PURPOSE FOR WHICH IT IS LOANED. BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE &... -
Page 11: Section 5 | Wiring Diagrams
THIS DRAWING IS CONFIDENTIAL AND PROPRIETARY TO CUSTOM, EQUIPMENT AND IS LOANED IN EXPECTATION THAT IT WILL BE KEPT CONFIDENTIAL AND USED ONLY FOR THE PURPOSE FOR WHICH IT IS LOANED. BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE &... - Page 12 THIS DRAWING IS CONFIDENTIAL AND PROPRIETARY TO CUSTOM, EQUIPMENT AND IS LOANED IN EXPECTATION THAT IT WILL BE KEPT CONFIDENTIAL AND USED ONLY FOR THE PURPOSE FOR WHICH IT IS LOANED. BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE &...
-
Page 13: Section 6 | Troubleshooting Flowcharts
Problems problem. Flowchart Connect battery. Contact Hy-Brid Lifts with questions about a different problem Reference Revision B BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE & TROUBLESHOOTING SUPO-726 MAINTENANCE & TROUBLESHOOTING SUPO-726 HB-P3.6 REV A HB-P3.6 REV A... -
Page 14: Troubleshooting Flowchart: Elevating
Hy-Brid Lifts hose. Is there a different problem (something is leaking, unusually noisy, etc.) Reference Revision B BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE & TROUBLESHOOTING SUPO-726 MAINTENANCE & TROUBLESHOOTING SUPO-726 HB-P3.6 REV A HB-P3.6... -
Page 15: Troubleshooting Flowchart: Lowering
O-ring or damage needs replacement. to O-ring. Reference Revision B BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE & TROUBLESHOOTING SUPO-726 MAINTENANCE & TROUBLESHOOTING SUPO-726 HB-P3.6 REV A HB-P3.6... -
Page 16: Section 7 | Parts
SWITCH,ROTARY MOMENTARY,3- ELEC-002A-KIT SWIVEL CASTER ASSELMLY WHEE-713-5-KIT TERMINAL BOOT (BLACK) ELEC-634D UPR CTL ASM, HB-P3.6 144-21-010-55 WHL,8X2 WHEE-706-KIT BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE & TROUBLESHOOTING SUPO-726 MAINTENANCE & TROUBLESHOOTING SUPO-726 HB-P3.6 REV A HB-P3.6 REV A... -
Page 17: Section 8 | Warranty
Company, at its option, to repair or replace (or have one of its designated authorized dealers repair or replace) the Product or part, component or assembly thereof that contains a defect in materials or Subject to the terms, conditions and limitations set forth herein, Custom Equipment, LLC (the “Company”) warrants to the first end-user (“Buyer”) that: workmanship. -
Page 18: Notes
NOTES NOTES BY CUSTOM EQUIPMENT LLC BY CUSTO M EQUIPMENT LLC MAINTENANCE & TROUBLESHOOTING SUPO-726 MAINTENANCE & TROUBLESHOOTING SUPO-726 HB-P3.6 REV A HB-P3.6 REV A... - Page 19 © 2017 Custom Equipment, LLC 2647 Highway 175 Richfield, WI 53076 U.S.A. Tel. +1-262-644-1300 Fax: +1-262-644-1320 www.hybridlifts.com service@customequipmentlifts.com “Hy-Brid Lifts” is a trademark of Custom Equipment, LLC These machines comply with EN 280 Revision Date: June 2017 Printed in the U.S.A.
