11. Setting you workstation(s) to communicate via ipMIDI
The AWS Logictivity software enables 12 MIDI ports which are pre-assigned as follows:
P P o o r r t t
1
2
3
4
5
6
7
8
Note that there are now two switchable workstation layers allowing two independent workstations to be interfaced.
Once configured, you can switch between the two layers using the console's SSL/DAW menu.
Port 7: If your console has AWSomation, this port is used for MIDI Time Code (MTC).
Port 8: Used for the import and export of legacy SysEx TR and AWSomation data.
Port 9-10: Mapped to the conventional MIDI connectors on the rear of the console.
NOTE: In addition to ipMIDI port 7, hardware MIDI port 4 on the rear of the console is also hard coded as an MTC
input. To avoid contention, only use one of these two MTC ports at any one time.
24
L L a a y y e e r r A A s s s s i i g g n n m m e e n n t t
1 Faders 1-8
1 Faders 9-16
1 Faders 17-24
2 Faders 1-8
2 Faders 9-16
2 Faders 17-24
- MTC Input
- SysEx
P P o o r r t t L L a a y y e e r r
9 -
10 -
11 -
12 -
13 -
14 -
15 -
16 -
A A s s s s i i g g n n m m e e n n t t
AWS MIDI port 1
AWS MIDI port 2
-
-
-
-
-
-
