- Page 1 Vehicle-Mounted Camera User Manual UD02783B...
-
Page 2: Regulatory Information
User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to Vehicle-Mounted Camera. This manual may contain several technically incorrect places or printing errors. The content is subject to change without notice, and the updates will be added to the new version of this manual. -
Page 3: Safety Instruction
disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. - Page 4 If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center. If the product does not work properly, contact your dealer or the nearest service center. Never attempt to disassemble the camera by yourself.
-
Page 5: Product Features
Introduction 1.1 Product Features This series of camera adopts high performance sensor and advanced circuit board design technology. It features high resolution, low distortion, and low noise, etc. It is suitable for surveillance system and image process system. The main features are as follows: Low illumination, 0.1 Lux @ (F1.2, AGC ON), 0 Lux with ... - Page 6 Table 1-2 Description of Type II Camera Description Photosensitive Resistor IR LED Main Body Microphone Lens Aviation Plug 1.2.3 Overview of Type III Camera The overview of type III camera is shown below. Figure 1-3 Overview of Type III Camera Table 1-3 Description of Type III Camera Description...
-
Page 7: Installation
Table 1-4 Description of Type IV Camera Description Sunction Mounting Base Main Body Aviation Plug Lens Microphone Photosensitive Resistor IR LED The rearview camera of type IV camera has IR LED and it can monitor the inside of car. The fore view camera can monitor the outside of car. - Page 8 2.1 Installation of Type I Camera This camera supports windshield mounting with sticker. The installation steps are as follows. Step 1 Loosen the secure screw of the camera, as shown in Figure 2-1. Secure Screw Figure 2-1 Secure Screw Step 2 Adjust the double-side tape sticker base to a suitable installation angle.
- Page 9 Sticker Figure 2-3 Attach the Sticker Step 2 Route the cable through the cable hole. (in the cable notch) Cable Notch Figure 2-4 Route Cables Step 3 Fix the base plate onto the wall with screws.(wall mounting with screws) Step 4 Install the camera onto the wall.
- Page 10 Pan Position Range [0°~360°] Rotation Position Range [0°~360°] Tilt Position Range [0°~60°] Figure 2-7 3-axis Adjustment Step 7 Secure the camera by locking the lock catch. 2.3 Installation of Type III Camera This camera supports in-ceiling mounting. The installation steps are as follows. Step 1 Attach the drill template (supplied) to the ceiling.
- Page 11 Figure 2-11 Install the Camera Step 6 Make sure the enclosure is properly fixed with the base plate. Base Camera Main Body Enclosure Figure 2-12 Enclosure Insert the clips of enclosure into the slot of the base plate. Step 7 Insert the adjustment ring into the camera to adjust the angle of bracket position.
-
Page 12: Ptz Control
Figure 2-14 Sticker Protective Film Step 2 Clear the front windshield of your vehicle and stick the camera onto it. Step 3 Adjust the camera angle. Step 4 Insert the adjustment ring into the camera to perform the 3-axis adjustment. Pan Position Range [0°... -
Page 13: Ir Led Control
Enable IR mode You can enable IR mode by calling preset No. 126. 3.3 IR LED Control Enable IR LED: You can enable IR LED by calling preset NO. 130. Disable IR LED You can disable IR LED by calling preset NO.131. 3.4 Mirror Mode Disable Mirror Mode ...
