System Manual
In-Home bus: Audio
Issue 2013

Advertisement

Table of Contents
loading

Related Manuals for SSS Siedle In-Home Bus: Audio

Summary of Contents for SSS Siedle In-Home Bus: Audio

  • Page 1 System Manual In-Home bus: Audio Issue 2013...

  • Page 2: Table Of Contents

    Contents 6 Programming – manual 1 In-Home bus: Audio 7 Supplementary functions System description Overview of functions 38-41 Switching and control functions Remarks Door release actuation 2 Safety remarks Programming - manual (Teach-In) Door call parallel switching 68-70 Door call to BTS/BTC 850-...

  • Page 3: In-Home Bus: Audio

    1 In-Home bus: Audio 2 Safety remarks Danger System description Siedle In-Home: Audio Siedle In-Home: Audio „Single line“ „Multiple line“ Configuration Configuration The In-Home bus: The Audio system In-Home: Audio „Single line“ is Mounting, installation and servicing comprises a bus installation with a restricted to 31 users;...

  • Page 4: Conductor Lengths

    3 Configuration, conductor lengths Single line system Configuration of In-Home: Audio Conductor length The basic installation of In-Home- • Conductor material J-Y(ST)Y or YR Bus: Audio takes place as a single- conductor with 0.8 mm diameter: line system. Within this line, the •...
  • Page 5 In-Home bus users: Audio Overview of user assignment of the individual devices. Devices occupying 1 user BTS 850-... BTC 850-... BFS 850-... BFC 850-... BNS 750-... BSE 650-... BEM 650-... BSM 650-... Devices occupying 2 users BTLM 650-04 BTLE 050-03 CL A xx B-02 CSA/STA/SBA 850-... STL ... Devices with variable user assignment (depending on programming) DCA 650-...
  • Page 6 3 Configuration, conductor lengths Single line system Sample range of a single-line system Side Side Cable material J-Y(ST)Y or YR circuit 1 circuit 1 0.8 mm Distribution of the installation in the sub-distribution board: • Range to door station 1 and door station 2 Each max.

  • Page 7: Single-Line System With Intercom Functions

    3 Configuration, conductor lengths Single-line system with intercom functions Configuration of In-Home: Audio Conductor material with intercom function Telecommunication or light current Using the handsfree bus telephone conductors can be used for instal- BFC 850-..., internal building com- lation: munication can be supplemented J-Y(ST)Y Twisted pair conduc- to include additional convenience...

  • Page 8: Multiple Line System

    3 Configuration, conductor lengths Multiple line system Line 2 Line 15 Line 1...
  • Page 9 Configuration of the multiple line system A multiple line system comprises individual lines which are linked together by two cores. The lines are connected at the bus line recti- fier using terminals Sa and Sb. In multiple line systems, door calls and control functions are possible from one line to another.

  • Page 10: In-Home: Audio Users

    With the basic functions calling, tion. Plastic housing with solid alu- speech and door release. Illuminated minium front, for surface-mounting. light button. Connection to Siedle Removal from the front, with news- In-Home bus: Audio paper compartment. In compliance with DIN EN 13724.
  • Page 11 BRMA 050-01 Siedle Classic Siedle Steel STL... CL A 01 B-02 - CL A 08 B-02 Bus call button matrix for the con- Door station with stainless steel nection of existing call buttons to Door station with stainless steel front, door loudspeaker and call but- the custom-fit door loudspeaker front.
  • Page 12 4 In-Home: Audio users Power supply, line rectifiers BNG 650-0 ZBVG 650-0 NG 602-01 Bus line rectifier in a 9-grid housing. Bus line rectifier in a 6-grid housing. Bus supply unit accessory as a plug- Primary: 230 V AC, 50/60 Hz Primary: 230 V AC, 50/60 Hz in card for integration in bus line Secondary: 12 V AC, 1 A rectifier BNG 650-...
  • Page 13 4 In-Home: Audio users Switching, control BSM 650-02 BSE 650-0 BEM 650-0 Bus switching module in 3-grid Bus switching unit for mounting in Bus input module for mounting in 70 mm boxes. LED for status display housing. 4 integrated relays, each a 55 junction box with an input for with a potential-free working con- and programming mode button.
  • Page 14 4 In-Home: Audio users PC interface, DoorCom, Software PRI 602-0 PRI 602-01 USB BPS 650-0 from V2.50 Programming interface for con- Programming interface for con- Bus programming software for pro- nection of a Windows PC via serial nection of a Windows PC via USB gramming In-Home bus systems.
  • Page 15 BTC 850-... Circuit board for connec- calls in another room or corridor. tion of an additional power supply. Connection to In-Home bus: Audio Required in case of manual program- Call volume steplessly adjustable up ming from the third BTC 850-..., to max.
  • Page 16 4 In-Home: Audio users Bus handsfree telephone, accessories BFS 850-02 BFC 850-0 ZPSF 850-0 Standard bus handsfree telephone. Deluxe handsfree bus telephone Parallel switching accessory for inte- Connection at bus cores Ta and Tb. intercom. Connection at bus cores gration into deluxe handsfree bus telephone BFC 850-...
  • Page 17 5 Installation Bus call button module, bus line rectifier Bus call button module Connection of the bus call button modules to the bus door loud- speaker via ribbon cable. The name plate lighting is supplied from the terminal block of the BTLM 650-04. If there are more than 20 illuminated bus call button modules with LED lighting (BTM 650-01, -02, -03, -04),...
  • Page 18 BTLM Tö 12 V AC min. 20 Ohm Komponentbehov Siedle Vario BNG 650-... BTS 850-... BFS 850-... BTC 850-... BFC 850-... BTLM 650-... BTM 650-... Henvisning...

  • Page 19: Buttons

    AS-THa-1/1 Siedle Vario Remarks a) The BNG 650-0 is able to supply Mode of operation 1 door release and max. 20 bus call Calling and speech between the button modules with LED lighting door station and connected bus tele- BTM 650-01, -02, -03, and -04. phones BTS/BFS/BTC/BFC 850-...
  • Page 20 BTLE Tö 12 V AC min. 20 Ohm BRMA Device Bus custom-fit door loudspeaker BNG 650-... BTS 850-... BFS 850-... BTC 850-... BFC 850-... requirement BTLE 050-... BRMA 050-... Remarks...
  • Page 21 AS-THa-1/1 Siedle Remarks custom-fit door loudspeaker a) The BNG 650-0 can also supply the customer‘s own existing call Mode of operation buttons. A voltage of 12 V AC max. Calling and speech between the 400 mA is available for the lighting door station and connected bus tele- if a door release with an impedance phones BTS/BFS/BTC/BFC 850-...
  • Page 22 BTLE Tö 12 V AC min. 20 Ohm BRMA Device Siedle Classic Siedle Classic BNG 650-... BTS 850-... BFS 850-... BTC 850-... BFC 850-... requirement CL A... B-... call buttons Remarks...
  • Page 23 AS-THa-1/1 Siedle Classic Remarks a) The BNG 650-0 can supply Mode of operation 1 door release and a maximum of 30 Calling and speech between the buttons. With more than 30 call door station and connected bus tele- buttons, an additional transformer phones BTS/BFS/BTC/BFC 850-...
  • Page 24 Tö Tö 12 V AC min. 20 Ohm Tö Device STA 850-... BNG 650-... BTS 850-... BFS 850-... BTC 850-... BFC 850-... requirement SBA 850-... Remarks...
  • Page 25 AS-THa-1/1 Remarks a) The BNG 650-0 can supply 1 Siedle Select door release and a maximum of 16 Mode of operation buttons. Calling and speech between the With more than 16 call buttons, an door station and connected bus tele- additional transformer TR 603-...
  • Page 26 Tö Tö 12 V AC min. 20 Ohm Tö Device Siedle Steel BNG 650-... BTS 850-... BFS 850-... BTC 850-... BFC 850-... requirement STL 0004 Remarks...
  • Page 27 AS-THa-1/1 Siedle Steel Remarks a) The BNG 650-0 can supply 1 door Mode of operation release and a maximum of 30 Calling and speech between the buttons. With more than 30 call door station and connected bus tele- buttons, an additional transformer phones BTS/BFS/BTC/BFC 850-...
  • Page 28 BTLM Tö Tö 12 V AC min. 20 Ohm Tö Siedle Vario BNG 650-... VNG 602-... Device BFC 850-... BFC 850-... BFC 850-... BFC 850-... BFC 850-... BTLM 650-... requirement + ZPSF 850-... + ZPSF 850-... + ZPSF 850-... + ZPSF 850-... + ZPSF 850-...
  • Page 29 AS-THa-1/1 Siedle Vario with Remarks a) The BNG 650-0 is able to supply intercom function 1 door release and max. 20 bus call Functional characteristics button modules with LED lighting Calling and speech between the BTM 650-01, -02, -03, and -04. door station and connected hands- With more than 20 illuminated bus free bus telephones BFC 850-...
  • Page 30 BTLM Tö Tö Tö Tö 12 V AC Tö 12 V AC min. 20 Ohm min. 20 Ohm Tö Device Siedle Vario Siedle Vario BNG 650-... BTS 850-... BFS 850-... BTC 850-... BFC 850-... requirement BTLM 650-... BTLM 650-... BTM 650-... BTM 650-...
  • Page 31 AS-THa-1/2 Siedle Vario Remarks a) The BNG 650-0 is able to supply Mode of operation 1 door release and max. 20 bus call Calling and speech between the button modules with LED lighting door station and the connected bus BTM 650-01, -02, -03, and -04. telephones BTS/BFS/BTC/BFC 850-...
  • Page 32 BTLM Tö Tö 12 V AC min. 20 Ohm Tö Other BNG 650-... Device Siedle Vario BNG 650-... BTS 850-... BFS 850-... BTC 850-... BFC 850-... BNG 650-... BTS 850-... BFS 850-... BTC 850-... BFC 850-... requirement BTLM 650-... ZBVG 650-... BTM 650-...
  • Page 33 For more information, see chapter 7, AS-THa-2/1 Multiple line system page 68. Mode of operation Selective dialling of the door sta- Calling and speech between the tion possible using additional free door station and the connected bus buttons. telephones BTS/BFS/BTC/BFC 850-... Automatic assignment of the door Remarks a) The BNG 650-0 is able to supply release button to the door station...
  • Page 34 BTLM Tö 12 V AC min. 20 Ohm Siedle Vario bus Device Siedle Vario BIM 650-... TR 603-... ZWA 640-... BNG 650-... BTS 850-... BFS 850-... BTC 850-... BFC 850-... requirement BTLM 650-... BTM 650-... UAE socket 8/8 DRM 650-... Remarks...
  • Page 35 b) Door release 12 V AC, use at AS-THa-1/1 call via display call Supplementary functions module DRM 611-0 least 20 Ohm, (e.g. TÖ 615-...), for Internal speech communication pos- sible between the bus telephones possible connection variants see chapter 7, page 66 Mode of operation BTS/BFS/BTC/BFC 850-0, switching Calling and speech between the and control functions possible with •...
  • Page 36 BTLM Tö Tö 12 V AC min. 20 Ohm Tö Analog telephone connection to TBR 21 Siedle Vario BNG 650-... BTS 850-... BFS 850-... BTC 850-... DCA 650-... TR 603-... Device requirement BTLM 650-... BTM 650-... Remarks...
  • Page 37 AS-THa-1/1 DoorCom Analog Remarks DCA 650-... a) The BNG 650-0 is able to supply 1 door release and max. 20 bus call Mode of operation button modules with LED lighting Calling and speech between the BTM 650-01, -02, -03, and -04. door station and the connected a/b With more than 20 illuminated bus telephones of a telephone system.
  • Page 38 6 Programming Overview of functions Functions with Siedle In-Home and programming possibilities. Terms used in the table are explained in detail on the next page. Plug+Pla PC-Prog. via Basic function Manual Remarks Prog. Prog. BPS 650-... (Teach-In) from V 2.50 Door call Storey call Functional after installation, call...
  • Page 39 Manual Prog. Plug+Play PC-Prog. via Intercom functions Remarks (Teach-In) Prog. BPS 650-... from V 2.50 Internal group call ZPSF 850-... required Collective announcement ZPSF 850-... required Automatic call pick-up with internal call Internal call with callback function...
  • Page 40 6 Programming Overview of functions Dialling last door Internal group call Callback The door station from which the last Internal call to several indoor devices If you are available to accept an door call was placed can be dialled simultaneously. The device which internal call, a callback can be by double clicking the light button.
  • Page 41 Door release button The door release button on the bus indoor device always switches the DR contact at the bus line rectifier for 3 seconds and the DR contact in the door loudspeaker which placed the call. Door call When a visitor presses the door bell button, the bus telephone rings and the call silencing button flashes.
  • Page 42 6 Programming Remarks The In-Home bus can be pro- Handsfree bus telephones • In multiple line systems, the bus grammed in three ways: BFS 850-... and BFC 850-... power supply accessory ZBVG 650-... must additionally be plugged into a Picking up and replacing the receiver 1 Programming - Manually, also BNG 650-...
  • Page 43 6 Programming - manual Activating the bus line rectifier To activate the programming mode at the bus line rectifier, the pro- gramming mode button has to be briefly pressed down. LED1 indicates whether the programming mode is switched on. After activating the programming mode, LED1 changes over from normal mode to program- ming mode.
  • Page 44 6 Programming - manual Activating the bus door loudspeaker Depending on the type of door station, the programming mode has to be activated in a different way. Activation of the door station is identical for all bus telephones. There is no difference between receiverless bus telephones and bus telephones with receivers.
  • Page 45 6 Programming - manual Activating the bus telephone Activating the bus handsfree telephone 1 Activating the bus telephone 2 Hold down the light button for 4 seconds. A protracted acknow- Bus telephones are set to the pro- gramming mode using the light ledgement tone is audible in the receiver as confirmation.
  • Page 46 6 Programming - manual Programming door calls Application At the bus telephone, a different Call from the door station to a bus ring tone optionally be selected. telephone. The volume of the door call can be changed at the bus telephone. 1 Switch on the programming mode.
  • Page 47 6 Programming - manual Programming door calls at the handsfree bus telephone Application At the bus handsfree telephone a Call from the door station to a bus different ring tone can optionally telephone. be selected for the door call. The volume of the door call can be changed at the bus telephone.
  • Page 48 6 Programming - manual Programming door calls via the storey call button Application Programming is only possible if the Call from the door station to a bus storey call button (ERT) is connected telephone. at the bus telephones. If there is no access available to an apartment, programming can still be carried out in this way.
  • Page 49 6 Programming - manual Door call parallel switching deluxe bus telephone BTC 850-... Application Programming must start at the bus Where a door call has to be signalled Using the manual programming telephones which do not have any method, 2 bus telephones can be at several bus telephones simultane- additional power supply connected.
  • Page 50 6 Programming - manual Programming internal calls Application The muting and light buttons of the Using bus programming software BPS 650-0 the buttons of the bus You wish a bus telephone to be bus telephone can be reprogrammed able to call and communicate if required for internal call functions.
  • Page 51 6 Programming - manual Programming internal calls Tel. 1 Tel. 2 7 At the first bus telephone, hold 8 At the second bus telephone, hold 9 Replace the receiver at both bus down the internal call button you down the internal call button you telephones.
  • Page 52 6 Programming - manual Dialling the door station Application This function can be programmed You wish to be able to call one or for any bus telephone to any button. more door stations from a bus tel- The only exception is the door ephone using buttons, e.g.
  • Page 53 6 Programming - manual Call differentiation of 2 door stations Application Call differentiation can take place At the bus telephone you wish to be from max. 2 doors. able to tell at which door the door Door call 1 = Tone sequence 1 call has been made, e.g.
  • Page 54 6 Programming - manual Additional contact on the BSM 650-... Application In addition to an already pro- grammed bus telephone, you wish a potential-free switching contact to be closed when a door call is placed. Actuation of an additional bell or lamp on placement of a door call.
  • Page 55 6 Programming - manual Button of a bus telephone on the BSM 650-... Application Actuation of a contact in the BSM 650-..., e.g. in order to open a garage or switch on a staircase light. 2 Switch the BSM 650-... to the pro- 1 Switch on the programming mode.
  • Page 56 6 Programming - manual Call button of a door station on the BSE 650-... Application must already be programmed to the Using the bus programming soft- call button. ware BPS 650-... the switching func- Potential-free switching contact tion/time can now be changed. which is closed on placement of a door call.
  • Page 57 6 Programming - manual Button of a bus telephone on the BSE 650-... Application Using the bus programming soft- ware BPS 650-... the switching func- Actuation of additional functions tion/time can now be changed. such as switching on the staircase light or garage door OPEN/SHUT. Switching time with manual pro- gramming 1 second.
  • Page 58 6 Programming - manual Bus secondary signal unit BNS 750-... Application Signal device to additionally indicate the door call and/or storey call in another room. 1 Switch on the programming mode. 2 At the door station, hold down the 3 Lift the receiver at the bus tele- light/programming button for 4 ...
  • Page 59 6 Programming - manual Call via DRM 611-... Application used, note that the receiver must be Names are entered at a PC using the programming software PRS 602-... Bus telephones are called from the picked up to execute the program- door station via the display call ming procedure.
  • Page 60 6 Programming - Plug+Play Basics Plug+Play programming offers the same sequence in which the mod- • After all the telephones have been closed, at the bus line rectifier press opportunity for those without pro- ules are connected to each other via gramming experience to commission the IN/OUT connections.
  • Page 61 Bus custom-fit door loudspeaker The sequence of terminals on the bus call button matrix corresponds to the sequence of bus telephones. Terminal 7.1 = Bus telephone 1 etc. Terminal 7.12 = Bus telephone 12 Siedle Classic The sequence of terminals on the bus call button matrix corresponds to the sequence of bus telephones.
  • Page 62 6 Programming - Plug+Play Example of a 4-family home Example Plug+Play programming 4-family home Restrictions with Plug+Play pro- be performed at a later stage. gramming • Bus telephones which are already Possible errors assigned to a door loudspeaker • If unsuitable devices log in during in the same line are not repro- Plug+Play programming (old bus tel- grammed.
  • Page 63 6 Programming - Plug+Play Procedure - Example Apartment 1 click Apartment 2 Apartment 3 Apartment 4 1 Activate the Plug+Play mode at 2 Set up the bus telephone in 3 Set up the bus telephone in the BNG 650-... , hold down the apartment 1 with the receiver in apartment 2 with the receiver in programming mode button for...
  • Page 64 6 Programming - with PC BPS 650-... and PRI 602-... USB Using bus programming software Mobile operation In-Home bus programming: BPS 650-... from V2.50 the entire function of an In-Home system can be programmed using a Windows PC. For connection of the PC to the In-Home installation, the pro- gramming interface PRI 602-... USB and the bus power supply acces-...

  • Page 65: Supplementary Functions

    7 Supplementary functions Switching and control functions Bus switching unit Bus switching module Bus input module BSE 650-... BSM 650-... BEM 650-... Application Application Application 1 Changeover contact, e.g. for 4 working contacts, e.g. for Optical feedback of switching - Switching the outside light - Switching the outside light statuses, e.g.

  • Page 66: Door Release Actuation

    7 Supplementary functions Door release actuation In deviation from the standard plans, release contact which is only closed order to guarantee the greatest pos- the door release can be actuated in when the bell has previously been sible degree of operating reliability/ various ways.
  • Page 67 The bus line rectifier DR contact and the door release contact in the door loudspeaker are used. The contact in the BNG 650-0 switches every time BTLM the door release button is pressed, the contact in the door loudspeaker only at the door from which the last door call was placed.

  • Page 68: Door Call Parallel Switching

    7 Supplementary functions Door call parallel switching Manual programming: Programming with PC and BPS: In case of manual programming In general, 2 telephones can be During PC programming, 4 BTS/ only 2 bus telephones can be pro- switched in parallel. Parallel opera- BFS/BTC/BFC 850-...units can be grammed in parallel without tion can be extended when pro-...
  • Page 69 A maximum of 8 ZPS/ZPSF 850-... units can be supplied by a video line rectifier NG 602-..The maximum current of the 30 V DC direct voltage from the VNG 602-... is 1100 mA. The specified ranges only apply to the external power supply to the devices, not to the range of the In-Home bus.
  • Page 70 7 Supplementary functions Door call parallel switching BTC 850-... uses a ZPS 850-... / each Parallel programming of several bus • Programming must start at the bus BFC 850-... uses a ZPSF 850-... telephones to one call button. telephones which do not have any • BTS 850-... and BFS 850-... can •...
  • Page 71 Device overview BFS 850-... BTS 850-... BTC 850-... BTC 850-... + ZPS 850-... BFC 850-... + ZPSF 850-...

  • Page 72: Storey Call Parallel Switching

    7 Supplementary functions Storey call parallel switching Parallel storey call The storey call button (ERT) is used to call into the apartment from an apartment door. To call several bus telephones, the ERT terminal can be connected in parallel, e.g. office floor with 4 bus telephones with one storey call button at the storey entrance.
  • Page 73 7 Supplementary functions Supplementary contact, radio chime, pilfer safeguard Interfacing relay accessory ZAR 850-.../ZARF 850-... Actuation of an additional signalling device such as a radio chime or optical display of the door call. If the contact is required in the sub-distributor, the door call can be programmed to a contact at a BSE 650-...

  • Page 74: Staircase / Outside Light

    7 Supplementary functions Staircase light/Outside light Light actuation Using the light button in the bus telephone BFS/ BTS/BTC/BFC 850-... or BTLM 650-... , the light contact at the bus line rectifier BNG 650-... is actuated. Following completion of the instal- lation, this function is active without any further programming.

  • Page 75: Servicing

    8 Servicing Restart, exchange, operating mode Restarting the system Exchanging bus telephones in an Exchanging an existing existing system BSG 650-... for a BNG 650-0 A restart of the complete system is known as a Power-ON-Reset. If an already programmed bus The existing system programming is Switch off the power supply to the telephone has to be exchanged,...
  • Page 76 8 Servicing Restart, exchange, operating mode Operating mode switch 1-Norm-2 BNG 650-0 Switch setting 1 Switch setting “Norm” “Reverse compatible” BTS 750-0 BFS 850-.../BTS 850-0 BTC 750-0 BTC 850-.../BFC 850-... BNS 750-0 BTS 750-02 BTLM 650-0/ -01 BTC 750-02/ -03 BTLE 050-0 / -01 BNS 750-02 BSM 650-0...

  • Page 77: Led Displays Bng

    8 Servicing LED displays BNG 650-0 The two displays LED1 and LED2 at the bus line rectifier indicate func- tions for operation and possible faults in the In-Home bus. The fol- lowing table indicates the possible displays. Display LED1 “Operation” LED flashes evenly 0,3s 0,3s...

  • Page 78: Measured Values

    8 Servicing Measured values Measured values at the In-Home bus: Audio, to be measured with a digital multimeter max. Idle status min. Voltage Ta/Tb at bus line rectifier BNG 650-... 26 V DC 29 V DC 16 V DC Voltage Ta/Tb at most distant user Current consumption bus telephones BFS/BTS/BTC/BFC 850-...
  • Page 79 Index 9 Glossary BEM 650-... Address 9, 17 The latest issues of the In-Home BFC 850-... Bus system manual: Audio is pro- As-delivered status vided in the download area under BFS 850-... Call silencing www.siedle.de. BIM 650-... Classic CL ... 11, 22 BNG 650-... Commissioning Customer service in the BNS 750-...
  • Page 80 S. Siedle & Söhne © 2010/06.13 Telefon- und Telegrafenwerke OHG Printed in Germany Best.-Nr. 0-1101/141866 EN Postfach 1155 78113 Furtwangen Bregstraße 1 78120 Furtwangen Telefon +49 7723 63-0 Telefax +49 7723 63-300 www.siedle.de info@siedle.de...
