A6 TPC 75
Instruction manual
Valid for: serial no. 452-xxx-xxxx
0443 408 101 GB 20210907

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A6 TPC 75 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ESAB A6 TPC 75

Summary of Contents for ESAB A6 TPC 75

  • Page 1 A6 TPC 75 Instruction manual Valid for: serial no. 452-xxx-xxxx 0443 408 101 GB 20210907...

  • Page 2: Table Of Contents

    Flux hopper complete 10 l ..................Flux hopper complete 6 l ..................Inlet tube complete ....................Flux hopper complete 0.75 l ..................Optional equipment - Apparatus cubicle ..............Rights reserved to alter specifications without notice. 0443 408 101 © ESAB AB 2021...

  • Page 3: Safety

    1 SAFETY SAFETY Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who works on or near the equipment observes all the relevant safety precautions. Safety precautions must meet the requirements that apply to this type of equipment. The following recommendations should be observed in addition to the standard regulations that apply to the workplace.
  • Page 4 Read and understand the instruction manual before installing or operating. PROTECT YOURSELF AND OTHERS! CAUTION! Read and understand the instruction manual before installing or operating. ESAB can provide you with all necessary welding protection and accessories. 0443 408 101 - 4 - © ESAB AB 2021...

  • Page 5: Introduction

    The pressurised flux tank can be used as a free--standing floor unit or be mounted on a stand or column and boom using a support bracket. It is part of ESAB’s range of flux equipment which includes flux vacuum systems and other flux handling equipment.

  • Page 6: Optional Accessories

    0414 363 880 Sensor box for level indicator, 24 V 0414 364 001 Miniflash, flashing warning lamp 0433 865 880 Support bracket Flux feed rate Flux feed height Air pressure 0443 408 101 - 6 - © ESAB AB 2021...
  • Page 7 2 INTRODUCTION Flux feed height as a function of air pressure, for flux supplied at a rate of 2 l/min through a 40 m long 1” plastic hose 0443 408 101 - 7 - © ESAB AB 2021...

  • Page 8: Technical Data

    3 TECHNICAL DATA TECHNICAL DATA A6 TPC 75 Working pressure 0.2–0.4 MPa Max. air consumption (max. working pressure) 300 litres/min Max. permissible air pressure 0.6 MPa Material classification DIN 17 155, Kesselblech H11 Compressed air hose (internal diameter) Ø10 mm Tank capacity...

  • Page 9: Installation And Operation

    Adjust to a suitable working pressure of 0.2–0.4 MPa using the pressure regulator, and read the pressure at the gauge (C). NOTE! Pressure should be no higher than necessary to obtain satisfactory operation with the welding equipment in use. 0443 408 101 - 9 - © ESAB AB 2021...

  • Page 10: Maintenance

    Check the water trap daily to monitor compressed air quality. If water is present it may be necessary to install a dehumidifier. NOTE! Pressure vessels used for flux distrubution should be inspected for renewed approval every 5th year. 0443 408 101 - 10 - © ESAB AB 2021...

  • Page 11: Dimensions

    DIMENSIONS DIMENSIONS 0443 408 101 - 11 - © ESAB AB 2021...

  • Page 12: Spare Parts List

    SPARE PARTS LIST SPARE PARTS LIST Flux pressure tank, TPC 75 Ordering no. Denomination Notes 0333 225 880 Flux pressure tank, TPC 75 (W) = This is a wear component 0443 408 101 - 12 - © ESAB AB 2021...

  • Page 13: Filter Regulator

    (W) L = 25 m 0190 315 109 Hose PVC 0252 900 408 Hose clip 0156 806 880 Bleeding valve 0156 252 880 Flux strainer (W) = This is a wear component 0443 408 101 - 13 - © ESAB AB 2021...

  • Page 14: Bracket Tpc 75 Complete

    0433 866 881 Bracket 0145 550 001 0145 551 001 Metal strip 0212 106 257 Screw IN6 0212 101 628 Screw 0212 602 011 (W) = This is a wear component 0443 408 101 - 14 - © ESAB AB 2021...

  • Page 15: Flux Hopper Complete 10 L

    0215 201 232 O-ring   0148 799 001 Washer     Screw  M3×16 0020 301 780 Flux strainer   0443 383 001 Flux hose L = 500 0153 299 880 Flux nozzle 0443 408 101 - 15 - © ESAB AB 2021...

  • Page 16: Flux Hopper Complete 6 L

     D8/4,3×0.8 0153 347 880 Flux valve   0020 301 780 Flux strainer   0443 383 002 Flux hose  L = 500 0332 948 001 Flux tube 0333 094 880 Clamp 0443 408 101 - 16 - © ESAB AB 2021...
  • Page 17 SPARE PARTS LIST 0443 408 101 - 17 - © ESAB AB 2021...

  • Page 18: Inlet Tube Complete

    Inlet tube complete   0186 961 880 Straight inlet tube  D=25/21 0186 961 881 Bent inlet tube  D=25/21 90 degrees Flux inlet tubes to be mounted in flux hopper 0147 649 881 or 0413 315 881. 0443 408 101 - 18 - © ESAB AB 2021...

  • Page 19: Flux Hopper Complete 0.75 L

    Flux hopper complete 0.75 l 0153 855 001 Filter 0252 900 416 Hose clamp 0252 900 406 Hose clamp 0153 854 001 Tube 0322 166 880 Holder 0153 347 880 Flux valve 0443 408 101 - 19 - © ESAB AB 2021...

  • Page 20: Optional Equipment - Apparatus Cubicle

    Optional equipment - Apparatus cubicle Item no. Ordering no. Denomination Notes     Optional equipment   0414 363 880 Apparatus cubicle 0537 601 703 Switch 0193 396 001 Relay 0414 364 001 Miniflash 0443 408 101 - 20 - © ESAB AB 2021...
  • Page 21 SPARE PARTS LIST 0443 408 101 - 21 - © ESAB AB 2021...
  • Page 22 For contact information visit esab.com ESAB AB, Lindholmsallén 9, Box 8004, 402 77 Gothenburg, Sweden, Phone +46 (0) 31 50 90 00 http://manuals.esab.com...
