- Page 1 ELITE 2000 AUTO TREADMILL CARDIO INCLINE USER MANUAL CAUTION READ ALL PRECAUTIONS AND Visit facebook.com/trojanhealth INSTRUCTIONS IN THIS MANUAL BEFORE USING THIS EQUIPMENT. www.trojanhealth.co.za KEEP THIS MANUAL FOR FUTURE REFERENCE.
-
Page 2: Table Of Contents
• Fitness Tips & Techniques _____________________________________ 29 • Conditioning Guidelines _______________________________________ 30 • Warm Up & Cool Down _______________________________________ 31 • 2 Year Limited Warranty ______________________________________ 32 • Repair Procedure _____________________________________________ 33 • Notes _______________________________________________________ 34 ELITE 2000 - T... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS It is the sole responsibility of the purchaser of Trojan products to read the owner’s manual, warning labels and instruct all individuals, on proper usage of the equipment. Understanding each and every warning to the fullest is important. If any of these instructions or warnings are unclear please contact Trojan Customer Services on 0861 TROJAN (0861 876526), within the Republic of South Africa. - Page 4 INSPECTION • Do not use or permit use of any equipment that is damaged, or has worn or broken parts. For all Trojan equipment use only replacement parts supplied by Trojan. • Always make sure that all nuts and bolts are tightened prior to each use.
-
Page 5: Grounding Instructions
Make sure that the product is connected to an outlet with the same configuration as the plug. No adaptor should be used with this product. Please unplug the treadmill when not in use to avoid any damage in the event of power surges. GROUNDED OUTLET GROUNDING PIN ELITE 2000 - T... -
Page 6: Pre Assembly Check List
PRE ASSEMBLY CHECK LIST Thank you for choosing the Trojan ELITE 2000 Treadmill. We take great pride in producing this product and hope it will provide many hours of quality exercise to make you feel better, look better and enjoy life to its fullest. -
Page 7: Hardware & Tools List
2 PCS 2 PCS 2 PCS Hex Socket Screw Cross Washer Head Screw Hex Socket Cap Screw 2 PCS 5 PCS 1 PC Tool Hex Bolt Multi Tool Allen Key 2 PCS 1 PC Allen Key ELITE 2000 - T... -
Page 8: Parts List
Outer Upright Tube Cover Hex Socket Screw M10 X 50 Inner Upright Tube Cover Hex Socket Screw M10 X 40 Motor Cover Hex Socket Screw M10 X 15 29 L/R Protective Cover Hex Socket Screw M8 X 50 ELITE 2000 - T... - Page 9 Cross Pan Head Screw M4 X 8 Amplifier Board Lock Washer Φ10 X 1.2 SD Card / USB Socket Lock Washer Φ8 X 1.2 Filter Lock Washer Φ6 X 1.2 Inductor Flat Washer Φ13 X Φ8 X 1.2 Headphone Jack ELITE 2000 - T...
-
Page 10: Exploded Drawing
EXPLODED DRAWING ELITE 2000 - T... -
Page 11: Assembly Steps
Lock Washer (83). Note: Please do not tighten the Hex Socket Screw (57) for the time being. Place the Protective Cover (29 L/R) over the Left and Right Upright Tube (3) respectively as shown in the illustration. ELITE 2000 - T... - Page 12 PLEASE ENSURE THE ASSEMBLY HAS BEEN COMPLETED, PER THE ABOVE INSTRUCTIONS AND THAT ALL BOLTS ARE SECURELY TIGHTENED. ONCE THIS HAS BEEN CHECKED, YOU MAY PROCEED WITH THE INSTRUCTIONS THAT FOLLOW. PLEASE ENSURE THAT YOU READ THE INSTRUCTIONS CAREFULLY BEFORE OPERATING THE TREADMILL. ELITE 2000 - T...
-
Page 13: Folding Instructions
Note: Ensure that all parts are secured and correctly assembled before beginning to exercise with the treadmill. To prevent injury, please ensure that you, children or pets are not in the way of the descending running deck. ELITE 2000 - T... -
Page 14: Computer Functions
When the motor is running, press INCLINE - to decrease the incline. VOLUME: Adjusts the music volume. UP/NEXT: Changes the track currently playing. PROGRAM + MODE: When the safety key is removed, press PROGRAM+MODE for 3 seconds for metric / inch conversion. ELITE 2000 - T... -
Page 15: Operation Instructions
• When the set time, calories or distance reduces to zero the buzzer will “Beep” 3 times and the speed screen will display END. 5 seconds later, the machine will return to standby mode and the buzzer will “Beep” twice. ELITE 2000 - T... - Page 16 3 “Beeps”. The computer will display END. 5 seconds later, the machine will return to the standby mode. • Remove the safety key to stop the treadmill immediately. The LCD screen will display “---” and the buzzer will “Beep” 3 times. ELITE 2000 - T...
- Page 17 SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE ELITE 2000 - T...
- Page 18 The system has an energy-saving function. In standby mode, if the treadmill has not received any instruction from the user after 10 minutes, the system will enter the energy-saving mode automatically. Press any key to restart the system. ELITE 2000 - T...
- Page 19 • If the treadmill feels like it is not running correctly, remove the safety key and the treadmill will slow down and come to a complete stop. Insert the safety key to return to the standby mode. • Should you have any queries, please contact the Trojan Call Centre for assistance. ELITE 2000 - T...
-
Page 20: Trouble Shooting
Use correct voltage moving forward. 1. If the motor wires are not connected correctly, This error indicates that the motor wires are possibly not then reattach them correctly. connected correctly. ELITE 2000 - T... - Page 21 This error indicates a possible Check whether the external AC voltage is lower external AC under-voltage. than 160VAC or if it is unstable. If yes, then stop using machine and consult an electrician. ELITE 2000 - T...
-
Page 22: Technical Parameter
1120 x 940 x 1620 3.5 HP POWER RUNNING SURFACE (mm) INPUT CURRENT 520 x 1410 AS ORDER NET WEIGHT 97 KG SPEED RANGE 1.0 - 20 KM/H MAX WEIGHT 150 KG INCLINE 0 - 15 % ELITE 2000 - T... -
Page 23: Exercise Instructions
Work at your own pace, but it is very important to maintain a steady tempo throughout. The rate of work should be sufficient to raise your heart beat into the target zone shown on the graph below. ELITE 2000 - T... - Page 24 Once you are used to the speed, then you can run on the machine and you can add the speed between 3 and 5 Km/h. Keep the speed about 10 minutes, then stop the machine. ELITE 2000 - T...
- Page 25 Speed 6.0-7.5 Km/h Fast Walking Speed 7.5-9.0 Km/h Jogging Speed 9.0-12.0 Km/h Fast Jog/Run ATTENTION: VELOCITY OF MOVEMENT AT ≤6 KM/H, IS A NORMAL WALKING SPEED. THE VELOCITY OF MOVEMENT AT ≥9 KM/H IS CONSIDERED A RUNNING SPEED. ELITE 2000 - T...
-
Page 26: Maintenance
If in doubt do not use the treadmill and contact our help line. Take care to protect carpets and floor in case of leakages. This product is a machine that contains moving parts which have been greased/lubricated and could leak out. ELITE 2000 - T... - Page 27 To avoid slipping during running as well as possibly damaging the belt it is important that the belt is kept tight over the rollers. You can adjust the distance between the plates and the belt. Be careful not to make belt too tight or too loose. ELITE 2000 - T...
-
Page 28: Centre The Running Belt
Periodically adjust the tightness of the belt as the belt tends to loosen after use. Turn the left and right adjusting bolt 1/4 turn clockwise, then re-start running. Turn the bolt until the belt is tight. ELITE 2000 - T... -
Page 29: Fitness Tips & Techniques
MUSCLE CHART TROJAN ELITE 2000 TREADMILL The exercise routine that is performed on the Trojan ELITE 2000 Treadmill will develop the lower body muscle group as well as condition the circulatory system and provide a good aerobic workout. These muscle groups are highlighted on the muscle chart below. -
Page 30: Conditioning Guidelines
14, your heart rate is 140 beats per minute. (A six second count is used because your heart rate will drop rapidly when you stop exercising). Adjust the intensity of your exercise until your heart rate is at the proper level. For more information visit: www.trojanhealth.co.za ELITE 2000 - T... -
Page 31: Warm Up & Cool Down
Sit with the soles of your feet together and your knees outward. Pull your feet toward your groin area as far as possible. Hold for 15 counts, and then relax. Repeat 3 times. Stretches: Quadriceps and hip muscles. ELITE 2000 - T... -
Page 32: Year Limited Warranty
Consumer upon collection or delivery of the repaired product. The Consumer does not need to return the product to the store. The Consumer should call the Trojan Call Centre on 0861 Trojan (0861 876526). Customers residing outside South Africa can contact us on +27 10 206 4405 and the call centre will advise of the procedure. -
Page 33: Repair Procedure
Do not return the product to the store. Call the Trojan Call Centre on 0861 Trojan (0861 876526) to log the faulty product (under warranty or out of warranty). Customers residing outside South Africa can contact us on +27 10 206 4405. -
Page 34: Notes
