4044039NUK(Black) 4044449NUK(Grey) 4044139NUK(White)
Weight Limit: 500 Lb / 227 Kg
J.Z. - 2019/10/25
Thank you for purchasing from Dorel UK!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
01942 524100
Call
Date of Purchase
IMPORTANT - READ CAREFULLY - RETAIN FOR FUTURE REFERENCE
Metal Bed
King UK
Lot Number
B344044039NUK00
1
Advertisement
Related Manuals for Dorel 4044039NUK
Summary of Contents for Dorel 4044039NUK
- Page 1 Metal Bed King UK Weight Limit: 500 Lb / 227 Kg Thank you for purchasing from Dorel UK! DO NOT RETURN TO THE STORE ! If parts are missing or damaged, we will gladly ship your replacement parts free of charge.
-
Page 2: Warranty Information
Warranty Information Read Before Beginning Assembly Dorel UK warrants this product to be free from defects in material and workmanship Call our toll free number if you need assistance. and agrees to remedy any such defect. This warranty covers one year from the date Work in a spacious area and near where the unit will be used, preferably on a of original purchase. - Page 3 Parts Replacement Parts, Call 01942 524100 All in 1 big box! There are inner box(es) that include components required to complete this assembly. Before you throw the package, please use the Post Headboard Footboard Side Rail Check Box to identify the parts and ensure that you have all the parts needed for the assembly.
- Page 4 IMPORTANT: Below part numbers list is unique to your product. Parts Please keep it on hand when calling for replacement parts. Replacement Parts, Call 01942 524100 Part Number 4044039NUK(Black) 4044449NUK(Gunmetal Grey) 4044139NUK(White) Part Label T949230 T928770 T949200 T949240 T936380 T949210...
- Page 5 Hardware 4044039NUK(Black) Hardware Pack #: T4044449N-02 4044449NUK(Grey) 1/4" Hardware Pack #: T4006109N-00 4044139NUK(White) 1/4" X 11/16" 5/16" X 3/4" X 16 1/4" X 7/8" X 12 1/4" X 1 9/16" Wrench Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step instructions.
- Page 6 Step 1 Insert A X 2 into C with...
- Page 7 Step 2 Holes on the top side. Insert F X 2 into E X 2 with...
- Page 8 Step 3 3.1 Attach H X 2 to sub-assembly E/F x 2 from previous step with 3.2 Attach G to E X 2 with...
- Page 9 Step 4 This bed offers you 2 options for the height of the bed foundation. To assembly in Higher Position: From STEP 4 to STEP 8. To assembly in Lower Position: From STEP 9 to STEP 13. Attach M X 2 to G with...
- Page 10 Step 5 5.1 Attach sub-assembly E/F from previous step to A X 2, C and D with 5.2 Screw into A X 2, D. X 16...
- Page 11 Step 6 6.1 Insert one end of both I into the slot on G as illustrated. 6.2 Attach the other end of both I to H X 2 with...
- Page 12 Step 7 Attach M & K to G with...
- Page 13 Step 8 8.1 Insert O1 into E X 2 and F X 2 as illustrated. 8.2 Lock O1 into place with Y.
- Page 14 Step 9 To assembly in Lower Position: From STEP 9 to STEP 13. Attach L X 2 to G with...
- Page 15 Step 10 10.1 Attach sub-assembly E/F from previous step to A X 2 and D with 10.2 Screw into A X 2, C and D. 10.1 10.2 X 16...
- Page 16 Step 11 11.1 Insert one end of both I into the slot on G as illustrated. 11.2 Attach the other end of both I to H X 2 with 11.1 11.2...
- Page 17 Step 12 Attach L & K to G with...
- Page 18 Step 13 13.1 Insert O1 into E X 2 and F X 2 as illustrated. 13.2 Lock O1 into place with Y. 13.1 13.2...
-
Page 19: Helpful Hints
Move your new furniture carefully, with two people lifting and carrying the unit to its new location. Your Dorel UK furniture can be disassembled and reassembled to move. Some parts have been pre-assembled for this item. They are illustrated on this page and available for replacement.
