INSTRUCTION MANUAL
TWIN / TWIN BUNK BED
DA1010-1C / DA1010-2C (WHITE)
0-65857-17958-3 / 0-65857-17959-0 (WHITE)
0-65857-17961-3 / 0-65857-17962-0 (GRAY)
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
______________________________
______ / ______ / ______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer
service department. We will replace the part
1-800-295-1980
Model No:
DA1010-CU (WHITE)
DA1010G-CU (GRAY)
DA1010G-1C / DA1010G-2C (GRAY)
UPC CODE:
0-65857-17960-6 (WHITE)
0-65857-17963-7 (GRAY)
Lot number:
(TAKEN FROM CARTON)
Date of purchase:
FREE of charge.
NEED HELP!
Tel #: 1-800-295-1980
CALL US FOR ASSISTA
E-Mail: das@dorel.com
Fax #: 514-353-7819
DO NOT RETURN PRO
E-MAIL:DAS@DOREL.
NOTE:
Advertisement
Related Manuals for Dorel DA1010-CU
Summary of Contents for Dorel DA1010-CU
- Page 1 INSTRUCTION MANUAL Model No: DA1010-CU (WHITE) TWIN / TWIN BUNK BED DA1010-1C / DA1010-2C (WHITE) DA1010G-CU (GRAY) DA1010G-1C / DA1010G-2C (GRAY) UPC CODE: 0-65857-17960-6 (WHITE) 0-65857-17958-3 / 0-65857-17959-0 (WHITE) 0-65857-17963-7 (GRAY) 0-65857-17961-3 / 0-65857-17962-0 (GRAY) NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
- Page 2 12345 Albert-Hudon Boulevard, Suite 100 Montreal, Quebec Canada, H1G 3L1 E-MAIL: das@dorel.com WARNING STRANGULATION HAZARD - NEVER ATTACH OR HANG ITEMS TO ANY PART OF THE BUNK BED THAT ARE NOT DESIGNED FOR USE WITH THE BED; FOR EXAMPLE, BUT NOT LIMITED TO HOOKS, BELTS AND JUMP ROPES.
- Page 3 Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase.
- Page 4 TWIN / TWIN BUNK BED HARDWARE LIST ∅1/4" x 100mm ∅6.5mm x 48mm JOINT CONNECTOR (4mm HEX HEAD) WOOD JOINT CONNECTOR (4mm HEX HEAD) 16 PCS 14 PCS ∅6.5mm x 100mm ∅4mm x 35mm WOOD JOINT CONNECTOR (4mm HEX HEAD) FLAT HEAD WOOD SCREW 6 PCS 20 PCS...
-
Page 5: Parts List
TWIN / TWIN BUNK BED PARTS LIST LEFT HEADBOARD RIGHT HEADBOARD FOOTBOARD 2 PCS 1 PC 2 PCS... - Page 6 TWIN / TWIN BUNK BED PARTS LIST BOTTOM SIDE RAIL TOP SIDE RAIL TOP SIDE RAIL (WITH 2 HOLES) (WITH 1 HOLES) (WITH 3 HOLES) 1 PC 1 PC 1 PC BOTTOM SIDE RAIL SLAT LONG GUARDRAIL (WITH NO HOLES) 2 PCS 2 PCS 1 PC...
- Page 7 TWIN / TWIN BUNK BED Holes Holes STEP 1 Attach footboards (C) to the bottom side rails (E and G) using joint connectors (1) and barrel nuts (8) as shown. Use Allen key (9) to tighten all joint connectors. Note: This is the lower bunk.
- Page 8 TWIN / TWIN BUNK BED STEP 2 Insert wood dowels (7) into each end of the long guardrails (I). Attach two long guardrails (I) and two top side rails (D and F) to the headboards (A and B) as shown. Fasten top side rails (D and F) with joint connectors (1) and barrel nuts (8).
- Page 9 TWIN / TWIN BUNK BED STEP 3 Attach slats (H) to side rails (D and F) of the upper bunk and (E and G) of the lower bunk with flat head wood screws (4) using a Phillips head screwdriver (not included).
- Page 10 TWIN / TWIN BUNK BED STEP 4 Insert wood dowels (7) in the ends of short guardrails (J). Attach short guardrails (J) to left headboard (A) with wood joint connectors (3). Attach the guardrail leg (N) to the short guardrails (J) and top side rail (D) with flat head wood screws (5). Attach another guardrail leg (N) to long guard rails (I) and top side rail (F) with flat head wood screws (5).
- Page 11 TWIN / TWIN BUNK BED STEP 5 Place four wood dowels (6) into the holes in the bottom posts (C). Stack the top bunk onto the bottom bunk with the help of another person.
- Page 12 TWIN / TWIN BUNK BED 8 PCS 8 PCS STEP 6 To assemble the ladder, insert wood dowels (7) into the end of the ladder steps (M). Attach long ladder end (K) and short ladder end (L) to ladder steps (M) with wood joint connectors (2) and Allen key (9).
- Page 13 TWIN / TWIN BUNK BED 6PCS STEP 7 Attach the ladder to the short guardrails (J), the top side rail (D) and bottom side rail (E) with wood joint connectors (2) as shown. NOTE: If slats (H) are covering the ladder mounting holes, remove slats (H) and replace them after the ladder is attached.
- Page 14 TWIN / TWIN BUNK BED Instructions for converting the bunk bed into two single beds To be used as To be used as the headboard the headboard for single bed for single bed To be used as the footboard To be used as for single bed the footboard for single bed...
- Page 15 DO NOT RETURN PRODUCT TO THE STORE. If a part is missing or damaged, contact our customer service department. We will replace the part FREE of charge. NEED HELP! Tel #: 1-800-295-1980 CALL US FOR ASSISTAN E-Mail: das@dorel.com 1-800-295-1980 DO NOT RETURN PRODU...
-
Page 16: Customer Service
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name: Shipping Address: Street &...
