Chapter 3: Hardware Design

1

Equipment View

18
This chapter demonstrates the main hardware characteristics from RT412
With a compact design, all the equipment connections can be access by one side.
The RT412 comprises:
•
One power supply, AC/DC high voltage;
•
One electrical input, one optical input and one input selection connection for time
reference;
•
Two TTL electrical outputs for synchronization, been Euro Type connector;
•
One optical output using ST connector;

Figure 2: Front view of RT412

Figure 3: View from RT412 connectors
