VERSION # 20-07-22
1 / 9
MODEL #
CM3319T
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM3319T
Summary of Contents for Furniture of America CM3319T
- Page 1 MODEL # CM3319T Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 9...
- Page 5 TABLE CM3319T #1 1pc #2 2pcs #3 2pcs #4 2pcs #5 2pcs #6 6pcs Table Top Leaf Table Stand Table Base Stand Base Foot #D 44pcs #A 24pcs #B 12pcs #C 8pcs Lock washer Bolt 5/16"x1-3/4" Bolt 5/16"x2-1/2" Bolt 5/16"x1-3/8"...
- Page 6 CM3319T is packed in 2 cases Carton Disignation Part Hardware #A 24pcs Table top #B 12pcs #C 8pcs #D 44pcs Table Leaf CM3319T-1 #E 44pcs #F 1pc Foot Table Stand Table Base CM3319T-2 Stand Base 6 / 9...
- Page 7 ASSEMBLY INSTRUCTIONS Align feet (#6) to the base (#5), then secure by using bolts (#B) with washers (#D,E). Part #5 x2pcs Part #6 x6pcs Hardware #B x12pcs Hardware #D x12pcs Hardware #E x12pcs Align pedestal (#3) to the base, then secure by Part #3 x2pcs using bolts (#A) with washers (#D,E).
- Page 8 ASSEMBLY INSTRUCTIONS Part #4 x2pcs Align table top base (#4) to the Hardware #A x12pcs pedestal, then secure by using bolts Hardware #D x12pcs (#A) with washers (#D,E). Hardware #E x12pcs Align table base to the table top (#1), Part #1 x1pc then secure by using bolts (#C) with Hardware #C x8pcs washers (#D,E).
- Page 9 ASSEMBLY INSTRUCTIONS Part #2 x2pcs Use the locking mechanism on the bottom of the table top. 9 / 9...
