- Page 1 MODEL # CM3319RT Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product. VERSION # 20-07-22 1 / 8...
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 8...
- Page 5 TABLE CM3319RT #1 1pc #2 1pc #3 1pc #4 1pc #5 4pcs Table Top Table Stand Table Base Stand Base Foot #D 24pcs #A 20pcs #B 4pcs #C 24pcs Flat washer Lock washer Bolt 5/16"x2-1/2" Bolt 5/16"x1-3/8" Ø5/16" Ø5/16" #E 1pc Allen wrench 5 / 8...
- Page 6 CM3319RT is packed in 2 cases Disignation Carton Part Hardware #A 20pcs Table top #B 4pcs #C 24pcs #D 24pcs Table Base #E 1pc CM3319RT-1 Stand Base Foot CM3319RT-2 Table Stand 6 / 8...
- Page 7 ASSEMBLY INSTRUCTIONS Align feet (#5) to base (#4), then secure by using bolts (#A) with Part #4 x1pc washers (#C,D) Part #5 x4pcs Hardware #A x8pcs Hardware #C x8pcs Hardware #D x8pcs Align pedestal (#2) to the base, then secure by using bolts (#A) with washers Part #2 x1pc (#C,D).
- Page 8 ASSEMBLY INSTRUCTIONS Align table top base (#3) to the pedestal, then secure by using bolts Part #3 x1pc (#A) with washers (#C,D). Hardware #A x6pcs Hardware #C x6pcs Hardware #D x6pcs Align table base to the table top (#1), Part #1 x1pc then secure by using bolts (#B) with washers (#C,D).
