ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
product (with 1 being easy and 5 being
difficult). For most products, two
persons are recommended.
EASY
YNJ-1521
DIFFICULT
Page 1
E-commerce-Enitial Lab
Tools Required for Assembly
Allen Wrench
Phillips Screwdriver
2 PERSON RECOMMENDED
( Included)
(Not Included)
15.07.22
Advertisement
Related Manuals for Furniture of America YNJ-1521
Summary of Contents for Furniture of America YNJ-1521
- Page 1 E-commerce-Enitial Lab ASSEMBLY INSTRUCTIONS YNJ-1521 ASSEMBLY RATING Tools Required for Assembly The Assembly Rating is a 5-point system that shows the degree of effort Allen Wrench needed in assembling a specific ( Included) product (with 1 being easy and 5 being difficult).
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5...
- Page 6 COFFE TABLE ASSEMBLY INSTRUCTIONS MODEL # YNJ-1521 Please keep for future reference PARTS LIST Before you begin, please read "Assembly and Care Advice","Pre- Assembly Introduction" and "Cam Lock Fastener Assembly Instructions" DIMENSIONS 47.24“ (W) X23.62" (D) X17.28" (H) 2PCS 2PCS...
- Page 7 ASSEMBLY INSTRUCTIONS Assembling Drawer’s Runners (a.k.a. Rails, Glides, Slides or Guides) An assembly of ONE drawer requires two sets of runners. The runner is composed of an inner rail and outer slide. Please read completely first before assembling. Mounting the Inner Rail (Fixed) of the Runner: Before mounting, please determine which side of the panel is the front and rear.
- Page 8 ASSEMBLY INSTRUCTIONS STEP2 Hardware #1=12pcs Hardware #2=8pcs Hardware #3=54pcs Hardware #5=4pcs Page 8...
- Page 9 ASSEMBLY INSTRUCTIONS STEP3 Hardware #1=8 pcs Hardware #2=12pcs Hardware #4=10pcs Hardware #5=12pcs Page 9...
- Page 10 ASSEMBLY INSTRUCTIONS STEP4 Hardware #1=4pcs Hardware #2=4pcs Hardware #3=4pcs Hardware #4=8pcs Page 10...
- Page 11 ASSEMBLY INSTRUCTIONS STEP5 Hardware #6=2pcs Hardware #7=4pcs Hardware #10=4pcs Make sure the product is rested on a flat surface and does not feel loose or wobbly. If it does, double check that the bolts/screws are secured and properly tightened. ASSEMBLY IS COMPLETED Page 11...
