Outdoor Charcoal Barbecue Grill
Model No. XGS236178263002 / CBC2204W
Model No. XGS236178263002 / CBC2204W
Table of Contents
. . . . . . . . . . . . . . . . . . . .
Expanded View & Hardware . . . . . . . . . . . . . . . . . . . 4
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . 5
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . 7
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Combustion by-products produced when using this product
contain chemicals known to the State of California to cause
cancer, birth defects, and other reproductive harm .
Wash your hands after handling this product .
This instruction booklet contains important safety information .
Please read and keep for future reference .
Keep this owner's manual for future reference . If you sell or
give this product to someone else, make sure this manual
accompanies this product .
Walmart call center:
Service hours 7 days/week, 7:00 AM - 9:00 PM CST
Contact number: 1-833-908-2026
Manufactured in China for:
RevoAce Inc . Limited / Hong Kong, China
OWNER'S MANUAL
OWNER'S
CALIFONIA PROPOSITION 65
This product can expose you to
chemicals including carbon black,
which is known to the State of
California to cause cancer.
For more information, go to www.
P65Warnings.ca.gov.
Do not leave this appliance
unattended, especially cooking the
fatty meat and close the lid too long
time.
For Outdoor Use Only!
(outside any enclosure)
Page 2
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you.
It gives off carbon monoxide, which
has no odor.
Never burn charcoal in enclosed
spaces E.g. Homes, vehicles or tents.
Failure to follow the danger, warning
and cautions in this manual may
result in seriousbodily injury or death,
or in a fire or an explosion causing
damage to property.
CBC2204W-OM-E-F100
MANUAL
WARNING
DANGER
WARNING
WARNING
DANGER
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EXPERT GRILL XGS236178263002
Summary of Contents for EXPERT GRILL XGS236178263002
- Page 1 OWNER’S OWNER’S MANUAL MANUAL Outdoor Charcoal Barbecue Grill Model No. XGS236178263002 / CBC2204W Model No. XGS236178263002 / CBC2204W WARNING CALIFONIA PROPOSITION 65 This product can expose you to chemicals including carbon black, which is known to the State of California to cause cancer.
- Page 2 FOR YOUR SAFETY W WARNINGS: W Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. W Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment. W Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury, or death.
- Page 3 IMPORTANT SAFEGUARDS mittens, etc.). Doing so will greatly reduce the life of the metal and finish of your grill. W Never touch grates (charcoal, cooking or warming), ashes or coals to see if they are hot. W Check to make sure the air vents are free of debris and ash before using the grill.
- Page 4 Expanded View Parts List Lid Air Vent B0105-A01 Air Vent Handle* (2) B0106-D00 Handle (2) C1904-010 Brand Plate* B0109-LBA Cooking Grid C1904-030 Charcoal Grid C1904-040 C2204-010 Lid Hanger* C1904-090 Bottom Bowl C1904-050 Bottom Air Damper C2204-020 Rear Leg (2) C1904-070 Front Leg (2) C1904-060 Bottom Grid...
- Page 5 Assembly Instructions DO NOT RETURN TO PLACE OF PURCHASE Attach Handle, Lid Air Vent Please have your owner’s manual and model number available for reference . For Easiest Assembly: 1 . Select an area where you will assemble this product . To protect components, choose a smooth surface that’s free of cracks or openings .
- Page 6 Attach Bottom Grid and Wheels Attach Bottom Air Damper and Handle Insert Charcoal Grid, Cooking Grid and Cover Lid Hang Lid on to Bottom Bowl Assembly to Bottom Bowl Assembly...
- Page 7 Operating Instructions W CAUTION: Never use charcoal that has been pre-treated with lighter fluid. Use only a high grade plain charcoal, charcoal/wood mixture, lump charcoal or cooking wood. First Use WARNING Make sure all labels, packaging and protective films have been removed from the grill . Remove manufacturing oils before cooking on this grill for the first time, by operating the grill for at least 15 minutes with the lid closed .
- Page 8 Cleaning and Care Before Each Use Keep the grill area free and clear from any combustible materials, gasoline, and other flammable vapors and liquids . See below for proper cleaning instructions . Cleaning Surfaces Wait for grill to fully cool . Wipe surfaces clean with a mild dishwashing detergent or baking soda mixed with water .
Need help?
Do you have a question about the XGS236178263002 and is the answer not in the manual?
Questions and answers
How do I use the cotter pin for the wheels?
To use the cotter pin for the wheels on the EXPERT GRILL XGS236178263002:
1. Slide the wheel onto the axle or shaft.
2. Insert the cotter pin (ø1.4x30) through the hole at the end of the axle, beyond the wheel.
3. Bend the ends of the cotter pin outward to secure the wheel in place.
This prevents the wheel from sliding off during use or movement.
