EXPERT GRILL XGS236178263003 Owner's Manual

EXPERT GRILL XGS236178263003 Owner's Manual

Outdoor lp gas barbecue grill
Hide thumbs

Advertisement

Quick Links

Outdoor LP Gas Barbecue Grill
Model No. XGS236178263003 / GBT2210W
Model No. XGS236178263003 / GBT2210W

Table of Contents

. . . . . . . . . . . . . . . . . . . .
Important Safeguards
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . 8
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . 11
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . 13
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
The use and installation must conform with local
codes or, in the absence of local codes, with either the
National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural
Gas and Propane Installation Code, CSA B149.1, or
Propane Storage and Handling Code, B149.2, or the
Standard for Recreational Vehicles, ANSI A 119.2/NFPA
1192, and CSA Z240 RV Series, Recreational Vehicle
Code, as applicable .
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION . PLEASE READ AND KEEP FOR
FUTURE REFERENCE .
If you are assembling this unit for someone else, give
this manual to him or her to read and save for future
reference .
Walmart call center:
Service hours 7 days/week, 7:00 AM - 9:00 PM CST
Contact number: 1-833-908-2026
Manufactured in China for:
RevoAce Inc . Limited / Hong Kong, China
GBT2210W-OM-E-F100
OWNER'S MANUAL
OWNER'S
WARNING
FOR YOUR SAFETY:
1. Do NOT store or use gasoline or
other flammable liquids or vapors in
the vicinity of this or any other
appliance.
2. An LP cylinder not connected for
use shall not be stored in the vicinity
of this or any other appliance.
DANGER
Do not leave this appliance
unattended, especially cooking the
fatty meat and close lid too long time.
Failure to follow the dangers,
Page 2
warnings and cautions in this manual
may result in serious bodily injury
or death, or in a fire or an explosion
causing damage to property.
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only!
DANGER
If you smell gas:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from
the appliance and immediately
call your fire department. Failure
to follow these instructions could
result in fire or explosion which
could cause property damage,
personal injury or death.
MANUAL
(outside any enclosure)

Advertisement

loading
Need help?

Need help?

Do you have a question about the XGS236178263003 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EXPERT GRILL XGS236178263003

Summary of Contents for EXPERT GRILL XGS236178263003

  • Page 1: Table Of Contents

    OWNER’S OWNER’S MANUAL MANUAL Outdoor LP Gas Barbecue Grill Model No. XGS236178263003 / GBT2210W Model No. XGS236178263003 / GBT2210W WARNING FOR YOUR SAFETY: 1. Do NOT store or use gasoline or other flammable liquids or vapors in the vicinity of this or any other appliance.
  • Page 2 FOR YOUR SAFETY WWARNINGS: 1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. 2. Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment. 3. Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury, or death.
  • Page 3 IMPORTANT SAFEGUARDS W Only use LP gas cylinders equipped with a cylinder connection device compatible with the connection for outdoor cooking appliances. W The LP gas cylinder must have a cylinder collar to protect the cylinder valve. W Never use an LP gas cylinder with a damaged body, valve, collar or footing. W Dented or rusted LP gas cylinders may be hazardous and should be checked by your LP gas supplier prior to use.
  • Page 4 IMPORTANT SAFEGUARDS W Do NOT use in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline and other flammable vapors and liquids. W Minimum clearance from sides and back of unit to combustible construction is 36 inches (91.4 cm). Do NOT use this appliance under any type of overhang or roof.
  • Page 5 IMPORTANT SAFEGUARDS grill does not light, may result in an explosive flame-up. W Never operate grill without its heat plates installed. W Always use a meat thermometer to ensure food is cooked to a safe temperature. W Use protective gloves when assembling this product. W Do NOT force parts together as this can result in personal injury or damage to the product.

  • Page 6: Expanded View & Hardware

    Expanded View...
  • Page 7 Parts List Handle G1904-010 Regulator/Control Knob G2210-030 Brand Plate* B0109-LBA Leg Support A (2) G2210-040 G2210-010 Leg Support B (2) G2210-050 Lid Handle Plate G2014-020 Heat Shield G1814-040 Cooking Grid G2014-040 Leg (2) G2014-090 * Pre-assembled Heat Plate B0230-C00 Heat Plate Support (2) B0231-B00 Burner G2014-050...

  • Page 8: Assembly Instructions

    Assembly Instructions Attach Lid Handle and Lid Handle Plate DO NOT RETURN TO PLACE OF PURCHASE. Please have your owner’s manual and model number available for reference . Note: The model number can be found on the back or side of the grill .
  • Page 9 Attach Heat Plate Supports Attach Heat Shield and Burner Insert Heat Plate, Cooking Grid and attach Cover Lid Regulator/Control Knob Note: Once attached, the regulator/control knob will freely rotate to accomodate for the LP gas tank .
  • Page 10 Fold Legs and Lock Lid Note: Lid must be locked before transporting grill . Unfold Legs and Unlock Lid Note: Always open legs completely and secure in place befor lighting grill . .

  • Page 11: Operating Instructions

    Operating Instructions Figure 1 This grill is designed to operate with a 1 lb . 7 .75 in . or 10 .6 in . high disposable / 16 .4 oz . or 14 .1 oz . propane gas tank (DOT 39 Cylinder) (Figure 1) . CAUTION 1 lb 1 lb...
  • Page 12 Operating Instructions (Continued) Lighting Instructions Figure 6 W CAUTION: Keep outdoor gas cooking appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. W CAUTION: Do NOT obstruct the flow of combustion and ventilation air. W CAUTION: Check and clean burner/venturi tubes for insects and insect nests.

  • Page 13: Cleaning And Care

    Operating Instructions (Continued) If a grease fire occurs, close the lid AND turn regulator/control knob to “ OFF,” until the grease burns out . Use caution when opening the lid as sudden flare-ups may occur . If excessive flare-ups occur, do NOT pour water onto the flames . Minimize Flare-ups: Trim excess fat from meats prior to cooking .
  • Page 14 Cleaning and Care (Continued) 10 . Clean any clogged ports with a stiff wire (such as an opened paper clip) . 11 . Inspect burner for any damage (cracks or holes) . If damage is found, replace with a new burner from manufacturer . 12 .

  • Page 15: Limited Warranty

    Limited Warranty RevoAce Inc . Limited (“RA”) warrants to the original retail purchaser of this product, and to no other person, that if this product is assembled, maintained, and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year for all remaining parts from the date of purchase, all parts in such product shall be free from defects in material and workmanship .

  • Page 16: Troubleshooting

    Troubleshooting Problem Possible Cause Prevention/Cure LP gas tank is low or empty Replace LP gas tank Turn LP gas tank valve to “ OFF” LP gas leak Wait 5 minutes for gas to clear Follow “Checking for Leaks” section Wires or electrode covered with cooking residue Clean wire and/or electrode with rubbing alcohol Electrode and burners are wet Wipe dry with cloth...
