CAPTURE HOOD
MODEL 6710 version 2
INSTRUCTION MANUAL
Be sure to read this manual thoroughly before using the instrument.
Fully understand and pay attention to each caution mentioned.
Please keep this manual as a service reference.
0 1 0 0 3
1 5
08
www.lazodecontrol.com
+51 960 810 089
ventas@lazodecontrol.com

Advertisement

Table of Contents
loading

Related Manuals for Kanomax 6710

Summary of Contents for Kanomax 6710

  • Page 1 CAPTURE HOOD MODEL 6710 version 2 INSTRUCTION MANUAL Be sure to read this manual thoroughly before using the instrument. Fully understand and pay attention to each caution mentioned. Please keep this manual as a service reference. 0 1 0 0 3 www.lazodecontrol.com...
  • Page 2 Thank you for your purchasing a KANOMAX instrument. This is a precision instrument, please read this instruction manual carefully before using the instrument and pay attention to all the cautions under the instructions. www.lazodecontrol.com +51 960 810 089 ventas@lazodecontrol.com...
  • Page 3 Composition & Parts  Standard part: Model No. Functions 6710 Air quantity/temperature/humidity  Standard components: Items Main structure User Manual Carrying Case Instrument Base 2ft×2ft Fabric hood Frame poles for 2ft×2ft hood Communication cable Software Installer  Optional components: Items...
  • Page 4  ATTENTIONS & NOTES The warning symbols mentioned in this manual are defined below: symbol classifications Danger: To Prevent Serious Injury or Death Warnings in this classification indicate a danger that may result in serious injury or death if not observed.
  • Page 5          DANGER Do not exposure the instrument to rain or water.  …… Otherwise, it may cause an electric shock, fire or injury. Forbidden CAUTION Always unplug the instrument when it is not in use. ...

  • Page 6: Table Of Contents

    CONTENTS 1 Introduction ............................1 1.1 Product features ........................1 2. Capture Hood Structure........................2 2.1 Instrument Base ........................2 2.2 Main structure ......................... 3 2.3 Fabric Hood ..........................3 3. Installation and Assembling ......................3 3.1 Capture Hood Installation ..................... 3 3.2 Assembling the Frame (detail) .....................
  • Page 7 5.1.3 Set Units of Measure for Airflow, Temperature and Atmos ......... 16 5.1.4 Actual flow, Standard flow settings ................. 17 5.2 General Settings........................18 5.3 Data processing settings ..................... 19 5.4 Communication settings ...................... 20 5.5 Print Settings......................... 21 6.Main Specifications ......................... 23 7.

  • Page 8: Introduction

    1 Introduction The model 6710 is used to measure the air flow at the supply and the exhaust points of an HVAC system. There are several interchangeable hoods of various sizes so it’s easy to find one that will match the size of the supply and exhaust points of any HVAC system.

  • Page 9: Capture Hood Structure

    Capture Hood Structure The capture hood consists of a fabric hood, main structure and an instrument base. The structural drawing is below: Fabric hood Instrument base Main structure 2.1 Instrument Base The exterior structure of the base as below: 2 The internal structure of the base as below: Back pressure plate Portable handle Back pressure on/off...

  • Page 10: Main Structure

    2.2 Main structure Battery Compartment Cover lock Keypad Display LCD Cover Socket POWER communicatio   Side view Back Front view 2.3 Fabric Hood The fabric hood kit consists of a frame, and a fabric hood with four windows as shown below: Window Frame Fabric hood...

  • Page 11: Assembling The Frame (Detail)

    2 The figures below are provided as a reference. a. Use the mark and the stitching as a guide to ensure the hood position. b. Make sure the hood fully wraps around the base. 3.2 Assembling the Frame (detail) Insert one end of a support pole into its pole mount in the base as in figure and the other end into the frame corner as in figure .

  • Page 12: Installing The Main Structure

    Note The support poles and the portable handle should be disassembled before packing the capture hood in the carrying case to avoid damaging the case. 3.4 Installing the Main structure To install the Main structure , set the bottom of the panel in the holder on the unit base and gently push the top of the panel backwards until it locks into place.

  • Page 13: Supplying Power With Batteries

    4.2 Supplying Power with Batteries 4 AA-size batteries can be used for a power supply.  Press the compartment cover lock (refer to figure ), and then slide the cover off to open  the battery compartment. Put 4 AA-size batteries in and make certain the batteries are correctly oriented. ...

  • Page 14: On/Off

    4.3 ON/OFF 1. Getting started The LCD is displayed below for reference: 1 Press POWER for a while. 2 Then you enter into the main interface as shown in the left figure. 2. Shut down Press and hold POWER for more than 2 seconds in any mode, and the instrument will turn off automatically.

  • Page 15: Incline Adjustment Settings Of The Instrument

    SAVE: Save the current test results.  SET: Store changes or enter into the selected option’s next level interface.  MENU: On the main screen holding this down for 2 seconds will enter into the main  “MENU”. OK: Pressing for 2 seconds will save the date or time in the “General Settings”, ...

  • Page 16: Back Pressure Compensation On / Off Settings

    Right switch makes the panel tilt up. Left switch makes the panel tilt down. Note 1. The instrument may turn off, when you attempt to adjust the incline settings of the instrument if the battery display is at 2. You can’t adjust the incline settings of the instrument when testing or if you’re not in the main interface.

  • Page 17: Measuring

    4.7 Measuring 4.7.1 Start and enter into the main interface To start measuring, go to the main interface menu as shown below: 2012 / 06 / 01 13 : 10 : 10 : 13 : 050 - - - - m³/h 25.4 53.4...
  • Page 18 1 “Single” measurements are individual flow measurements. When you press “START”, the instrument will begin measuring and the air flow value will be displayed as “- - - -”. 2 The test will stop automatically when the air flow is stable and a flow value with the corresponding wind direction will be displayed.

  • Page 19: Back Pressure Compensation Measurement Mode

    4.7.4 Back Pressure Compensation Measurement Mode When measuring air flow in an environment with a strong wind or turbulent flow, it will produce resistance for test air flow and system pressure. It is suggested you turn the Back Pressure Compensation ON when the air flow is more than 1500 m /h, otherwise you can test without the Back Pressure Compensation ON.

  • Page 20: Test Settings

    5.1 Test Settings 1 Press to select “Test Settings”, and press enter into “Test Settings”. Press return to the main interface. (2) The option items in “Test Settings” are as follows: 1. Test ID 2. Test Mode 3. Unit 4. Act. Std (Actual / Standard air flow setting www.lazodecontrol.com +51 960 810 089 ventas@lazodecontrol.com...

  • Page 21: Test Id Setting

    5.1.1 Test ID setting A Test ID consists of a group of Cycles (or Samples). A Test ID can contain up to 100 Cycles. The maximum number of Test IDs is 30. Any new Sample will be saved to the current Test ID. You can change the current Test ID at any time to keep your data organized.

  • Page 22: Test Mode Settings

    5.1.2 Test Mode settings This setting is for change the test mode & the settings about the test modes. Refer to the steps below:  Under “Test Settings”, press to select 2 “Test Mode”.  Press to enter into the “Test Mode” setting. ...

  • Page 23: Set Units Of Measure For Airflow, Temperature And Atmos

    5.1.3 Set Units of Measure for Airflow, Temperature and Atmos For available units, refer to the below chart Display shows Available units Air flow m³/h, CFM, l/s Temperature Atmos kPa, inHg To change the units of measure, follow these steps: ...

  • Page 24: Actual Flow, Standard Flow Settings

    5.1.4 Actual flow, Standard flow settings This setting is for selecting Actual air flow [ACT] or Standard air flow [STD].  Under the “Test Settings”, select option 4 “Act. Std”.  Press to enter or press to return to “MENU”. ...

  • Page 25: General Settings

    5.2 General Settings  Under “MENU”, select option 2 “General Settings”.  Press to enter “General Settings” or press return to the main interface.  The settings includes: Date, Time, Backlight and Auto 2012 Shut. High Under option 1, press ...

  • Page 26: Data Processing Settings

    5.3 Data processing settings  Under “MENU” select option 3 “Record Processing”.  Press to select “Record Processing”. Press return to the main interface.  Press to select option 1 or 2.  Press to select a setting to change, or press quit.

  • Page 27: Communication Settings

    Under option 1, press  Press to select option item as below. 1. Delete All 2. Delete IDs Select ID  Press for 2 seconds to save the changes or press 3. Delete Cycles Select ID to quit. Select Cycle Under option 2, press 1.

  • Page 28: Print Settings

    5.5 Print Settings Note Before printing ensure the following: 1. Please select the factory configuration printer and printer cable. For details, refer to the printer manual <<RD series of mini-printer>>. 2. Baud Rate is set to 19200. The initial value is set to 19200. ...
  • Page 29 Under option 1, press  Press to select the “Start ID” value.  Press to save or press to quit.  Press to select the “Stop ID” value.  Press to save or press to quit.  Press to select option item as below. ...

  • Page 30: Main Specifications

    Main Specifications Items 6710 version 2 Flow range 40 4300 m³/h Air Flow Accuracy Readings ±3%± 8 m³/h Air Flow 85 m³/h Resolution 1 m³/h Temperature range 0 60 Temperature Accuracy ±0.5 within 5 40 ±0.3 Resolution Humidity range 0 100%RH...

  • Page 31: Common Trouble Shooting

    7. Common Trouble Shooting Symptom Possible causes / troubleshooting Check the positive/negative connections of the batteries. Verify the batteries are inserted correctly. No display Low battery charge. Replace or recharge the batteries. Low battery charge. Replace or recharge the batteries. A test is running.

  • Page 32: Warranty

    This limited warranty covers all defects encountered in normal use of the PRODUCT, and does not apply in the following cases: (1) Use of parts or supplies other than the PRODUCT sold by KANOMAX GROUP COMPANIES, which cause damage to the PRODUCT or cause abnormally frequent service calls or service problems.

  • Page 33: After Service

    When making an inquiry, please provide the following information. (1) PRODUCT name: Capture Hood (2) Model Number: 6710 or XXXX xxxxxx (3) Serial number: (4) P/O or Invoice No: xxxxxx (5) Description of the problem in detail:...
