- Page 1 Mirrored Core Cabinet 1 Door 313/5226 32cm 13cm 46cm Issue 2 - 06/29/20...
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline:03456 400800 Please check you have all the panels listed below Left side panel x 1 3 Back rail x 1 Right side panel x 1 5 Bottom panel x 1 6 Adjustable shelf x 1 4 Top panel x 1 7 Back panel x 1...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note:The quantities below are the correct amount to complete the assembly .In some cases more fittings may be supplied than are required. Hinge x 2 Locking pin x 4 Locking nut x 4 Φ4 x 12mm Screw x 12...
- Page 5 Assembly Instructions Step 1 Assembling side panels NOTE:It would be useful to ask someone to help you at this stage. Screw 4 x locking pin into left side panel and right side panel Insert 6 x wooden dowel to left side panel as shown.
- Page 6 Assembly Instructions Step 2 Assembling door panel NOTE:It would be useful to ask someone to help you at this stage. Use 4 x screw to fix 2 x hinge onto door panel Carefully attach door panel to the unit by fixing hinge onto side panel with 12mm screws Adjust the door up or down, left or right, in or out if needed as shown:...
- Page 7 Assembly Instructions Step 8 Step 3 Finishing the unit NOTE:It would be useful to ask someone to help you at this stage. Use 45mm screw and wall plug to fix the unit on the wall as shown. Insert 4 x plastic support into left side panel and right side panel.
-
Page 8: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
