CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS
IN THE AREA.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD INSERT. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
MATRIX 1900
INSERT
(OB01900 Model)
Wood Insert
Owner's Manual
Part 2 of 2
INSTALLATION AND
OPERATION REQUIREMENTS
Safety tested according to
ULC S628, UL 1482 and
UL 737 by an accredited
US Environmental Protection
Agency phase II certified
wood insert compliant with
2020 cord wood standard.
laboratory.
EPA
< ≤
2.5
g/h
46278A
Advertisement
Table of Contents
Related Manuals for Osburn MATRIX 1900
Summary of Contents for Osburn MATRIX 1900
- Page 1 Wood Insert Owner's Manual Part 2 of 2 INSTALLATION AND OPERATION REQUIREMENTS MATRIX 1900 INSERT (OB01900 Model) Safety tested according to ULC S628, UL 1482 and UL 737 by an accredited laboratory. US Environmental Protection Agency phase II certified wood insert compliant with 2020 cord wood standard.
- Page 2 It is also highly recommended to register the warranty online at https://www.osburn-mfg.com/en/warranty/warranty-registration/ Registering the warranty will help to quickly find the information needed on the unit.
- Page 3 CERTIFICATION PLATE...
-
Page 5: Table Of Contents
3.10 Optional Fresh Air Intake Kit Installation...............29 3.11 Optional Fire Screen Installation ..................30 3.12 Air Tubes and Baffle Installation ..................31 3.13 Removal Instructions ....................34 3.14 Exploded Diagram and Parts List ................35 4. OSBURN LIMITED LIFETIME WARRANTY ................38 Product Specification Manual - Matrix 1900 Page 5... -
Page 6: General Information
This appliance is officially tested and certified by an independent agency. Tested and certified in compliance with CFR 40 part 60, subpart AAA, section 60.534(a)(1(ii) and draft ASTM WK47329-14 based on the ATM send by EPA on October 12th, 2017. Carbon monoxide. Page 6 Product Specification Manual - Matrix 1900... -
Page 7: Specifications
CAN/CSAZ240 MH standard. Tested and certified in compliance with CFR 40 part 60, subpart AAA, section 60.534(a)(1(ii) and draft ASTM WK47329-14 based on the ATM send by EPA on October 12th, 2017. Product Specification Manual - Matrix 1900 Page 7... -
Page 8: Dimensions
15 1/4" 8 1/8" 388mm 36" 206mm 914mm 18" 457mm 10 1/2" 2 1/4" 265mm 57mm 8 1/8" 206mm 18" 457mm 10 1/2" 2 1/4" 265mm 57mm Figure 3 : Front View Page 8 Product Specification Manual - Matrix 1900... - Page 9 19 1/4" 315mm 490mm 12 3/8" 315mm Figure 5 : Top View - Combustion Chamber Figure 6 : Side View - Combustion Chamber Product Specification Manual - Matrix 1900 Page 9 MATRIX 1900 (OB01900) MATRIX 1900 (OB01900) CHAMBRE À COMBUSTION/COMBUSTION CHAMBER...
-
Page 10: Epa Loading
OFF to avoid blowing ash outside the combustion chamber. Refer to section "5.1 Blower" of the owner's manual for how to turn OFF the fan. Page 10 Product Specification Manual - Matrix 1900... -
Page 11: Clearances To Combustible Material
1" (25 mm) 15 ½" (394 mm) surround If a fresh air intake is required, it is recommended to add at least 4" to the width of the minimum opening of the hearth. Product Specification Manual - Matrix 1900 Page 11... -
Page 12: Floor Protection
(0 mm) D=B- G (257 mm) extension facing From door opening. The depth of the hearth extension in front of the insert is included in the calculation of the floor protector’s dimensions. Page 12 Product Specification Manual - Matrix 1900... -
Page 13: R Value
Four inches of brick (R = 4 x 0,2 = 0,8) plus 1 inch of Durock® (R = 1 x 0.52 = 0.52). Information as reported by manufacturers and other resources. Horizontal still air can’t be «stack» to accumulate R-values; each layer must be separated with another non-combustible material. Product Specification Manual - Matrix 1900 Page 13... - Page 14 K values to R by dividing the thickness of each material by its K value. Add R values of the proposed materials as shown in the previous example. Exemple: K value = 0.75 Thickness = 1 R value = Thickness/K = 1/0.75 = 1.33 Page 14 Product Specification Manual - Matrix 1900...
-
Page 15: Installing Options On Your Product And Replacing Parts
Remove the split pin by pulling and turning it using pliers. Turn the handle one counterclockwise turn to increase pressure. Reinstall the split pin with a small hammer. Figure 11 : Removing the split pin Figure 12 : Installing the split pin Product Specification Manual - Matrix 1900 Page 15... - Page 16 Using a flat screwdriver, turn the adjustable hinge rods in the direction shown to adjust the doors. Tighten all door hinge pressure screws when they are at the desired positions. Configurations 1-2-3-4-5-6, show in which direction these act on the adjustment of the door. Page 16 Product Specification Manual - Matrix 1900...
-
Page 17: Removal Of Refractory Stones
Close the door. Do not use the insert for 24 hours. VIDER LA CHAMBRE DE COMBUSTION Removal of Refractory Stones 1. Empty the combustion chamber. Figure 13 : Empty the combustion chamber Product Specification Manual - Matrix 1900 Page 17... -
Page 18: Connecting The Blower With A Bx Wire
(B) and gain access to the wires. Save the screws for later. 2. Disconnect the black (C) and white (D) wires. 3. Remove the ground screw (E) to remove the green wire. Save the screw for later. Page 18 Product Specification Manual - Matrix 1900... - Page 19 5. Remove the piece of metal (G) from the plate (B) obstructing the hole to the left of the power cord (H) using pliers or a screwdriver. Cut the power cord (H) on each side of the black clamp. Product Specification Manual - Matrix 1900 Page 19...
- Page 20 9. Close the connection box by screwing in the plate (B) with the two screws (A) kept in step 1 and secure the BX wire by tightening the screw (L) of the connector (I). Page 20 Product Specification Manual - Matrix 1900...
-
Page 21: Changing The Side Of The Blower Power Cord
Remove the four screws (F) that hold the connection box (G) to the insert and gently pull it out until the white and black wires come out of the insert. Keep the screws. Product Specification Manual - Matrix 1900 Page 21... - Page 22 Then pass the wires through the grommet (J) located on the side at the front of the device. 5. Screw the connection box (G) with the four screws (F) kept in step 2. Page 22 Product Specification Manual - Matrix 1900...
- Page 23 (extension supplied with the manual kit). 8. Secure the excess wires using the three plastic grommets (C) removed in step 1. 9. Reinstall the grille (B) with the screws (A) kept in step 1. Product Specification Manual - Matrix 1900 Page 23...
-
Page 24: Blower Removal
(B) to be able to remove it. DÉSINSTALLATION VENTILATEUR PT.1 3. Unscrew the two wing nuts (C) on each 4. Take out the fan (D). side of the fan. Page 24 Product Specification Manual - Matrix 1900... -
Page 25: Removable Air Control Handle
This insert comes with a removable handle for the primary air control. A holder for the handle is supplied with the manual. Here is an example of the holder installation. CAUTION: Do not leave the handle on the air control after use, as it will get very hot. Product Specification Manual - Matrix 1900 Page 25... -
Page 26: Faceplate Removal
It is not necessary to keep the screws (A), since they were only useful for the transport of the insert. COMMENT ENLEVER LA FAÇADE (LE PRODUIT ARRIVE AVEC LA FAÇADE INSTALLÉES) 3/8" Page 26 Product Specification Manual - Matrix 1900... -
Page 27: Faceplate Decorative Panel Installation/Removal
SI LE CLIENT VEUT INSTALLER SONT PRODUIT AVEC L'ENTONNOIR DETAIL I IL FAUT QU'IL INSTALLE LE RESTANT DES VIS (6X) Faceplate decorative panel installation • Screw the panel with 6 additional screws (B). Product Specification Manual - Matrix 1900 Page 27... -
Page 28: Door Overlay Installation
Position the overlay (A) on the door frame and secure using the bolts (B). To facilitate the installation, do not tighten the nuts until they are all installed. Note: It is not necessary to remove the glass or any other component to install the overlay.. Page 28 Product Specification Manual - Matrix 1900... -
Page 29: Optional Fresh Air Intake Kit Installation
(J) using the other pipe clamp. The outside wall termination must be installed outside of the home. The pipe must be HVAC type, insulated, and must comply with ULC S110 and/or UL 181, Class 0 or Class 1. Product Specification Manual - Matrix 1900 Page 29... -
Page 30: Optional Fire Screen Installation
In the United States or in provinces with a particulate emissions limit (e.g.: US EPA), the use of open-door wood stoves with a rigid firescreen is prohibited. Open the door. Hold the fire screen by the two handles and bring it close to the door opening. Page 30 Product Specification Manual - Matrix 1900... -
Page 31: Air Tubes And Baffle Installation
Starting with the rear tube, lean and insert the right end of the secondary air tube into the rear right channel hole. Then lift and insert the left end of the tube into the rear left channel. Product Specification Manual - Matrix 1900 Page 31... - Page 32 To remove the tubes use the above steps in reverse order. Note that secondary air tubes (A) can be replaced without removing the baffle board (B) and that all tubes are identical. Page 32 Product Specification Manual - Matrix 1900...
- Page 33 Product Specification Manual - Matrix 1900 Page 33...
-
Page 34: Removal Instructions
• Remove faceplate (D) by lifting it and then pulling on it. • Remove the three screws securing the pipe connector (A). • Unscrew the bolts securing the insert to the floor on each side of the unit (B). Page 34 Product Specification Manual - Matrix 1900... -
Page 35: Exploded Diagram And Parts List
3.14 Exploded Diagram and Parts List Product Specification Manual - Matrix 1900 Page 35... - Page 36 ARCHED GLASS WITH GASKET 19 1/8'' X 9 1/4'' AC06400 3/4" X 6' FLAT BLACK SELF-ADHESIVE GLASS GASKET SE24371 MATRIX 1900 CAST IRON DOOR ASSEMBLY AC06500 SILICONE AND 5/8" X 8' BLACK DOOR GASKET KIT 30101 SPRING TENSION PIN 5/32"Ø X 1 1/2"L...
- Page 37 HANDLE 30898 REPLACEMENT KIT 30337 SQUARE HEAD SET SCREW 1/2-13 X 1-3/4" SE24372 MATRIX 1900 FACEPLATE ASSEMBLY PL74839 GRILL SE46278 MATRIX 1900(OB01900) MANUAL KIT AC05959 METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL Product Specification Manual - Matrix 1900 Page 37...
-
Page 38: Osburn Limited Lifetime Warranty
Labour cost and repair work to the account of the manufacturer are based on a predetermined rate schedule and must not exceed the wholesale price of the replacement part. Shall your unit or a components be defective, contact immediately your OSBURN dealer. To accelerate processing of your warranty claim, make sure to have on hand the following information when calling: •... - Page 40 Resale is strictly prohibited. The manufacturer may update St-Augustin-de-Desmaures (Québec) Canada this document from time to time and cannot be responsible G3A 2H3 for problems, injuries, or damages arising out of the use 418-908-8002 of information contained in any document obtained from https://www.osburn-mfg.com/en/ unauthorized sources. tech@sbi-international.com...
