Mischa Buffet
Assembly Instructions
9
NOTE: If the doors are uneven or
there is a gap in the middle, loosen
or tighten the screw on the door
hinge until they are sitting flush.
3
11
Attach door hinges on panels [3] and [4] to the unit using 16x timber screws
(U). Tighten with a screwdriver. Ensure the doors open and close easily.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
12
A3
U
4
U
A3
A3
U
10
5
A4
3
Insert 8x shelf plugs (A4) into the unit at the desired height for the
shelves and rest the shelf panels [13] onto them. Ensure the shelves
are balanced and stable.
4
A4
6
13
13
6
