- Page 1 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Installation Instructions / Warranty 4-Hole Roman Tub Trim Carlton 17454XX1 Terrano 37447XX1 Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890...
-
Page 2: Installation Considerations
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Carlton 17454XX1 Terrano 37447XX1 Installation Considerations This trim kit must be used with rough-in • 13444-18. The handshower must be used. • Backflow protection is provided by a check valve in the handshower connection hose. Additionally, the diverter will automatically spring back to the "spout"... -
Page 3: Replacement Parts
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Replacement Parts cold handle 17291XXX hot handle 17292XXX escutcheon 94052XXX handshower holder 92380XXX handle escutcheon 94035XXX diverter 94037000 aerator 13485XXX gold aerator 94981990 hose 94148000 check valve 10 screen washer 11 diverter knob 94086XXX 12 spout 96164XXX 13 handshower 17850XXX... -
Page 4: Installation
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Installation • Remove the plastic plaster shields from the valves and the spout tee. Remove the white plastic handle snap • connectors. Turn the valve stems clockwise to make sure that they are "off" (1, 2). Carlton only - install the handle •... - Page 5 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Lightly lubricate the o-rings on the diverter • with the enclosed lubricant. Push the diverter firmly straight down into the spout tee. Terrano only - install the spout • escutcheon(1) Push the spout over the diverter. Tighten •...
- Page 6 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Pull the outer Secuflex hose completely • from the handshower mount. Unscrew the outer Secuflex hose (1) from the handshower connector hose and remove the brass plug (2) Do not allow the handshower connector hose to fall back through the hole! Install the check valve (3) to the •...
- Page 7 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Remove the end cap and the liner from • the handshower holder. • Compress the outer hose until you can grasp the end of the inner hose • Feed the inner hose through the handshower holder (1), liner (2), and end cap (3).
- Page 8 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Use a knife to cut the o-rings at the end of • the outer hose. • Feed the hoses back through the handshower mount . Place the handshower holder onto the • handshower mount so that the pin on the mount engages the corresponding hole on the handshower holder.
-
Page 9: Troubleshooting
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 User Instructions • Turn the right handle for cold water, the left handle for hot. To divert the water to the handshower, pull up on the diverter knob. When the water is • turned off, the diverter will automatically reset to the spout position. •... -
Page 10: Limited Lifetime Consumer Warranty
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Cleaning Recommendation for Hansgrohe Products Modern faucetry and shower products utilize a combination of materials to comply with the needs of the market with regard to design and functionality. To avoid damage, it is necessary to use some caution when cleaning. Damage caused by improper treatment is not covered under the Hansgrohe warranty. - Page 11 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR: Conditions, malfunctions or damage not resulting from defects in material or workmanship. Conditions, malfunctions or damage resulting from (1) improper installation, improper maintenance, misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or caustic cleaning agents or “no rinse”...
- Page 12 Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Hansgrohe, Inc. 1490 Bluegrass Lakes Parkway Alpharetta, GA 30004 • • Tel. 770 360-9880 Fax 770 360 9887 • www.hansgrohe-USA.com Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890...
