Carbide 3D BitRunner V2 Quick Start Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
The Carbide 3D BitRunner V2 automates your router's on/off functionality in Carbide Motion. No more
reaching into the work envelope with a moving end mill. Now you can power down your router with the
touch of a button—allowing you to perform tool changes quickly and safely. Use the BitRunner V2 in
conjunction with the BitSetter and BitZero to automate your cutting process even more.
BitRunner V2 comes in deluxe and standard versions. While both versions have the same functionality, the
deluxe version comes with an EMI filter not included in the standard.
Shapeoko Pro, Shapeoko 4, and Shapeoko 3 models that shipped with the Z-Plus as standard equipment are
ready for BitRunner V2 right out of the box. Users with Shapeoko 3 models with Carbide Motion boards 2.3
and earlier (machines purchased before Black Friday 2019) will need to have purchased a new "Carbide
Motion PCB – with Enclosure" at checkout. See
We're here to help! If you encounter any issues while setting up or using your BitRunner V2, please contact
the Carbide 3D support team at: support@carbide3d.com.
Important Software Information
You must run Carbide Motion 4 or later with the BitRunner V2. Download the most recent version of Carbide
Motion from: carbide3d.com/carbidemotion/download/.
Do Not Connect to Ethernet-Enabled Devices
While an Ethernet cable is used to connect the control pendant to the BitRunner V2, the BitRunner V2 is NOT
an Ethernet device.
WARNING: Do not attempt to connect the BitRunner V2 or control pendant to any Ethernet-enabled
devices such as a modem or internet router.
BitRunner V2 Quick-Start Guide
support@carbide3d.com
Install a New Carbide Motion Board (v2.3 or
docs.carbide3d.com
earlier).
08/19/2021
v1.0
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the BitRunner V2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Carbide 3D BitRunner V2

Summary of Contents for Carbide 3D BitRunner V2

  • Page 1 Motion from: carbide3d.com/carbidemotion/download/. Do Not Connect to Ethernet-Enabled Devices While an Ethernet cable is used to connect the control pendant to the BitRunner V2, the BitRunner V2 is NOT an Ethernet device. WARNING: Do not attempt to connect the BitRunner V2 or control pendant to any Ethernet-enabled devices such as a modem or internet router.
  • Page 2 BitRunner V2 enclosure and attached power cords Control Pendant Enable/disable the BitRunner V2 Logic Cable Connects the BitRunner V2 to the controller Ethernet Cable Connects the BitRunner V2 to the control pendant Grounding Cable Attaches to spindle mount to ground the spindle support@carbide3d.com docs.carbide3d.com 08/19/2021...
  • Page 3 If you have an older Carbide Motion board (2.3 or earlier), you should have purchased a new Carbide Motion PCB and enclosure with your BitRunner V2. Before setting up the BitRunner V2, you will need to install the new controller: 1.
  • Page 4 1.3.1 Connect the Male End to the BitRunner V2 1. Plug the male end of the logic cable into the 6-pin female port on the top of the BitRunner V2. See Figure 2. a. The black plastic latch on the side of the connector faces RIGHT.
  • Page 5 However, if the cable is plugged in incorrectly, the BitRunner V2 will not operate. 1. Plug the cable’s female end into the 6-pin male BitRunner V2 connector protruding from the front- end of the controller. See Figure 3.
  • Page 6 1.4 Connect the BitRunner V2 to the Control Pendant Use the flat black Ethernet cable to connect the BitRunner V2 to the control pendant. The two ends of the cable are interchangeable. See Figure 4. 1. Plug one end of the Ethernet cable into the Ethernet jack on the control pendant.
  • Page 7 2. Plug the other end of the Ethernet cable into the jack on the top of the BitRunner V2. See Figure 5. a. The clear latch and black strain-relief boot face LEFT. b. Press firmly to fully seat the connector. You will hear the latch click into place.
  • Page 8 (EMI). We especially recommend grounding the spindle during the winter, or in very dry or EMI-noise-heavy environments. To attach the grounding cable: 1. Insert the banana plug into the round port on the top of the BitRunner V2. See Figure 6. Figure 6 support@carbide3d.com docs.carbide3d.com...
  • Page 9 Figure 7 1.7 Upgrade Carbide Motion The BitRunner V2 requires at least Carbide Motion 4. 1. Check for the build number in the bottom-left corner of Carbide Motion. Build numbers higher than 400 do not need to be upgraded.
  • Page 10 Using the BitRunner V2 2.1 Enable/Disable the BitRunner V2 The BitRunner V2 is enabled and disabled via the control pendant. To enable the BitRunner V2: 1. Press the control pendant button to supply power to the router. The red button LED will turn ON. See Figure 8.
  • Page 11 3. Load the G-code (.nc file) in Carbide Motion. The G-code (or absence thereof) determines when BitRunner V2 cuts or supplies power to the router. If there is no G-code/.nc file being executed in Carbide Motion, then no power is supplied to the router. The G-code also triggers alert boxes to open in Carbide Motion which let you know when it’s time to change the...
  • Page 12 5. Flip the power switch on the router to the ON position. 6. Press the control pendant button again to re-enable the BitRunner V2 (button LED will turn on). 7. In Carbide Motion, click the Resume button to resume cutting. Carbide Motion will continue cutting until it’s time to perform another tool change, load the next G-code file, or until the project is done.

  • Page 13: Troubleshooting And Maintenance

    Press the control pendant button BitRunner V2 is not enabled to enable the BitRunner V2. Ensure BitRunner V2 is plugged BitRunner V2 is not plugged into power. BitRunner V2 will into a power outlet. not turn on. Ensure all cables are correctly connected.

  • Page 14: Maintenance

    The fuse may have blown if you know the G-code is good and the control pendant LED still lights up, but the BitRunner V2 has stopped working. 1. Unplug the BitRunner V2 from the power source and unplug all cables on the top of the device. 2. Use a 2.5mm hex key to remove the four FHS securing the back panel.
  • Page 15 Pry from the left side of the fuse box, near the “B” embossed on the lid. Figure 11 NOTE: Figure 11 shows the deluxe BitRunner V2. The standard version will not have the large coils under the metal EMI shield.
  • Page 16 5. Use your finger or a small flathead screwdriver to carefully remove the fuse. See Figure 12. Figure 12 6. Insert a new 15A 250V 5×20mm fuse. 7. Replace the metal EMI shield. 8. Replace the back panel of the BitRunner V2. support@carbide3d.com docs.carbide3d.com 08/19/2021...
