Drive/Controls Assembly Parts List - Ingersoll-Rand IRN 15K Instructions Manual

Item Part No�� Qty
1 22168090 1 JUMPER, 2-POLE 1492-CJ6-2
GROMMET, INSULATION, 20-
23264146 2
25hp/15-18.5kW H.V.
GROMMET, INSULATION, 20-
2
25hp/15-18.5kW L.V.
GROMMET, INSULATION, 30-
23264112 2
40hp/22-30kW L.V.
2
GROMMET, INSULATION, 30-
2
40hp/22-30kW H.V.
GROMMET, INSULATION, 20-
54741608 2
25hp/15-18.5kW L.V.
GROMMET, INSULATION, 30-
23264138 2
40hp/22-30kW L.V.
GROMMET, INSULATION, 20-
23264120 1
25hp/15-18.5kW H.V.
GROMMET, INSULATION, 30-
3 23264138 2
40hp/22-30kW H.V.
GROMMET, INSULATION, 30-
54741608 1
40hp/22-30kW L.V.
4 23490295 1 RAIL
DRIVE W/EMC, 20-25hp/15-
22772842 1
18.5kW L.V.
DRIVE W/EMC, 20-25hp/15-
22812671 1
18.5kW H.V
DRIVE W/EMC, 30-40hp/22-
22772867 1
30kW L.V.
DRIVE W/EMC, 30-40hp/22-
22812689 1
30kW H.V.
5
DRIVE W/O EMC, 20-25hp/15-
23837495 1
18.5kW L.V.
DRIVE W/O EMC, 20-25hp/15-
23837529 1
18.5kW H.V
DRIVE W/O EMC, 30-40hp/22-
23837503 1
30kW L.V.
DRIVE W/O EMC, 30-40hp/22-
23837511 1
30kW H.V.
6 39252903 4 BLOCK, TERMINAL
80447543 Rev. B
RELEASED 31/Jan/2017 14:12:04 GMT

dRIVE/CONTROLS ASSEMBLY PARTS LIST

description Item Part No�� Qty
7 39252937 1
8 96702253 4
9 96704416 4
10 96740188 4
11 22480404 1
12 23453095 1
13 49067218 1
14 49154016 1
15 54403266 1
16 92368687 1
17 96701958 1
18 96737564 1
19 96747530 1
20 39875570 1
21 92490358 A/R TUBE,
22 22685317 1
23 22835631 1
24 22859938 1
23410798 1
25
22359764 1
26 92354539 1
27 96748496 4
28 22861629 1
22855548 1
29
22970578 1
A/R AS REQUIRED
description
STOP, DIN RAIL N37-75
SCREW
NUT
WASHER
CLAMP
BULKHEAD, FEMALE UNION
BRACKET, TRANSDUCER
MOUNTING
TRANSDUCER, PRESSURE 16
BAR, 4-20 mA, 1/8 NPT
ELBOW
SCREW
SCREW
NUT
ADAPTER, FEMALE
CABLE, TRANSDUCER
INTELLISYS SG
CONTROLLER, UNIGY DRIVE
ASSEMBLY, EMERGENCY STOP
PUSH BUTTON
CONNECTOR, DIVERTER
VALVE, BLOW DOWN 1/4' BSPT
NIPPLE
ELBOW
TUBE, BLOWDOWN VALVE/
INLET (20-45hp/15-33.5kW)
TUBE, BLOWDOWN VALVE/
MANIFOLD, 20-25hp/15-18.5kW
TUBE, BLOWDOWN VALVE/
MANIFOLD, 30-40hp/22-30kW
35
