Parameter Name
RTR
(only for firmware
version 1.8)
Note:
The frequency defined by CHAN parameter is not valid if Frequency Hoping mode is selected.
In the Frequency Hoping mode, the Frequency Pattern generator must generate the random numbers
smaller than the number of frequencies listed in the unit's frequency list.

3. Serial Interfacing Commands

3.1. DPORT

The DPORT is an object that responsible for data port interface configurations like Bit Rate, Flow
Control, etc.
DPORT [Parameter Name] [Parameters List] [/?]
Parameter Name
RATE
BITS
PARITY
FLOW
RS
DATATX
www.javad.com
Base Unit
0 - No Retransmission in the wireless cluster
1- There is Repeater
Remote Unit
0 - Auto Detect (Base or Repeater)
1 - Receive from Repeater
2 - Receive from Base
0 – Maintenance Port baud rate, a default setting
1 – 1200 baud
2 – 2400 baud
3 – 4800 baud
4 – 9600 baud
5 – 14400 baud
6 – 19200 baud
7 – 38400 baud
8 – 57600 baud
9 – 115200 baud, a default setting
Set number of bits in one byte (8 or 7)
8 is a default setting
0 – None, a default setting
1 – Odd
2 – Even
0 – None, a default setting
1 – Not used
2 – HW (RTS/CTS)
0 - RS232, a default setting
1 - RS485
2 - RS422
use save, boot commands to activate modification
0 - UART, a default setting
1 - USB
2 - BT
Parameter List
Parameter List
Command Line Interface
Serial Interfacing Commands
