Specifications
Connector Specifications
Receiver Specifications
This connector provides DB15 connectivity for the HPT204BT with DTE. About using and configuration
RS-485 please contact JAVAD GNSS support.
External Antenna RF Connector
The external antenna connector type is a BNC RF connector AEP Connectors p/n 6501-7051-003.
36
Table A-5. DB15 Connector Specifications
Number
Signal Name
1
DCD_OUT
2
DTR_OUT
3
RX+/CTS_IN
4
RX-/RX_IN
5
PWR_IN
6
USB_PWR
7
Ground
8
PWR_IN
9
DSR_IN
10
TX+/RTS_OUT O
11
TX-/TX_OUT
12
Ground
13
USB_D+
14
USB_D-
15
Ground
Dir
Details
O
Data Carrier Detect (RS-232)
O
Data Terminal Ready (RS-232)
I
Receive Data positive line (RS-422)/
Clear to Send (RS-232)
I
Receive Data negative line (RS-422)/
Receive Data (RS-232)
I
+9 to +36 VDC Power Input
I
Power Input line (USB)
-
Power Ground
I
+9 to +36 VDC Power Input
I
Data Set Ready (RS-232)
Transmit Data positive line (RS-422) /
Request to Send (RS-232)
O
Transmit Data negative line (RS-422) /
Transmit Data (RS-232)
-
Power Ground
I/O
Positive line (USB)
I/O
Negative line (USB)
-
Power Ground
www.javad.com
