Chapter 1 Getting Started

About G.SHDSL testing

All manuals and user guides at all-guides.com

The HST-3000's optional G.SHDSL testing feature enables

users to emulate an STU-R, STU-C, and Ethernet terminal

equipment (TE) to turn up and troubleshoot G.SHDSL circuits,

and the service over the circuit. Using the optional IP suite or

optional on-board web browser, the HST-3000 can also vali-

date a data connection over the network.

The capabilities of the G.SHDSL feature include the following:

– Both remote and central office (exchange) modem emula-

tion

– Ethernet TE emulation to verify service on the premises

LAN

– Various physical line and EOC standards

– User EOC messages

– Network layer and PPP emulation and authentication

– IP layer routing

– ATM loopback

– ATM F5 loopback

– ATM BERT capability

– IP ping

– Web browser

– "In-line" STU-R TE replacement "through" mode

– Supports 2-wire or 4-wire interface

HST-3000 G.SHDSL Testing User's Guide

Table of Contents

Do you have a question about the HST-3000 and is the answer not in the manual?

Page 1 (TE) to turn up and troubleshoot G.SHDSL circuits, and the service over the circuit. Using the optional IP suite or optional on-board web browser, the HST-3000 can also vali- date a data connection over the network. The capabilities of the G.SHDSL feature include the following: –...
Page 2 – Solid green indicates that a data connection has been established with the network (so that the HST-3000 may send and receive data on the network). – Solid red indicates that a data connection error.
Page 3 – Solid amber indicates the battery capacity indicator (“gas gauge”) needs to be reset. For information about replacing or charging the battery, see the HST-3000 Base Unit User’s Guide. HST-3000 G.SHDSL Testing User’s Guide...
Page 4 Connect TNV signals to TNV ports only. The connector uses pins 4 and 5 for 2-wire G.SHDSL and the first pair of 4-wire G.SHDSL. The second pair for 4-wire uses either 1 and 2 or 3 and 6. HST-3000 G.SHDSL Testing User’s Guide...
Page 5 HST test results. CAUTION: DAMAGE TO MODULE Placing the sealing current terminator on a line with voltage over 150 volts may damage the unit. HST-3000 G.SHDSL Testing User’s Guide...
