Viavi OneExpert DSL ONX-580 User Manual

Table of Contents

Quick Links

OneExpert DSL

User's Guide

Table of Contents

Summary of Contents for Viavi OneExpert DSL ONX-580

Page 1 OneExpert DSL User's Guide...
Page 2 Copyright/Trademarks © Copyright 2019 VIAVI Solutions Inc. All rights reserved. No part of this guide may be reproduced or transmitted, electronically or otherwise, without written permission of the publisher. VIAVI Solutions and the VIAVI logo are trademarks of VIAVI Solutions Inc. (“Viavi”).
Page 3: Federal Communications Commission (Fcc) Notice
– Consult the dealer or an experienced radio/TV technician for help. In order to maintain compliance with the limits of a Class A digital device VIAVI requires that quality interface cables be used when connecting to this equipment. Any changes or modifications not expressly approved by VIAVI could void the user’s authority to operate the...
Page 4 VIAVI has established a take-back processes in compliance with the EU Waste Electrical and Electronic Equipment (WEEE) Directive, 2012/19/EU, and the EU Battery Directive, 2006/66/EC. Instructions for returning waste equipment and batteries to VIAVI can be found in the WEEE section of VIAVI Standards and Policies web page.
Page 5: California Proposition
California and the state’s drinking water and environment from excessive exposure to chemicals known to the state to cause cancer, birth defects or other reproductive harm. For the VIAVI position statement on the use of Proposition 65 chemicals in VIAVI products, see the Hazardous Substance Control section of the VIAVI Standards and Policies web page.
Page 6 OneExpert DSL User's Guide 22052280, Rev. 015 April 2019...
Page 7 Contents About this Guide Purpose and scope ....................17 Assumptions ......................17 Technical Assistance ....................17 Safety and compliance information ..............18 Conventions ......................18 Typographical conventions................18 Keyboard and menu conventions .............. 19 Symbol conventions ..................19 Safety Definitions ..................20 Chapter 1 Introduction About the OneExpert DSL ..................22 Available mainframes ..................
Page 8 Contents Power button ....................34 Exploring the bottom panel ................35 Charge Indicator ..................... 35 Exploring the right side panel ................36 ONX-580 and ONX-580P connector panel ..........36 ONX-580A connector panel .................36 USB connectors ....................37 POTS connector ....................37 Network connectors ..................37 RJ45 Wiring connector .................
Page 9 Contents Enabling network connectivity ..............53 Establishing an Ethernet connection ............54 IPv4 Address Mode ................54 IPv6 Address Mode ................55 IPv4/IPv6 Dual Stack Address Modes ..........56 Establishing a WiFi connection ..............57 Adding a WiFi network profile ..............57 Connecting to a WiFi network ..............58 Establishing a Bluetooth connection ............59 Enabling Bluetooth connectivity ...............59 Connecting to a Bluetooth device .............59...
Page 10 Contents SmartAccess Anywhere – Remote Coaching ..........77 Chapter 4 xDSL / G.fast Testing About xDSL and G.fast testing ................. 80 Supporting test modules and software options ......... 80 What’s new? ......................81 Selecting the test mode ..................82 Specifying test settings ..................83 Loading a test profile ...................83 Saving a test profile ..................83 Deleting a test profile ..................83...
Page 11 Contents Upload Measurement ..............108 Download Measurement ..............108 Measurements Upload ..............109 Broadcom Speed Service data testing ............110 Before you begin ...................110 Managing Speed Service test profiles .............111 Server Settings ....................111 Running Broadcom Speed Service ............112 Average Latency Measurements ........... 113 Rate Measurements ................
Page 12 Contents Connecting to the line ..................134 Viewing results ....................134 Running a OneCheck Ethernet test ............... 135 OneCheck Ethernet Editor ................136 Testing the data layer ..................137 Chapter 7 Wiring Tools About the Wiring Tools ..................140 Wire Mapping ......................140 Mapping ......................140 Sending tones ....................
Page 13 Contents Chapter 11 Testing with SmartIDs About SmartID tests ...................164 Locating SmartIDs ....................164 Coax Map test .......................166 Whole-Home Check ....................169 Chapter 12 Testing Full Sweep Coax About the Full Sweep Coax Test ..............174 Locating SmartIDs ....................174 Coax Check ......................176 Chapter 13 Copper Testing About copper testing ..................180...
Page 14 Getting Started ....................238 Controlling the OneExpert from your Mobile Device ........238 Updating the iOS application software ............240 Connecting to StrataSync from the VIAVI Mobile Tech App ....241 Mobile Tech Main Menu ................242 OneExpert DSL User's Guide 22052280, Rev. 015...
Page 15 Contents Chapter 16 Test Results DSL/G.fast Results ..................... 246 Context Sensitive Help ................246 Summary .......................247 Packets ......................250 Network ......................251 Errors .......................252 Events ......................253 DSL RTX (retransmission) ................253 Signal .......................253 Identity ......................254 DSL Graphs ....................254 IP Data results .....................255 Ping Results ....................255 File Transfer results ..................256 TrueSpeed results ....................256...
Page 16 Contents Resistance ....................268 Distance to short ..................269 Leakage ......................269 Opens/Capacitance ..................270 DC current .....................270 Longitudinal balance ...................271 Load coil ......................271 TDR ......................... 272 RFL ........................272 Spectral ......................272 Noise ......................272 Impulse Noise ....................272 RX and TX Tones ..................272 WiFi Advisor results ...................
Page 17: About This Guide
Purpose and scope The purpose of this guide is to help you successfully use the OneExpert DSL features and capabilities. Additionally, this guide provides a complete description of the VIAVI warranty, services, and repair information. Assumptions This guide is intended for novice, intermediate, and experienced users who want to use the OneExpert DSL effectively and efficiently.
Page 18: Safety And Compliance Information
About the Guide Safety and compliance information Safety information is contained in a separate guide and is provided in printed format with the product. For information about CE compliance, see the Declaration of Conformity. A copy of the declaration is included in the shipping package. Conventions This guide uses typographical and symbols conventions as described in the following tables.
Page 19: Symbol Conventions
About the Guide Keyboard and menu conventions Description Example A plus sign + indicates Press Ctrl+s simultaneous keystrokes. A comma indicates consecutive key Press Alt+f,s strokes. A slanted bracket indicates On the menu bar, press Start > Program Files. choosing a submenu from menu. Symbol conventions This symbol indicates a note that includes important supplemental information or tips related to the main text.
Page 20: Safety Definitions
About the Guide Symbol conventions (continued) This symbol represents a risk associated with fiber optic lasers. It may be associated with either a DANGER, WARNING, CAUTION or ALERT message. See Safety Definitions below for more information. This symbol, located on the equipment, battery, or the packaging indicates that the equipment or battery must not be disposed of in a land-fill site or as municipal waste, and should be disposed of according to your national regulations.
Page 21 Introduction This chapter provides a general description of the OneExpert DSL. Topics discussed include the following: • "About the OneExpert DSL" on page 22 • "Features and capabilities" on page 26 • "What ships with the OneExpert DSL?" on page 28 •...
Page 22: About The Oneexpert Dsl
The combination of its multi-touch user interface and unique Viavi OneCheck automated tests provides field technicians with ease of use and more expertise when performing complex tasks. This equips technicians to fix problems the first time while improving access and home network quality.
Page 23 The ONX-580A supports DSL, services, and home network testing; copper testing is not supported. NOTE: For additional information about OneExpert DSL options and services, contact your local VIAVI representative or visit www.viavisolutions.com. Available test modules The table below lists the available OneExpert test modules and part numbers.
Page 24: Software Options
Chapter 1 Introduction Software options You can order software options to add functionality to the OneExpert DSL. Part Number Description Provides the ability to run the RFC 6349 ONX-TRUESPEED TCP throughput test (“TrueSpeed”) against a Virtual TrueSpeed server. Allows wireless connectivity to either connect/ communicate with mobile devices, to test with a ONX580-BLUETOOTH Smart ID Plus probe, communicate with WiFi Advisor...
Page 25: Additional Resources
Provides the DSL Helper option. If you received an option file from a VIAVI representative, copy it to USB, insert the USB in the instrument, copy the file to the internal file system, turn the power off, then turn the power back on.
Page 26: Features And Capabilities
Chapter 1 Introduction Features and capabilities Features and capabilities of the OneExpert DSL include the following: • A multi-touch user interface that is similar to those provided on smart devices • A mobile-connectivity iOS application that provides remote control, data enhancements, and technical support, including tutorials •...
Page 27 Chapter 1 Introduction • Full Sweep Coax testing, including: – Full Bandwidth 1.6 GHz SmartID testing • Copper testing (ONX-580 or ONX-580P platforms required) features: – Multimeter (AC volts, DC volts, Resistance) – TDR (including OneCheck™ TDR) – Crosstalk TDR for ONX-580P only –...
Page 28: What Ships With The Oneexpert Dsl
This section explains how to start using the OneExpert. When you unpack your instrument, do the following: • Inspect the OneExpert for damage. If the instrument is damaged, put it back in box and contact Viavi customer service (see "Technical Assistance" on page 17). •...
Page 29 Chapter 1 Introduction Attaching or removing a test module When shipped from the factory, the test module comes attached to the base unit. If another module is ordered later, or if you have more than one module, this section describes how to attach a different module to your base unit.
Page 30 Chapter 1 Introduction Attaching a test module 1. Position the module so that the connectors on the module line up with the connectors on the back of the base unit. If correctly positioned, the four screws also line up. 2. Gently push the module to mate the connectors. 3.
Page 31: Quick Tour
Quick Tour This chapter introduces the keypad, status indicators, connectors, and graphical user interface. Topics discussed include the following: • "Exploring the front panel" on page 32 • "Exploring the bottom panel" on page 35 • "Exploring the right side panel" on page 36 •...
Page 32: Exploring The Front Panel
Chapter 2 Quick Tour Exploring the front panel The controls and indicators on the front panel are used to operate the OneExpert DSL, set up tests, and view data. The following sections describe each of the controls and indicators on the front panel. Status indicators High-sensitivity...
Page 33: Status Indicators
Chapter 2 Quick Tour Status Indicators The controls and indicators on the front panel are used to operate the OneExpert DSL, set up tests, and view data detailed below. Sync – Reports the status of G.fast/xDSL modem synchronization. • Blinking green indicates that the modems are training. •...
Page 34: Touchscreen Display
Chapter 2 Quick Tour Touchscreen Display The touchscreen display operates similar to a smart phone or tablet, where you swipe to go to the next page or zoom in/out by pinching or opening your fingers. Softkeys Use the softkeys to select screen-specific options or to select pop-up menus associated with each key.
Page 35: Exploring The Bottom Panel
Chapter 2 Quick Tour Exploring the bottom panel The OneExpert DSL +12 VDC connector is located on the bottom end of the instrument. This connector is used to power the OneExpert DSL and to charge the lithium battery inside. Charge DC power indicator input...
Page 36 Chapter 2 Quick Tour Exploring the right side panel The connector panel, located on the right side of the instrument (under a rubber flap), provides the ports required to connect your OneExpert DSL to the line under test. When the connectors are not being used, close the rubber flap to keep out dust and rain.
Page 37: Usb Connectors
Chapter 2 Quick Tour USB connectors The USB connectors are used for connecting Smart IDs, exporting test results to a flash drive, or for performing firmware upgrades from a flash drive. POTS connector The POTS connector is used on the ONX-580 / ONX-580P modules for POTS testing. Network connectors Two Ethernet/Network ports are used to connect to Ethernet networks to allow testing (such as hub flash, port discovery, and ping), synchronize with StrataSync, upgrade...
Page 38: Rj11 Wiring Connector
To reduce the risk of fire, use only 26 AWG or larger telecommunications line cord between the DSL connector and the wall. NOTE: ELECTROSTATIC DISCHARGE IMMUNITY When using an Ethernet crossover cable, Viavi recommends using a shielded crossover cable for the best immunity to electrostatic discharge (ESD). Rings The D-rings on the corners of the instrument can be used to attach a carry strap.
Page 39 Chapter 2 Quick Tour Exploring the ONX-580 / ONX-580P top panel The upper area of the back panel of the ONX-580 / ONX-580P module houses the connectors for Copper or G.fast/xDSL testing. These connectors are not provided on the ONX-580A. The copper connectors are used for: •...
Page 40 Chapter 2 Quick Tour CAUTION: INSTRUMENT DAMAGE Connecting to circuits with voltage higher than 300V, compared to ground, may damage the internal components. Connect only to circuits with less than 300V. WARNING: ELECTRICAL SHOCK Electrical shock may result in serious injury or death. Use care when connecting to telecommunications circuits, to be sure that you do not come in contact with exposed conductors or power mains.
Page 41: Navigating The User Interface
Chapter 2 Quick Tour Navigating the user interface The user interface of the OneExpert is designed to be intuitive and easy to use. The LCD is a touchscreen that operates similar to a mobile device (such as an iPad or similar Android device), where you swipe to go to the next page or zoom in/out by pinching or opening your fingers.
Page 42: Selecting A Menu Option
Chapter 2 Quick Tour Battery status and time The area at the top of the screen provides the battery status (using a graphic of the battery charge remaining), indicates whether the adapter is plugged in (using a lightning bolt next to the battery), and displays the current time.
Page 43 Chapter 2 Quick Tour Home Screen Running Indicator Once you start running an application (e.g. MultiMeter), you can return to the home menu (by pressing the home icon in the upper-left corner of the application’s screen). The application will keep running and the icon on the home screen will be highlighted, showing that it’s active.
Page 44: Entering Data
Chapter 2 Quick Tour Entering data Some menu options may require you to enter text or numbers (for example, test settings or user information). The process is similar to data entry on a mobile device. 1. Press the desired item. A data entry box appears.
Page 45 Utilities This chapter describes utilities found in the System menu and the Tray menu. The utilities are used to set up your instrument, upgrade the software, specify user information, generate test reports, capture screenshots, and perform other tasks. Topics discussed include the following: •...
Page 46: Displaying The System Settings Menu
Chapter 3 Utilities Accessing system utilities System utilities are accessed using the System Settings or Tray menus on your instrument. Displaying the System Settings menu Using the items provided on the System Settings menu, you can turn on remote operation (via VNC Viewer), change screen and power settings, control the volume, view hardware and software versions, view options purchased with your meter, and complete USB software updates.
Page 47 Chapter 3 Utilities Displaying the Tray menu Using the icons provided on the Tray menu, you can specify settings required for network, WiFi, and Bluetooth® connectivity, control the volume on your instrument, and manage reports. You can also take screenshots of the user interface and review a PDF of this guide on your instrument.
Page 48: Setting Up Your Instrument
Chapter 3 Utilities Setting up your instrument As mentioned in the previous sections, you can set up your instrument in the System Settings and Tray menus. Configuring international settings The International Settings menu is used to select the language, local units of measurement, and other international settings.
Page 49: Setting The Date And Time
Chapter 3 Utilities Setting the date and time The OneExpert has an internal clock that you can set to provide accurate time stamps for test results. Go to the System Settings menu, then select Date and Time. The Date and Time Settings menu appears.
Page 50: Set The Backlight Timeout
Chapter 3 Utilities 3. If you enabled NTP, specify the following: • NTP Server Address type (IPv4 Address, IPv6 Address, DNS Name) • NTP Server (the address of the server where the instruments gets the time, e.g., 0.us.pool.ntp.org) The instrument indicates whether it is synchronized with the NTP server under Synchronization State.
Page 51: Setting The Volume
Chapter 3 Utilities Setting the volume You can control the volume of your instrument using the Volume icon on the Tray menu. 1. Display the Tray menu, and then press Volume. The volume scroll bar appears. 2. Either press the + / - buttons on the screen or swipe your finger across the bar to move the line on the bar, adjusting the volume.
Page 52: Restoring Factory Defaults
Chapter 3 Utilities Restoring factory defaults The following procedure describes how to reset the OneExpert to factory default settings. NOTE: Restoring factory defaults resets test application settings and system settings (such as brightness, contrast, and volume), and powers down the unit. 1.
Page 53: Establishing Network Connections
Chapter 3 Utilities Establishing network connections You can establish wired network and intranet connections, and wireless WiFi connections to your instrument to update the firmware, transfer files, synchronize to the StrataSync server, or control the instrument’s user interface remotely. Enabling network connectivity Before you establish a connection to an Ethernet or WiFi network, you must enable network connectivity on your instrument.
Page 54: Establishing An Ethernet Connection
Chapter 3 Utilities Establishing an Ethernet connection You must have an Ethernet LAN cable to establish an Ethernet connection to your instrument. The ONX supports simultaneous usage of System Network access and Data Test access on its two external Ethernet ports. To enable this feature, select <Reserve Ethernet Port 1 for Remote Access>...
Page 55 Chapter 3 Utilities Static IPv4 Address – Enter the instrument’s IP address (which will be used when accessing the provider network). IPv4 Netmask – Enter the netmask address to indicate whether the packets are to be routed to other networks or sub-networks. IPv4 Gateway –...
Page 56 Chapter 3 Utilities IPv4/IPv6 Dual Stack Address Modes Static – See the IPv4 Address Mode in this section. Stateless – See the IPv6 Address Mode in this section. 7. Display the Tray menu, and then press Network to establish the connection. The instrument establishes an Ethernet connection to the LAN.
Page 57: Establishing A Wifi Connection
Chapter 3 Utilities Establishing a WiFi connection The WiFi option allows you to establish a WiFi connection to a wireless network to 1) synchronize your instrument to the StrataSync server, 2) export reports, screenshots, or job tickets (using FTP), or 3) update the firmware on your instrument. NOTE: Most ONX models support both 2.4 GHz and 5 GHz WiFi.
Page 58: Connecting To A Wi-Fi Network
Chapter 3 Utilities Network Mode – IPv4, IPv6, or IPv4/IPv6 Dual Stack. Depending on the Network Mode, you have one or more additional settings to specify. For details, see those areas earlier in this section. 6. Return to the System Network menu. The network that you created a profile for is listed on the menu.
Page 59: Establishing A Bluetooth Connection
Chapter 3 Utilities Establishing a Bluetooth connection The Bluetooth® option allows communication with a paired mobile device or SmartID+. Enabling Bluetooth connectivity Before you establish a connection to Bluetooth device, you must enable Bluetooth connectivity on your instrument. 1. Go to the Tray menu. 2.
Page 60 2) a WiFi connection, or 3) a USB drive with a copy of the firmware. Download the firmware to a USB drive If you’re using a USB drive, you can download the firmware from: • The Viavi OneExpert DSL page at: http://www.viavisolutions.com/enus/products/ network-test-and-certification/copper-dsl-WiFi-and-broadband/oneexpert-dsl- modular-field-test-platform.
Page 61: Installing Software Options
Chapter 3 Utilities Installing software options The following procedures describe how to install software options on your instrument. Options can be installed from a USB stick onto which the options have been stored. The preferred method of option installation is via StrataSync, as shown in the next section. 1.
Page 62: Synchronizing To The Stratasync Server
To obtain the latest configuration settings, software options and updates, work orders, and ownership registration information, the OneExpert can synchronize with a VIAVI server via the internet. The synchronization also stores any user files saved on the unit to the StrataSync server.
Page 63 Chapter 3 Utilities 4. From the System menu, press the StrataSync icon. The StrataSync settings menu appears. 5. Specify the following settings: • System Settings StrataSync Account ID – Enter the account identification number. Only change this if necessary. • StrataSync Tech ID/ User ID –...
Page 64 Chapter 3 Utilities • Lastly, if any upgrades are available, the user will be informed of their availability and asked to verify their desire to receive the upgrade. When synchronization is complete, the Status will indicate “Sync Complete”. The unit may be disconnected from the server.
Page 65 Chapter 3 Utilities OneCheck Copper/DSL/Fiber/Ethernet Profile Editor The OneCheck profile editor streamlines all configuration requirements for Copper, DSL, Fiber, and Ethernet testing. The home screens for each of these testing areas are slightly different but the workflow is shared. 1. Press the OneCheck Editor icon on either OneCheck DSL, Copper, Fiber, or Ethernet menus of the Home screen.
Page 66: Generating Reports
OneExpert is connected to the Mobile Tech app. "Connecting to StrataSync from the VIAVI Mobile Tech App" on page 241. • New JSON and XML report formats – The following tests support the new VIAVI Common Data Model (CDM) format: – OneCheck (Copper, Fiber, DSL, Ethernet) –...
Page 67: Saving A Report
3. Specify the format (PDF, XML, HTML, or JSON). NOTE: VIAVI offers a proprietory XML schema definition file (XSD) available online (referenced in the XML report). 4. If you want to include custom fields in the report, enable, then specify values for the fields.
Page 68: Viewing A Report
Chapter 3 Utilities Viewing a report You can view saved reports on the LCD of your instrument. 1. Access the Tray menu and then press View Report. A View Report screen appears, showing all of the saved reports. 2. Select a report to view. The report appears on the screen. NOTE: If the View Report icon is disabled (gray), there are no reports saved on your instrument.
Page 69 Chapter 3 Utilities About custom report fields When you save a test report, you can select, and then specify values for up to five custom “customer” report fields, and five custom “technician” report fields. The values that you specify for the fields will be included in the generated XML, PDF, or HTML report output. NOTE: The custom fields will also be available for selection in associated StrataSync templates.
Page 70: Capturing A Screenshot
Chapter 3 Utilities To specify custom report fields 1. Either press the Save Report button or access the Tray menu and then press Save Report. The Save Report menu appears. 2. Do one of the following: • To select and specify values for custom customer fields, select Add Customer Report Fields.
Page 71 Chapter 3 Utilities Viewing your work orders The WorkFlow Manager icon (provided on the Tray menu) allows you to see all your current work orders. Tests specified within the work orders can be launched from here. Select a work order to view it, and then choose the test to run it.
Page 72: Managing Files
Chapter 3 Utilities Managing files The OneExpert file browser is used to open, rename, copy, or delete saved result files, screen shots, or other files stored on your instrument or on a USB flash drive that is connected to your instrument.
Page 73 Chapter 3 Utilities Copying and pasting files or folders 1. Go to the file browser. 2. Select the file or folder. 3. Press the File Options system key, and then do one of the following: • Select Copy, navigate to another folder or drive, press the File Options system key, and then select Paste.
Page 74: Remotely Operating The Instrument
Chapter 3 Utilities Viewing the User’s Guide on your instrument Using the instrument’s PDF viewer, you can view the User’s Guide on the instrument. The file must be on a USB stick or copied to the OneExpert. 1. Under the System menu, select File Browser. 2.
Page 75 2. Select Smart Access Anywhere and VNC. The Smart Access Anywhere menu appears. 3. Select Enable VNC Server and note the VNC password underneath: viavi- vnc. You will need it to connect via VNC Viewer. OneExpert DSL User's Guide April 2019...
Page 76: Using A Pc Keyboard
2. In the viewer’s server address field, enter the OneExpert’s IP address, and click OK. A password entry box appears. 3. Enter the VNC password you noted before, viavi-vnc (found in the Remote Operation menu) and then click OK. The OneExpert user interface appears in the VNC viewer, and works similarly to using the unit itself.
Page 77: Vnc Availability
The SmartAccess Anywhere client (PC, Android, or Apple) can connect to your device via local area connection or Internet connection. For client downloads and more information, see: https://www.viavisolutions.com/en-us/software-download/smart-accessanywhere-saa VIAVI provides links to Android and PC only. You can find the iOS version in the Apple App store. OneExpert DSL User's Guide April 2019...
Page 78 Chapter 3 Utilities OneExpert DSL User's Guide 22052280, Rev. 015 April 2019...
Page 79 xDSL / G.fast Testing This chapter provides task-based instructions for using the OneExpert DSL to gather DSL (VDSL, ADSL2+/2/1, and G.fast) statistics and verify connectivity. Topics discussed include the following: • "About xDSL and G.fast testing" on page 80 • "Selecting the test mode"...
Page 80 ONX580-GFAST software option. Sckipio G.fast testing requires the ONX580-GFASTSCKIPIO software option. NOTE: For additional information about OneExpert DSL options and services, contact your local Viavi representative or visit www.viavisolutions.com. OneExpert DSL User's Guide 22052280, Rev. 015...
Page 81: What's New
ITU-T standard. • OneCheck DSL – The OneCheck DSL test is a Viavi single-pair and bonded DSL test for ADSL, ADSL2+, VDSL and G.fast designed to automate troubleshooting and close-out testing during installation, repair and maintenance of DSL services, and easily provide a pass/ fail status.
Page 82: Selecting The Test Mode
Chapter 4 xDSL / G.fast Testing Selecting the test mode Before running any DSL or G.fast test, you must specify the test mode and test settings. Available test modes vary based on your instrument’s configuration and options. 1. From the main menu, select DSL / G.fast. The DSL / G.fast Menu appears.
Page 83: Specifying Test Settings
Chapter 4 xDSL / G.fast Testing Specifying test settings Before you begin testing, make sure the test settings on the OneExpert DSL match the settings of the line that you are testing. To access the setup screen, select Tests & Settings at the bottom or use the tray menu (swipe down from the top or press the Tray and then Modem Settings buttons).
Page 84 Chapter 4 xDSL / G.fast Testing Specifying DSL / G.fast settings After selecting the test mode, if you have not loaded a previously defined test profile, you must specify DSL, and if applicable, G.fast settings to match the settings of the line that you are testing.
Page 85 Chapter 4 xDSL / G.fast Testing NOTE: Vectoring is only available for VDSL circuits. Vectoring technology is used on VDSL2 connections to reduce FEXT from other pairs in a binder group resulting in higher downstream and upstream rates for all the pairs in the group. Vector Friendly mode is suggested when there is a need to emulate CPE that is incapable of full vectoring, but has been designed to synchronize to a vectoring DSLAM without losing...
Page 86 Chapter 4 xDSL / G.fast Testing NOTE: Enabling DSL retransmission (adding the check mark) only advertises support to the DSLAM. It does not guarantee the connection will use DSL Retransmission (G.INP) because G.INP is specified in the CO configuration. DSL retransmission is required for G.fast testing; therefore, if G.fast is selected as the xDSL technology, retransmission is automatically enabled and cannot be configured.
Page 87 Chapter 4 xDSL / G.fast Testing Nothing to specify. Your instrument will use the Dominant Band – attenuation values from a single band in each direction to calculate signal and line attenuation values Weighted Average Specify Include Unused Bands – This setting only impacts LATN calculations: •...
Page 88 Chapter 4 xDSL / G.fast Testing IPoE Data Mode If you specified IPoE as Data Mode: 1. Select whether to do Automatic Login. 2. Select MAC Address Mode and specify Factory Default or User Defined. If you select User Defined, specify the MAC Address to be used during the test. 3.
Page 89 Chapter 4 xDSL / G.fast Testing • Username • Password • Use Provider • Use Service Name 5. Specify the network settings as described in step 6 of Establishing an Ethernet connection on page Multi Interface Data Mode If you checked Multi Interface as Data Mode, this option permits you to set Interface Count (the number of interfaces).
Page 90 Chapter 4 xDSL / G.fast Testing IPoA Data Mode If you specified IPoA as Data Mode, do the following: 1. Select whether to do Automatic Login. 2. Select IP mode and then specify the network mode: IPv4, IPv6, or IPv4/IPv6 Dual Stack.
Page 91: Connecting To The Line
Chapter 4 xDSL / G.fast Testing Connecting to the line The method used to connect to the line varies depending on the test mode and line configuration. Connecting to a single twisted pair 1. Using the RJ-45 to telco clips cable, connect the RJ-45 to bed of nails test lead to the DSL connector on the right panel of the OneExpert DSL.
Page 92: Connecting To Bonded Pairs At The Nid/Demarc
Chapter 4 xDSL / G.fast Testing Connecting to bonded pairs at the NID/demarc 1. Using the RJ-45 “Y” cable, connect the single end of the “Y” test cable to the jack on the side of the OneExpert DSL. 2. Connect the blue end of the cable to Modem 1 and the orange end of the cable to Modem 2 on the NID/demarc.
Page 93: Terminating The Loop (Selt)
5. The far-end technician can continue testing. Running a OneCheck DSL test The OneCheck DSL test is a VIAVI out-of-service single or bonded pair closeout test. It automatically performs a series of DSL measurements, and compares results to user-defined threshold values and provides a pass, marginal, or fail indication.
Page 94 Chapter 4 xDSL / G.fast Testing 3. The test starts running and opens the test summary screen. The test will run for the duration you have configured for it, and then display the results with pass or fail marks. Note: To run the Ookla Speedtest, you need to accept the Terms of Use.
Page 95 Chapter 4 xDSL / G.fast Testing OneCheck DSL Editor To customize a OneCheck DSL profile, select the OneCheck DSL Editor icon. 1. Press the OneCheck DSL Editor icon on the home screen. The Editor screen will open, offering a list of available profiles. Select a profile to edit and change thresholds and the enabled tests (Ping, Speedtest, Broadcom Speed Service, etc).
Page 96: After Running The Test
Chapter 4 xDSL / G.fast Testing NOTE: To save the profile to a USB, have it inserted in the unit and then save the profile. The application will save it to both the unit and USB. Testing the data layer Using the data layer tests, you can test for connectivity and throughput.
Page 97: Data Testing
Data Testing This chapter provides task-based instructions for using the Data testing features of the OneExpert DSL. The data layer tests allow you to test for connectivity and throughput. These tests can be performed on DSL or Ethernet circuits. Topics discussed include the following: •...
Page 98: Ping And Traceroute Testing
Chapter 5 Data Testing About Data Tests The Data Tests are available using the Tests & Settings button when testing Ethernet or DSL circuits. Ping and Traceroute testing The Ping test sends a ping packet through the modem to an IP address or DNS name (could be a network switch or web address) to test for connectivity.
Page 99 Chapter 5 Data Testing 6. Use the Tray menu to save the results. See Saving a report on page The Ping or Traceroute test is complete. Testing FTP throughput Using the FTP test, you can perform a file transfer to test the throughput of the circuit. 1.
Page 100 Chapter 5 Data Testing 5. Select Server Settings and then specify the settings. • Specify the Destination Type (IPv4 address or DNS name). • Enter the server address. • Enter the server password. • If a fallback server is desired, check the box to enable the server. Select the Back button to return to the TrueSpeed test screen.
Page 101 Chapter 5 Data Testing Managing TrueSpeed test profiles When you enter the test, you can select an existing profile or create a new one, as described above. Additional profiles can be added, existing profiles can be edited, and profiles can be deleted. 1.
Page 102 The server needs to be placed in the network in a way that will allow it to deliver very high data rate traffic to the ONX for downstream and upstream throughput testing. Viavi recommends the Apache HTTP server (v 2.4) that is readily available from Apache and supports multiple operating systems.
Page 103 Chapter 5 Data Testing 1. Once the server configuration is complete, the IP address of the server and filename of the throughput file must be configured in the ONX meter. Speed Check configuration is accessible from within the Speed Check screen. Press the Speed Check icon to enter Speed Check or use the arrows to highlight and select it, as shown here.
Page 104 Chapter 5 Data Testing 4. When finished editing the configuration, press the Back icon or Back button to return to the main Speed Check screen. 5. The test can now be performed with the desired configuration, as shown here. OneExpert DSL User's Guide 22052280, Rev.
Page 105 Chapter 5 Data Testing Server scaling When configured as recommended above, one server can support multiple simultaneous ONX Speed Check tests. The scaling of this server should be based on two aspects: 1. First, the network connection to the server must be capable of supplying data rates necessary to support the number of concurrent tests.
Page 106: Before You Begin
Chapter 5 Data Testing Speedtest by Ookla data testing Speedtest is used to test servers all over the world. It determines the server name and checks downstream and upstream throughput via Ethernet or xDSL/G.fast test interfaces. Its download/upload rate is up to 1 Gbps for Ethernet TE. Speedtest uses any IP interface, including IPv4, that you established for testing.
Page 107: Server Settings
Chapter 5 Data Testing Server Settings The Server Settings screen for Speedtest provides the selection of either automatic or user- specified server for the test. • Select the Auto Server checkbox for the automatic server. The ONX will connect to a default Ookla server in the network, which will select the nearest Speedtest server, and use it for the remainder of the test.
Page 108: Latency Measurement
Chapter 5 Data Testing Running Speedtest Press the Start button on the Speedtest screen. As the test progresses, its current state is displayed. A green progress bar is presented when the state takes more than four seconds. An activity spinner indicates that the test is still running. Latency Measurement The ONX will ping the Speedtest server the number of times specified in the Speedtest configuration.
Page 109 Chapter 5 Data Testing Measurements Upload The following final result values are again provided: • Latency, upload, and download rates • Total bytes uploaded • Upload stage duration • Total bytes downloaded • Download stage duration An HTTP connection then opens to the URL: http://www.speedtest.net/api/ embed/api. php, and the measurements are uploaded.
Page 110 Chapter 5 Data Testing Broadcom Speed Service data testing Like Ookla, Broadcom Speed Service is used to test the connection speed to your Broadcom Speed Service server. It checks UDP downstream and upstream throughput via Ethernet or xDSL/G.fast test interfaces. Its download/upload rate is up to 1 Gbps for Ethernet TE and uses IPv4.
Page 111 Chapter 5 Data Testing Managing Speed Service test profiles When you enter the test, you can select an existing profile or create a new one. Additional profiles can be added, existing profiles can be edited, and profiles can be deleted. 1.
Page 112 Chapter 5 Data Testing Running Broadcom Speed Service Press the Start button on the Speed Service screen. As the test progresses, its current state is displayed. A green progress bar is presented when the state takes more than four seconds. An activity spinner indicates that the test is still running. As the test runs, the speedometer moves to indicate the measurement, and the dial turns dark blue as it measures the speed.
Page 113 Chapter 5 Data Testing Average Latency Measurements The application sends UDP packets to the Broadcom Speed Service server, providing the timestamp of transmission. The server will use this timestamp and the timestamp at which the packet was received to calculate the average latency. Rate Measurements The ONX opens a TCP connection to the provided server, through which control packets are exchanged.
Page 114 Option Description Part Number IP Video Allows testing of IP Video services ONX580-IPVIDEO NOTE: For additional information about OneExpert DSL options and services, contact your local Viavi representative or visit www.viavisolutions.com. OneExpert DSL User's Guide 22052280, Rev. 015 April 2019...
Page 115: Specifying Test Settings
Chapter 5 Data Testing Specifying test settings Before you begin testing, make sure the test settings on the OneExpert DSL match the settings of the line and network configuration you are testing. TIP: Test configurations can be stored for easy recall and use (see “Saving a report”...
Page 116 Chapter 5 Data Testing Additionally, RFC 2680 and RFC 3357 define enhanced analysis methods that are used to measure the quality of a media stream. There are two main statistics for this: Loss Period and Loss Distance. Leave Latency Pass – Enter the Pass threshold, in milliseconds. •...
Page 117: Specifying Stream Settings
Chapter 5 Data Testing Loss Distance – Enter the Loss Distance threshold, in number of packets. • This triggers when RTP losses cause a RTP LD Error.“Loss Distance” measures the difference in sequence numbers of two loss events, with a “loss event” being the loss of one or more packets in a row.
Page 118: Mapping Channels
Chapter 5 Data Testing Mapping channels The channel map is similar to the stream settings because you can specify stream names and addresses, but the channel map allows you to customize your channel list using a spreadsheet program, such as Excel. 1.
Page 119 Chapter 5 Data Testing rtsp-isma – An RTSP negotiated unicast stream using ISMA over UDP for transport. rtsp-isma-tcp – An RTSP negotiated unicast stream using ISMA over TCP for transport. Destination IP – The Destination IP of the stream. In the case of rtsp this will contain the complete RTSP URL.
Page 120: Connecting To The Line
Chapter 5 Data Testing Connecting to the line After specifying the test settings, you can connect to the line. The procedure is different depending on the access interface. • For Ethernet connections, connect as described in Connecting to the line on page 146.
Page 121 Specifying test settings • Connecting to the line • Placing and receiving calls NOTE: For additional information about OneExpert DSL options and services, contact your local Viavi representative or visit www.viavisolutions.com. OneExpert DSL User's Guide April 2019 22052280, Rev. 015...
Page 122 Chapter 5 Data Testing Accessing the VoIP application Select an interface (Ethernet TE, DSL, or G.fast), and then select VoIP. Specifying test settings Before you begin testing, make sure that the OneExpert DSL settings match the settings of the phone you are emulating. NOTE: You must specify the interface settings before specifying VoIP settings.
Page 123 Chapter 5 Data Testing Proxy Port – Only appears if Use Proxy is checked. Enter the port number of • the proxy server. • Username – Only appears if Use Proxy is checked. Enter the Proxy User name. • Password – Only appears if Use Proxy is checked. Enter the Proxy Password. •...
Page 124 Chapter 5 Data Testing Press the right arrow next to STUN to specify STUN settings. STUN (Simple Transversal of UDP [User Datagram Protocol] Through NATs [Network Address Translators]) allows VoIP calls across a NAT router. These settings should only be changed if necessary.
Page 125: Placing And Receiving Calls
Chapter 5 Data Testing SIP VLAN Priority – Select the SIP priority for VoIP signaling. • • RTP IP ToS – Real-time Transport Protocol (RTP) IP Type of Service. Select the RTP IP type of service for VoIP signaling. • RTP VLAN Priority –...
Page 126: Answering Calls Automatically
Chapter 5 Data Testing 6. Use the telephone receiver to hang up. The unit goes back on hook and ends the call. 7. To clear the call log, select the Action function key and then press Clear. VoIP results on page 297 to learn what your results mean.
Page 127: Browsing The Web
Chapter 5 Data Testing Browsing the web With the web browser feature, you can provide visual proof to customers that a circuit is correctly provisioned all the way to the Internet. The browser works over both DSL and Ethernet interfaces, allowing you to surf the web from the customer’s NID or demarcation point using only the OneExpert DSL.
Page 128: Adding Bookmarks
Chapter 5 Data Testing Adding bookmarks If there is a specific page that you would like to view or if you visit a site frequently, you can bookmark it. There are six bookmark slots available: one for your Home URL and five others.
Page 129: Ethernet Te Testing
Ethernet TE Testing This chapter provides task-based instructions for using the Ethernet TE testing features of the OneExpert DSL. Topics discussed include the following:: • "About Ethernet TE testing" on page 130 • "Specifying Ethernet settings" on page 130 • "Connecting to the line"...
Page 130: What's New
Chapter 6 Ethernet TE Testing About Ethernet TE testing In Ethernet TE mode, you can use the OneExpert DSL to emulate Ethernet terminal equipment by connecting to an Ethernet LAN or to the Ethernet port on the customer’s modem. After connecting to the circuit, you can then test for connectivity and throughput.
Page 131 Chapter 6 Ethernet TE Testing CAUTION: FAULTY RESULTS Any time the Network settings are changed, the network layer resets. If you change these settings during a test, you may cause errors in the test. Only change them before you begin a test.
Page 132 Chapter 6 Ethernet TE Testing • If you selected DHCP, you need to define: Use Vendor ID Use User Class Use ClientID Use Arp announce 6. Specify the network settings as described in step 6 of Establishing an Ethernet connection on page You are finished specifying Ethernet settings.
Page 133: Saving Test Profiles
Chapter 6 Ethernet TE Testing 3. Each interface can be enabled for VLAN. If you disable VLAN, you will proceed to IP Mode as the next step. If you enable VLAN, then you need to specify: • VLAN ID • VLAN Priority 4.
Page 134: Viewing Results
Chapter 6 Ethernet TE Testing Connecting to the line After specifying the test settings, you can connect to the line. The ONX supports simultaneous usage of System Network access and Data Test access on its two external Ethernet ports. To enable this feature, select <Reserve Ethernet Port 1 for Remote Access>...
Page 135 Chapter 6 Ethernet TE Testing Running a OneCheck Ethernet test The OneCheck Ethernet test automatically performs a series of Ethernet measurements, and compares results to user-defined threshold values and provides a pass, marginal, or fail indication. 1. Connect your instrument to the line under test. 2.
Page 136 Chapter 6 Ethernet TE Testing OneCheck Ethernet Editor To customize a OneCheck Ethernet profile, access the OneCheck Ethernet Editor. The future software upgrades will not affect your earlier customization unless you select Restore the Defaults. 1. Do one of the following: •...
Page 137 Chapter 6 Ethernet TE Testing NOTE: To save the profile to a USB, have it inserted in the unit and then save the profile. The application will save it both to the unit and to the USB. Testing the data layer Using the data layer tests, you can test for connectivity and throughput.
Page 138 Chapter 6 Ethernet TE Testing OneExpert DSL User's Guide 22052280, Rev. 015 April 2019...
Page 139: Wiring Tools
Wiring Tools This chapter provides task-based instructions for gathering test statistics and verifying connectivity. Topics discussed include the following: : • "About the Wiring Tools" on page 140 • "Wire Mapping" on page 140 • "Hub Flash" on page 142 •...
Page 140: About The Wiring Tools
Chapter 7 Wiring Tools About the Wiring Tools The purpose of the Wiring Tools tests are to test and map CAT3 (POTS) and CAT 5/6 (Ethernet) cables/wires. From the main menu, select Wiring Tools. Wire Mapping These tests are used to test and map cables/wires. These tests require the use of the smart remote on the far end of the cable.
Page 141 16.0 52.5 18AWG, Unjacketed 17.0 55.5 4. For greatest accuracy, Viavi recommends that you perform a wiring compensation to remove the effects of the test leads. • Swipe down on the screen to view the tray menu • Select Wiring Compensation.
Page 142: Sending Tones
Chapter 7 Wiring Tools Sending tones The purpose of this test is to send a tone on a network cable. By default, the OneExpert DSL sends tone on all the wires of a cable. 1. Do one of the following: •...
Page 143: Port Discovery
Chapter 7 Wiring Tools Port discovery The port discovery feature determines the capability of the port and established connection speed. In case of mismatch ensure the proper pin out or usage of cat 5/6 pair. 1. Connect an Ethernet cable from the Residential Gateway port to an Ethernet on the side of the OneExpert DSL.
Page 144 Chapter 7 Wiring Tools OneExpert DSL User's Guide 22052280, Rev. 015 April 2019...
Page 145: Optical Tools
Optical Tools This chapter provides task-based instructions for using the optional USB accessories. Topics discussed include the following: : • "About the optical tools" on page 146 • "Inspecting fiber" on page 146 • "Measuring optical power" on page 148 OneExpert DSL User's Guide April 2019 22052280, Rev.
Page 146: About The Optical Tools
OneExpert. Inspecting fiber The optional VIAVI microscope accessory is used to view a live video of a simplex fiber to determine if the fiber is clean. It can also capture a snap-shot and provide pass/fail analysis.
Page 147 Chapter 8 Optical Tools video of the fiber. 4. To change the magnification level, press Low Magnify/ High Magnify. The current selection is a larger text size. 5. To select the inspection profile, press Profiles. If you have a custom profile, you can use it on the OneExpert by putting the file into the configs/Microscope folder.
Page 148: Measuring Optical Power
Measuring optical power The Optical Power Meter is a Viavi accessory used to measure optical power. • The MP-60 meter measures 850, 1300, 1310,1490, and 1550 nm wavelengths •...
Page 149: Wifi Testing
WiFi Testing This chapter provides task-based instructions for using the optional WiFi testing features. Topics discussed include the following: : • "About the WiFi tests" on page 150 • "Scanning for WiFi networks" on page 151 • "Running Receiver Diagnostics" on page 151 •...
Page 150 Chapter 9 WiFi Testing About the WiFi tests The WiFi testing features of the OneExpert include the following: • Quickly determine the available SSIDs, level and channel of WiFi networks visible from any location. The test set can attach to a customer's network and provide assessment of the signal strength throughout the premises.
Page 151: Scanning For Wifi Networks
Chapter 9 WiFi Testing Scanning for WiFi networks The WiFi Scan is used to determine whether any WiFi networks are available, and provides the SSIDs, level and channel of any networks detected. 1. From the WiFi menu, select WiFi Scan. The test searches for active WiFi networks. The WiFi search process may take a few minutes.
Page 152: Verifying Ip Connectivity
Chapter 9 WiFi Testing Verifying IP connectivity The WiFi Access Point is used to provide a network bridge to the receiver or residential gateway (RG) and allow wireless access to the network. This allows you to ping or surf the web to verify IP connectivity behind the RG in the customer premise.
Page 153 Chapter 9 WiFi Testing 6. On your device or laptop, open your WiFi settings and connect to the OneExpert's hotspot. It will appear in the list as the serial number on the side of the unit. Once connected, the SSID of the device and the number of clients connected to the WiFi will appear.
Page 154 Chapter 9 WiFi Testing WiFi Troubleshooting using WiFi Coverage Expert The WiFi Coverage Expert test includes the following: • Quick, visually intuitive assessment of networks and channels used on WiFi bands • Detailed insight of devices and other activity on a selected network to identify causes of reduced performance.
Page 155 Chapter 9 WiFi Testing Audible Finders The Audible Finders enable you to locate areas of strong audio signal for your transmitting devices and find the devices that create problems. 1. Access the audible finders via the SmartChannel devices page or Top Talkers page. You can only find the devices that are actively transmitting because otherwise you can’t hear them.
Page 156 Chapter 9 WiFi Testing Managing WiFi Advisor Devices This section describes the WFED Management menu which is used to register WiFi Advisor devices, view device status, and manage firmware updates. Registering and unregistering devices After pairing the device(s) with the OneExpert, the device must be registered in the OneExpert’s WiFi Advisor application.
Page 157 Chapter 9 WiFi Testing Changing the power off delay The power off delay values associated with each registered WiFi Advisor are shown within the Registered Devices section of the Device Management screen. These values define the amount of idle time that must transpire before the test device will automatically power down.
Page 158 Chapter 9 WiFi Testing OneExpert DSL User's Guide 22052280, Rev. 015 April 2019...
Page 159: Hpna Testing
HPNA Testing This chapter provides task-based instructions for using the optional HPNA testing features. Topics discussed include the following: • "About HPNA Testing" on page 160 • "Monitoring the HPNA network" on page 161 OneExpert DSL User's Guide April 2019 22052280, Rev.
Page 160: About Hpna Testing
Chapter 10 HPNA Testing About HPNA Testing If your OneExpert is optioned and configured to do so (and CPE support the HPNA protocol over an Ethernet port), you can use your instrument to verify that HPNA networks are operating within expected service quality metrics and users can set up pass/fail limits to help simplify testing.
Page 161: Monitoring The Hpna Network
Chapter 10 HPNA Testing Connecting to the line After specifying the test settings, you can connect to the line. 1. Connect one end of an Ethernet cable to the Ethernet jack on the right side of the unit. 2. Connect the other end of the cable to the Ethernet port of the CPE that is on the HPNA network (such as a set-top-box or residential gateway).
Page 162 Chapter 10 HPNA Testing 3. Select the Start softkey to select the type of test to run: • Quick – Used to quickly test the HPNA network for common issues (a small number of packets). • Chronic – Used to exhaustively test the HPNA network for chronic trouble (a large number of packets).
Page 163: Testing With Smartids
Testing with SmartIDs This chapter provides task-based instructions for gathering test statistics and verifying connectivity. Topics discussed include the following: • "About SmartID tests" on page 164 • "Locating SmartIDs" on page 164 • "Coax Map test" on page 166 •...
Page 164: Locating Smartids
Chapter 11 Testing with SmartIDs About SmartID tests The purpose of SmartID tests are to test and map cables/wires, verify that the HPNA links and devices are installed and fully provisioned, and to verify that the entire HPNA network is operating correctly From the Main menu, select SmartID.
Page 165 Chapter 11 Testing with SmartIDs • Plug in the SmartID or enter the serial number (if the SmartID is plugged in, it will advertise its serial number to the OneExpert). • Repeat these steps for each SmartID. The SmartIDs are registered. 2.
Page 166: Coax Map Test
Chapter 11 Testing with SmartIDs Coax Map test The purpose of this test is to map out the topology of a coax network, from a single point, without having to perform a two ended test using far end devices. This measurement can be used to locate devices in a coax cable such as barrels, splitter, and splices.
Page 167 Chapter 11 Testing with SmartIDs Splitter– Indicates a passive splitter may be present at this length in the cable under test. Low-Quality Splitter – Indicates a low-quality splitter may be present at this length. Low-quality splitters can induce standing waves and cause poor performance. These low-quality splitters can also cause conventional cable ID to function incorrectly since many are DC coupled, causing the ID resistive values to be placed in parallel.
Page 168: Troubleshooting Tip
Chapter 11 Testing with SmartIDs For any given coax cable, the coax map test locates each item and pres- ents the results in an easy to read table. The table indicates the location of items in terms of a length in feet, from the test instrument.
Page 169: Whole-Home Check
Chapter 11 Testing with SmartIDs Whole-Home Check SmartIDs allow the technician to connect the OneExpert directly to any single SmartID device which then communicates with any other connected SmartID devices in order to certify an in- home network and provide distances to found impairments, as shown here. If a diplexer is on the network, disconnect the VDSL connection.
Page 170 Chapter 11 Testing with SmartIDs NID without diplexer – The primary SmartID (connected to the SCH with a USB • cable) should be connected at the RG (in place of the RG), and the remaining SmartID probes should be connected at the receivers (in place of the receivers). NID with diplexer –...
Page 171 Chapter 11 Testing with SmartIDs The test summary displays the paths between SmartIDs and indicates whether the quality of the path between the two points is passing or failing based on pre-set limits. The upper right area shows how many SmartIDs were detected and now many were mapped;...
Page 172 Chapter 11 Testing with SmartIDs OneExpert DSL User's Guide 22052280, Rev. 015 April 2019...
Page 173 Testing Full Sweep Coax This chapter provides task-based instructions for gathering Full Sweep Coax test statistics and verifying connectivity. Topics discussed include the following: • "About the Full Sweep Coax Test" on page 174 • "Locating SmartIDs" on page 174 •...
Page 174 Chapter 12 Testing Full Sweep Coax About the Full Sweep Coax Test Full Sweep Coax test checks noise levels and downstream/upstream loss in a network. This test is similar to the Whole Home Check without diplexer, but covers the frequency range beyond the HPNA specification to test non-HPNA networks.
Page 175 Chapter 12 Testing Full Sweep Coax Press the Mode softkey to navigate between the Locate IDs and the Coax Check applications, as shown here. The Actions softkey allows the user to register new SmartID and SmartID Plus probes as well as update the firmware on any probe.
Page 176 Chapter 12 Testing Full Sweep Coax Coax Check Full Sweep Coax Check is similar to the Whole Home Check (No Diplexer) application we discussed in the previous chapter, with a few key differences. Firstly, the frequency sweep is conducted between 2 MHz and 1.6 GHz, unlike the Whole Home Check application that sweeps from 2MHz to 52MHz.
Page 177 Chapter 12 Testing Full Sweep Coax There are no pass/fail limits in the frequency sweep (RG-STB, STB-STB, and maximum delta limits between frequency bins of 4, 8 and 12MHz wide). Therefore, the Sweep Loss result card in the Test Summary page is white. However, Cable Faults and Ingress pass/marginal/fail limits have been preserved, similar to the Whole Home Check application.
Page 178 Chapter 12 Testing Full Sweep Coax The naming convention for splitters in the network has been updated in Coax Check. While an HPNA splitter is identified as HPNA-Splitter, similar to Whole Home Check, a non-HPNA splitter is identified as a more generic term, Splitter in Coax Check. Full Sweep Coax Check Whole Home Check Path Detail Page...
Page 179: Copper Testing
Copper Testing This chapter provides instructions for using the optional OneExpert DSL copper testing features. Topics discussed include the following: • "About copper testing" on page 180 • "Testing with an UltraFED far end device" on page 182 • "Measuring voltage" on page 184 •...
Page 180: About Copper Testing
Chapter 13 Copper Testing About copper testing NOTE: The copper testing is available on the ONX-580 and ONX-580P but not available on the ONX-580A. The copper features provided by the ONX-580 tester allow technicians to quickly turn up and perform basic troubleshooting of the copper local loop.
Page 181 • OneCheck Copper with UFEDIIB – Same as the first test, but we are also using the Viavi UltraFED to achieve two ended testing, which is required for tests like resistive balance, tone loss, etc. •...
Page 182 Using the UltraFED Control menu, you can control a far-end device (FED) to allow two-ended pair testing with a single piece of test equipment. After a technician connects a Viavi UltraFED to the far end of the pair under test, and connects your instrument to the near end, your instrument controls the FED using DTMF tones.
Page 183 Chapter 13 Copper Testing Quiet Term – Terminates the pair at the UltraFED. • Select Pair 1 or Pair 2. • Select the termination value. • Use the plus and minus sign to specify the duration. • Press Send to issue the command. Single Tone –...
Page 184: Measuring Voltage
Chapter 13 Copper Testing Measuring voltage The multimeter function allows measuring of AC and DC voltage. 1. Connect the Tip (A), Ring (B), and Ground (Earth) leads to the line under test. 2. From the Copper menu, select the Multimeter button. 3.
Page 185 DC and AC Volts are listed for each test (these values are available on the 580P instrument only). 4. For greatest accuracy, VIAVI recommends that you compensate the measurement to remove the effects of the test leads. To compensate the opens measurements: •...
Page 186 Chapter 13 Copper Testing Measuring the distance to a short The following procedure describes how to measure the distance to a short. NOTE: Use this feature only when the resistance is 4 kΩ or less (4 kΩ or less is almost always a hard short). If there is no hard short on Tip and Ring (A and B), the measurement will be inaccurate.
Page 187: Measuring Opens
The result can be used to determine if there are any bad splices. Resistive Balance requires the VIAVI UltraFED or a manual strap to ground at the far end. 1. Connect the Tip (A), Ring (B), and Ground (Earth) leads to the line under test.
Page 188 When using the three terminal method and no earth terminal is connected, you will get a non-zero result from each wire to earth. 5. For greatest accuracy, VIAVI recommends that you compensate the opens measurement to remove the effects of the test leads. To compensate the opens measurements: •...
Page 189 Chapter 13 Copper Testing 7. Do one of the following: • If you are on the Snapshot menu, select Refresh to restart the test. • If you are on the Continuous menu, select Clear to restart the test. 8. 8 To save the results to a report, use the Tray menu. 9.
Page 190: Measuring Current
Chapter 13 Copper Testing Measuring current Using the Multimeter, you can test for proper loop current for POTS lines. 1. Connect the Tip (A), Ring (B), and Ground (Earth) leads to the line under test. 2. From the Copper menu, press the Multimeter button.
Page 191: Locating Faults Using The Tdr
Chapter 13 Copper Testing Locating faults using the TDR The Time Domain Reflectometer (TDR) feature helps locate cable faults. The TDR identifies bridged taps, wet sections, load coils, shorts, opens, and splices on the span. 1. Connect the Tip (A), Ring (B), and Ground (Earth) leads to the line under test. 2.
Page 192 Chapter 13 Copper Testing 10. If you are testing toward a FED, use the Options menu, then select TDR Helper to continuously open and short the pair. On a TDR trace, you can then see the end of the copper pair by watching the open trace (slope up) and the short trace (slope down) that will flip flop for the amount of time you specify.
Page 193 Chapter 13 Copper Testing Running a OneCheck TDR test The OneCheck TDR test is a Viavi out-of-service pair quality test that examines a copper pair to determine how far out the TDR can see on the pair, identify anomalies (faults) and their approximate location, then graphically show the location of the identified anomalies.
Page 194 Chapter 13 Copper Testing Running a CrossTalk TDR test The CrossTalk TDR feature is available only on ONX-580P and is used to check interference between two pairs of wires. This test helps to check if there is any crosstalk between the two lines as a result of corrosion or other problems.
Page 195 Chapter 13 Copper Testing Measuring balance Balance is a number representing the quality of the telephone circuit and the degree to which the Tip (A) and Ring (B) conductors are electrically thesame in their ability to cancel noise. The balance measurement is used to identify poor loop quality or cable bonding and grounding issues that allow excessive loop noise.
Page 196: Detecting Load Coils
Chapter 13 Copper Testing Detecting load coils The OneExpert DSL can detect up to five load coils that may exist on the line, out to 27,000 (8,200 meters) feet. It will also report a short, open, or a high noise condition, if detected. For accurate load coil detection, test on a pair without voltage (supplied by a battery).
Page 197 Chapter 13 Copper Testing 4. Place a call. • Dial the number: – Use the keypad to dial manually. – Select Phone Book to select a saved number. • To use pulse dialing, press the Options system key and then select Pulse. •...
Page 198 1. Connect the Tip (A), Ring (B), and Ground (Earth) leads to the line under test. 2. From the Copper menu, press the RFL button. The RFL screen appears. 3. For greatest accuracy, Viavi recommends that you compensate the opens measurement to remove the effects of the test leads. To compensate the opens measurements: •...
Page 199 Chapter 13 Copper Testing Separate Pair RFL test The Separate Pair RFL (available on the ONX-580P only) works just like the Single Pair RFL except it uses an additional known good wire attached to the blue (A1) lead for improved accuracy. RFL K-Test The RFL K-Test is typically used to test for fault location when there is no “known good”...
Page 200 Chapter 13 Copper Testing The OneExpert DSL assumes that the fault is on the red lead. If the fault is not on the red lead, it will automatically flip Tip (A) and Ring (B) and run the test again. Thus, your screen may show swapped leads. 3.
Page 201 Impedance – wideband (ONX580P only) and narrowband; single frequency and sweep NOTE: For additional information about OneExpert DSL options and services, contact your local VIAVI representative or visit www.viavisolutions.com. From the Copper menu, select TIMS. The WB Noise menu appears (or the last test used).
Page 202 Chapter 13 Copper Testing Measuring noise The noise measurement is used to identify interferences that may interrupt signal transmission. 1. Connect the Tip and Ring (A and B) leads to the line under test. 2. Select Mode and then select Noise. The Noise Power menu appears. 3.
Page 203: Measuring Impulse Noise
Chapter 13 Copper Testing Measuring impulse noise Impulse noise is spurious voltage spikes that can disrupt digital transmissions. 1. Connect the Tip and Ring (A and B) leads to the line under test. 2. Press the Display softkey. 3. Select Mode and then select Impulse Noise. The Impulse Noise menu appears. 4.
Page 204 Chapter 13 Copper Testing Impulse noise capture Impulse capture works like an oscilloscope. It provides a graphic display of the signal. 1. Connect the Tip (A) and Ring (B) leads to the line under test. 2. Select Mode, and then select Impulse Noise Capture. The Wideband Impulse Noise Capture menu appears.
Page 205 Chapter 13 Copper Testing Receiving wideband and narrowband tones The OneExpert DSL can receive tones to measure wideband and narrowband loss. 1. Connect the Tip and Ring (A and B) leads to the line under test. 2. Select Mode, and then select RX Tones. The OneExpert DSL begins measuring the frequency and level of each tone.
Page 206 Chapter 13 Copper Testing Transmitting wideband and narrowband tones The OneExpert DSL can transmit tones to measure wideband and narrowband loss. This operation is carried out by two technicians. 1. Connect the Tip and Ring (A and B) leads to the line under test. 2.
Page 207 Chapter 13 Copper Testing 7. To change the display view press Options and then select Meter or List (listed by frequency). 8. To use an external bridge, press Options and then select the checkbox for Use External Bridge. 9. To save the results to a report, use the Tray menu. 10.
Page 208 Chapter 13 Copper Testing Wideband balance sweep testing This feature regulates how well a copper pair rejects noise. 1. Connect the Tip and Ring (A and B) leads of the ONX to the line under test. 2. Connect the ground (E) lead of the ONX to ground. 3.
Page 209 Chapter 13 Copper Testing Far-End Crosstalk (FEXT) testing The test detects coupling at the far end from one pair of wires to another. Using an UltraFED IIB, a tone is transmitted from the far end on one pair of wires, and the ONX measures crosstalk on another pair of wires at the near end.
Page 210 Chapter 13 Copper Testing Return loss sweep testing This test measures return loss caused by impedance mismatches over a range of frequencies. 1. Connect the Tip and Ring (A and B) leads of the ONX to the line under test. 2.
Page 211 Chapter 13 Copper Testing 6. To specify the termination, press Technology, and then select: • Wideband – 100 ohm, 120 ohm, 135 ohm • Narrowband – 600 ohm, 900 ohm 7. Press Frequency and enter a value or use the arrows. 8.
Page 212: Running A Onecheck Copper Test
Chapter 13 Copper Testing Running a OneCheck copper test The OneCheck Copper test is a Viavi out-of-service pair quality test. It automatically performs a series of enabled tests including: DVOM (AC/DC volts, resistance), Opens/Capacitance, Balance, and Load Coil. It also compares results to user-defined threshold values and provides a pass, marginal, or fail indication.
Page 213 Chapter 13 Copper Testing OneCheck Copper Editor This application provides access to all profile management tasks. 1. Press the OneCheck Copper Editor icon on the OneCheck Copper menu. The OneCheck Copper Editor screen will open, listing your test profiles. 2. To add new test profiles, press the New button and select one of the four options .
Page 214 Chapter 13 Copper Testing DVOM Press DVOM on the Editor configuration screen to open the Volts settings screen to edit thresholds. • Select a threshold (for example Loop Pair AC Voltage (V)) to open the thresholds editor. This editor is also accessible from the OneCheck Copper POTS application.
Page 215 • Press the Back arrow to return to the Editor configuration screen. Loss Tones This test mode measures tones for loss using Viavi UltraFED. • Press Loss Tones on the Editor configuration screen. On the next screen you can add and remove items or edit them by pressing each item and using the thresholds editor.
Page 216 Copper Expert, that runs consecutive testing sessions to check the quality of the copper line. It locates and identifies various problems, helping the user eliminate them in the process. Copper Expert is a software option. Check with your VIAVI representative for more information.
Page 217 Chapter 13 Copper Testing Copper Expert reports and provides Expert Advice for the following: • If there is a battery cross (this happens when DC voltage is more than 2.0 Volts) and which lead it’s • If there is a battery contact (when DC voltage is more than 2.0 Volts on tip and ring) •...
Page 218 Chapter 13 Copper Testing Pair Balance Copper Expert runs the following tests to check whether the copper pair is well balanced: capacitive balance, longitudinal balance, AC Voltage balance, resistance leakage balance and resistive leg balance (resistive leg balance requires the UFED). If Copper Expert concludes that one of the tested balances is not passable, it will try to identify the location of the problem so you can fix it before proceeding to the tests.
Page 219: Bonding And Grounding
Chapter 13 Copper Testing Bonding and Grounding Bonding is a term used to indicate that the cable shields are connected across the openings (where a cable is opened or ends, and where cabinets, splices, and enclosures are located). Grounding refers to the cable shield connection to ground at different sections of the cable.
Page 220 Chapter 13 Copper Testing OneCheck POTS Closeout This test offers a quick and easy way to check if a line is usable for POTS (5-point closeout). It is accessed via its own icon on the home page under the OneCheck Copper section. The OneCheck POTS Closeout is available to all ONX-580 products and does not require any option.
Page 221 Chapter 13 Copper Testing Test default configurations and thresholds DC Current • Pass: >= 23 mA • Fail: < 20 mA Narrowband Loss • Tone Number • Frequency List - 1004 Hz (+/- 2 Hz --> 1002 to 1006 Hz) - Pass: >= -9.0 dB - Fail: <...
Page 222 Chapter 13 Copper Testing OneCheck Coax This test consists of copper testing and SmartID testing. The test requires the SmartID accessory that is also used by the Full Sweep Coax test. 1. Press the OneCheck Coax icon. 2. On the next screen select the type of cable for the test. 3.
Page 223: Routing The Cables Through The Glove
Wind the ends of the cable and fit them into the zippered pocket on the inside of the front of the glove. 8. Close the front of the glove and then pull the strap from the back over the top and into the connector just above the Viavi logo. OneExpert DSL User's Guide April 2019...
Page 224 Chapter 13 Copper Testing OneExpert DSL User's Guide 22052280, Rev. 015 April 2019...
Page 225: Fiber Testing
Fiber Testing This chapter provides instructions for using the optional OneExpert Fiber testing features. Topics discussed include the following: • "About fiber testing" on page 226 • "OneCheck Fiber" on page 227 • "Running a OneCheck Fiber test" on page 228 •...
Page 226 Chapter 14 Fiber Testing About fiber testing NOTE: Fiber testing is available on the ONX-580 and ONX-580P, but not the ONX-580A. The fiber optic features provided by the ONX-580 tester allow technicians to quickly turn up and perform basic troubleshooting of the fiber local loop.
Page 227 Chapter 14 Fiber Testing OneCheck Fiber These tests check whether the fiber connectors are clean, monitor the power of the fiber connection, and can run tests on your VIAVI Smart OTDR E126A or SL. The tests require these accessories: •...
Page 228 1. Connect your instrument to the fiber line under test using a VIAVI optical power meter MP60. Attach the MP60 and fiber scope to the USB jacks on the right side of the unit.
Page 229 Chapter 14 Fiber Testing OneCheck Fiber Editor Before you run the tests, you can configure up to three test profiles types. 1. Under the OneCheck Fiber menu, select The OneCheck Fiber Editor OneCheck Fiber Editor. screen will open, listing your test profiles. 2.
Page 230 Chapter 14 Fiber Testing Fiber Inspection Select Fiber Inspection on the Editor configuration screen to enable this test. It's enabled by default. When finished, press the Back arrow to go back to the Editor configuration screen. Optical Power Test Select Optical Power Test on the Editor configuration screen to enable this test.
Page 231 Chapter 14 Fiber Testing OTDR Test Select OTDR Test on the Editor configuration screen to enable this test. It's enabled by default. When finished, press the Back arrow to go back to the Editor configuration screen. Saving the profile and launching the test Once you are done with editing the profile, press the Back arrow to return to the Editor configuration screen for that profile.
Page 232 Chapter 14 Fiber Testing Fiber Certification These tests check whether the fiber connectors are clean and monitor the power of the fiber connection. 1. Under the OneCheck Fiber menu, select Fiber Cert. 2. You will be prompted to attach the fiber scope to the USB port and select OK. 3.
Page 233 Chapter 14 Fiber Testing 7. Once the fiber is clean, the next step will prompt you to attach the Fiber Meter to monitor the power over the fiber connection. 8. Select the wavelength you want to use. When finished, the tests for both the fiber certification and power meter will show if they passed or failed.
Page 234 Chapter 14 Fiber Testing SmartOTDR These tests can run fiber measurements on your VIAVI Smart OTDR E126A or SL. 1. Make sure your SmartOTDR is turned on. It will create a WiFi network that you can connect your ONX shortly.
Page 235 Chapter 14 Fiber Testing 5. Once connected, you can select a test configuration file and choose whether to use a launch cable, or run the default test. These settings will be saved for your next test. SmartOTDR configuration file – Point_To_Point or Short_Link_1km Cable ID –...
Page 236 Chapter 14 Fiber Testing OneExpert DSL User's Guide 22052280, Rev. 015 April 2019...
Page 237 Using the OneExpert with a Mobile Device This chapter provides task-based instructions for using the two optional applications that are available for mobile devices: OneExpert DSL and Viavi Mobile Tech. Topics discussed include the following: • "OneExpert DSL app" on page 238 •...
Page 238: Getting Started
Before using the OneExpert DSL with a mobile device, verify the following: • The mobile device must have the OneExpert app installed (available on the AppStore or from your Viavi representative). • In order to use the OneExpert DSL with a mobile device, the OneExpert DSL must be have the Apple option enabled.
Page 239 Chapter 14 Using the OneExpert with a Mobile Device You can now control the instrument as if you were pressing the actual buttons on the device, allowing you to run most of the tests that are available on the OneExpert DSL. Notice the Back button on the left and the Tray and Camera buttons on the right, as shown below.
Page 240 Chapter 14 Using the OneExpert with a Mobile Device Updating the iOS application software Updating the iOS application software allows you to have the latest application, including new features and company-specific procedures or applications. 1. To download the application, do one of the following: •...
Page 241 Chapter 14 Using the OneExpert with a Mobile Device Connecting to StrataSync from the VIAVI Mobile Tech App You can connect to StrataSync using your smart phone or tablet anytime, anywhere using the VIAVI Mobile Tech app. Mobile Tech supports sync and file management between your OneExpert and DSP meters and StrataSync using an iOS or Android mobile device.
Page 242 Chapter 14 Using the OneExpert with a Mobile Device Mobile Tech Main Menu Once you log into StrataSync, you will see the Main menu. Here you can see details of the instrument, sync to StrataSync, manage files on the unit, view documentation, and even contact product support for more information or to request a repair or calibration.
Page 243 Settings– Configure advanced settings for the Mobile Tech app, including when the unit syncs and clearing local data • Product Support – Contact the VIAVI Technical Assistance Center, request repair or calibration, or watch quick tip videos OneExpert DSL User's Guide April 2019 22052280, Rev.
Page 244 Chapter 14 Using the OneExpert with a Mobile Device OneExpert DSL User's Guide 22052280, Rev. 015 April 2019...
Page 245: Test Results
Test Results This chapter describes the test results that are gathered when running a test. Topics discussed include the following: • "DSL/G.fast Results" on page 246 • "IP Data results" on page 255 • "TrueSpeed results" on page 256 • "Video results"...
Page 246: Context-Sensitive Help
Chapter 15 Test Results DSL/G.fast Results The following section describes the results available in the DSL mode. To view the different categories of statistics, use the left and right arrows, or tap the tab on the screen. Tapping TRG or AG area in the heading toggles the display for the connectors (for example, the RJ-45 connector).
Page 247 Chapter 15 Test Results When selected, the corresponding help box is displayed, as shown here. Summary This category provides a summary of the most frequently used DSL test results, as shown in the following table. Results Description Range BOOTING, The state of modem synchronization IDLE, INIT, Training State (appears in the menu heading).
Page 248 Chapter 15 Test Results Summary (continued) Results Description Range Connection Statistics 32 kB–3.3 (Up) 32 kB–25 MB (Dn) 64 kB–50 MB (Up) 64 kB–100 Current upstream and downstream Actual Rate MB (Dn) connection rates. Upstream downstream aggregate net data rates up to 1 Gbps 32 kB–3.3 (Up)
Page 249 Chapter 15 Test Results Results Description Range Signal attenuation. Attenuation average of the bins/tones that contain the actual signal (empty bins are not 0–63.5 dB (ADSL1) included). For a description of the 0–102.2 dB SATN settings impacting this calculated (ADSL2/2+) value, see 0–02.2 dB (VDSL) step 10 on page 82 of...
Page 250 Chapter 15 Test Results Packets This category provides results concerning transmitted and received DSL data. The results displayed vary depending on the network type that you specified when you configured your test (Terminate, Through-Router, or Through-Bridge). All Network Types • Rate –...
Page 251 Chapter 15 Test Results Network This category provides network statistics which vary based on the network type (Terminate, Through-Router, or Through-Bridge) and IP mode (IPv4, IPv6, or IPv4/IPv6 Dual Stack) that you specified when you configured your test. If you are testing using the Through-Router or Through-Bridge network type;...
Page 252 Primary DNS – The address of the preferred DNS server. When using internet addresses such as www.viavi.com, the OneExpert DSL (and all IP devices) must translate the address to an IP address (such as 157.234.12.20) in order to route the packets or data.
Page 253 Chapter 15 Test Results Events The Events page shows the new G.fast results and is available only with the Sckipio modem. The user needs to have the correct module attached (ONX-TM-GFAST), the Sckipio option installed (ONX580-GFASTSCKIPIO), and has “Sckipio” selected as the DSL Modem Vendor.
Page 254: Dsl Graphs
Chapter 15 Test Results Signal (continued) • LATN – Line attenuation. Attenuation average of all tones/bins (the entire line, including empty bins/tones). For a description of the settings impacting this calculated value, see step 10 on page 82 of “Specifying test settings” in Chapter 4 “xDSL / G.fast Testing”.
Page 255: Ip Data Results
Chapter 15 Test Results The following table lists common noise sources and the corresponding frequencies and tones. Noise Tone Noise Source Tone # Frequency (kHz) Frequency ISDN BRI 38.8125 HDSL passband center 194.0625 HDSL passband max 392.4375 HDSL2 T1 passband center E1 passband center 1024 1022...
Page 256: File Transfer Results
Chapter 15 Test Results File Transfer results • Status – The status of the transfer. • Bytes Transferred – The number of bytes transferred. • Transfer Rate – The speed that the file was uploaded or downloaded. TrueSpeed results The summary result screen reports the round trip time and the actual upload and download rates.
Page 257 Chapter 15 Test Results The following section describes the VoIP Audio Quality MOS (mean opinion score) results. These results relate to one call. R-value is a number that indicates the quality of speech, displayed as a percentage (1=worst and 100=best). •...
Page 258 Chapter 15 Test Results Network results (continued) • Network Delay – Time, in milliseconds, needed to travel the network (only displayed when a call is active). • Packetization Delay – Number of milliseconds needed to fill the frame(s) comprising one RTP data packet. •...
Page 259 Chapter 15 Test Results Summary • Stream IDs – Numbered 1-6, identifies the stream Each result provides the following four statistics: • State – Status of the stream Stream Up – Active Idle – No active stream Failed – A stream is no longer detected. All streams brought up using RTSP protocol will eventually reach the Failed state.
Page 260 Chapter 15 Test Results QoS results This category provides a summary of the video quality of the selected program flow. This screen varies depending on the stream type. • Err. Ind. – Number of MPEG2 bits with the error indicator bit set. •...
Page 261: Packet Statistics
Chapter 15 Test Results Packet statistics This category provides statistics for the packets at the IP layer. • IP Packets Rx– Total number of IP packets received. • Jitter Current – The current jitter value. • Jitter Max – The maximum jitter value. •...
Page 262 Chapter 15 Test Results Stream (TS) statistics (continued) • PID Timeouts – Number of occurrences when the PID for Video or Audio is not present for more than the configured threshold value. • Service Name – The name of the service as given by the “service name” string in the MPEG2-TS transport stream.
Page 263: Hpna Results
Chapter 15 Test Results HPNA results The following section describes the results available in HPNA mode. Node list The following table describes the Node List results. Range/ Results Description Units Values This column indicates the host/client of H: Host every HPNA device in device the network.
Page 264: Network Test
Chapter 15 Test Results Network Test The following table describes the HPNA results. Range/ Results Description Units Values This is a directional indication of each link Station ID -> ID denoted by each node This is the current data rate, and baud/ 0-112, Mbps, MBaud/ Rate, Mod Mbps...
Page 265: Protocol Messages
Chapter 15 Test Results Range/ Results Description Units Values The number of received packets that have had an invalid checksum. Packets (NOTE: There is no count for transmitted packets.) Protocol Messages The number of control ctrl_log_req requests from the local host (CERT protocol).
Page 266: Smartid Results
Chapter 15 Test Results SmartID results The following section paragraphs describes the results available in SmartID tests. Test Summary This category provides an overview of the results, including basic pass/fail indications of the links between the SmartIDs. Use the arrow keys to navigate and highlight a section. The details for that section appear.
Page 267: Copper Results
Chapter 15 Test Results Copper results The copper results are described in the following sections. AC voltage You measure AC volts to: • Detect the presence of hazardous voltage. • Measure stray or foreign voltages. • Measure ringer voltage level. AC voltage results on Tip (A) to Ring (B) should be 0.0 volts.
Page 268 Chapter 15 Test Results DC voltage You measure DC volts to: • Detect and measure CO/exchange battery voltage. • Detect crossed battery conditions. To measure DC volts, remove the line battery and measure Tip (A) and Ring (B) to ground. It should be <...
Page 269: Distance To Short
Chapter 15 Test Results Distance to short This result measures the distance to the short. A resistance measurement of 4 kΩ or less typically indicates a short. For values greater than 4 kΩ, this function is disabled. The following table describes the distance to short result. Range Range (feet) Resolution...
Page 270 Chapter 15 Test Results Opens/Capacitance You measure opens/capacitance to: • Measure total electrical loop length (includes length of bridged taps). • Find wet sections, bridged taps or open faults. Opens/Capacitance: < 3% difference between Tip (A) and Ring (B) values indicate an acceptably balanced loop.
Page 271: Longitudinal Balance
Chapter 15 Test Results Longitudinal balance You measure longitudinal balance to measure the quality of the pair – a measurement of the degree to which the Tip (A) lead is electrically the same as the Ring (B) lead. The more each lead is electrically identical (capacitance, inductance, impedance), the better the pair will resist induced noise.
Page 272: Impulse Noise
Chapter 15 Test Results A TDR (Time Domain Reflectometer) is used to identify and locate buried splices, shorts and low resistance faults, opens, bridge taps, load coils, and wet cables. Velocity of Propagation (VoP) is the speed of the TDR signal traveling down the wire pair relative to the speed of light.
Page 273 Chapter 15 Test Results WiFi Advisor results BSSID results The BSSID results screen provides a listing of all detected BSSIDs along with their channel setting, current signal strength, and MAC address. To view more details of a particular BSSID, select the desired BSSID, and then press the right arrow.
Page 274 Chapter 15 Test Results Best Channels A table that identifies the current top 3 best channels based on channel width for the band being viewed. This helps determine which channel to select for a new access point. Spectral results The Spectral results provide a real-time spectral analyzer configurable by 802.11 band, channel, and channel width.
Page 275 Appendix This appendix includes troubleshooting and supplemental information for the OneExpert. Topics discussed include the following: • "Cleaning the instrument" on page 276 • "Resolving problems" on page 276 • "Getting Technical Assistance" on page 279 • "WiFi Advisor" on page 278 •...
Page 276: Cleaning The Instrument
Chapter 16 Appendix Cleaning the instrument The instrument itself does not require any specialized cleaning. An occasional wipe with a damp cloth is sufficient. NOTE: When cleaning the instrument, use a damp cloth and water only. Cleaning with chemicals could cause damage to the plastic case, buttons, or removal of markings.
Page 277: Data Testing
Chapter 16 Appendix - Verify that the Standard is correct (ADSL2+, G.DMT, Auto, etc.). - Isolate premise wiring. - Check for premise alarm system. - Verify the copper pair is provisioned for ADSL at the CO. - Test at the CO/Exchange on the customer pair. - Check the DSLAM modem vendor and software version.
Page 278 Chapter 16 Appendix WiFi Advisor The following table provides some typical problems and resolutions. Problem Resolution Signal strength and coverage Look for -35 to -70 dBm RSSI and >20 dB SNR. problems – Attenuation with distance and materials in the home –...
Page 279: Getting Technical Assistance
The WiFi Advisor is unresponsive Press and hold the power button for 5 seconds. (locked-up) Getting Technical Assistance If you require technical assistance, call 1-844-GO-VIAVI / 1.844.468.4284. For the latest TAC information, visit http://www.viavisolutions.com/en/services-andsupport/support/technical-assistance Additional Information For more detailed information, contact us at TAC@viavisolutions.com...
Page 280: Specifications
Chapter 16 Appendix Specifications Physical specifications Height 9.8” (250 mm) Width 4.68” (119 mm) Depth 3.2” (82.4 mm Weight 4.05 lb. (1.84 kg) Connector specifications USB 2.0 AC Adapter see “Power specifications” T/A R/B Ground mini-banana POTS 8-pin modular (RJ-45) Ethernet 8-pin modular (RJ-45) Wiring...
Page 281 Chapter 16 Appendix Physical specifications Operating time >4 hours for typical use cases Charging time 5 hours for a fast charge; for a full charge, allow to trickle charge overnight Power supply input 100-240VAC, 1.5A, 50-60 Hz Power supply output 12VDC, 5.0A Max Power supply operating temperature 0°...
Page 282 Rev 015, April 2019 English VIAVI Solutions North America: 1.844.GO VIAVI / 1.844.468.4284 Latin America +52 55 5543 6644 EMEA +49 7121 862273 APAC +1 512 201 6534 All Other Regions: viavisolutions.com/contacts email TAC@viavisolutions.com...

This manual is also suitable for:

Oneexpert dsl onx-580p Oneexpert dsl onx-580a Oneexpert dsl onx580-bdcm-dsl-bonded Oneexpert dsl onx-bdcm-dsl-anxab Oneexpert dsl onx-bdcm-gfast Oneexpert dsl onx-tm-gfast ... Show all

Viavi OneExpert DSL ONX-580 User Manual

Quick Links

Related Manuals for Viavi OneExpert DSL ONX-580

Summary of Contents for Viavi OneExpert DSL ONX-580

This manual is also suitable for:

Table of Contents
