Table of Contents

Introduction
Warning
Overhead Power Line Safety
Tools Required
Parts Included
Installation
Site Selection
Mounting Pipe
Radial System
Assembly
Vertical Base Section
Base Section to Mounting Pipe
Assembling the Vertical Sections
Tuning the Vertical Antenna System
Guying the Vertical Antenna
Appendix A - Optional Radial Plate
Appendix B - Optional Tilt Base
Appendix C - Optional Vertical Feedline Current Choke
Optional Accessory Items
Technical Support and Warranty

Introduction

The DX Engineering DXE-40VE-1 is a fast taper 33 feet high 40 meter monoband vertical antenna
system. The vertical antenna operates over the entire 40 meter band with a SWR less than 1.5:1.
There are no traps, coils or linear loading elements to rob power. Designed with 6063 corrosion-
resistant aluminum tubing and stainless steel hardware, this antenna is very durable and attractive.
The antenna may be used as a monoband antenna on a higher frequency by simply telescoping the
tubing inward to one quarter wavelength on the desired band. As supplied, an extra element section
is part of the design to allow extension to 36 feet if necessary.
- 1 -
