- Page 1 40/30 Meter Dual-Band Vertical Antenna DXE-4030VA-1 DXE-4030VA-1-INS-Revision 5a © DX Engineering 2017 1200 Southeast Ave. - Tallmadge, OH 44278 USA Phone: (800) 777-0703 ∙ Tech Support and International: (330) 572-3200 Fax: (330) 572-3279 ∙ E-mail: DXEngineering@DXEngineering.com...
-
Page 2: Table Of Contents
Table of Contents Introduction Features Supplied Installation Items Additional Material Needed, Not Supplied Parts List Suggested Parts Not Included Tools Required Manual Updates Warning Installation Site Selection Radial System Mounting Pipe Assembly Radial Plate to Mounting Pipe Attaching Ground Radial Wires to the Radial Plate Tilt Base to Mounting Pipe Vertical Base Section Base Section to Tilt Base... -
Page 3: Introduction
Heavy Duty design to withstand 60 MPH wind without guying Supplied Installation Items: DX Engineering’s patented Tilt Base - Precision laser cut from 3/16 inch thick 304 Stainless Steel, this mounting plate is virtually indestructible. Using the included two DXE-SSVC-2P V-Clamps, the Tilt Base is mounted to the same mast that you use for the optional radial plate. -
Page 4: Parts List
Parts List for the DXE-4030VA-1 40 - 30 Meter Vertical Antenna Lower Tilt Base Assembly Quantity Tilt Base, patented Stainless Steel, Laser Cut, 3/16" DXE-SSVC-2P V-Clamp Kit ® Insulated Tilt Base, Extren Mast Mount Channel Tilt Base Aluminum Mounting Plate 1/4-20 x 2"... -
Page 5: Suggested Parts Not Included
Every effort is made to supply the latest manual revision with each product. Occasionally a manual will be updated between the time your DX Engineering product is shipped and when you receive it. Please check the DX Engineering web site (www.dxengineering.com) for the latest revision manual. -
Page 6: Warning
WARNING! INSTALLATION OF ANY ANTENNA NEAR POWER LINES IS DANGEROUS Warning: Do not locate the antenna near overhead power lines or other electric light or power circuits, or where it can come into contact with such circuits. When installing the antenna, take extreme care not to come into contact with such circuits, because they may cause serious injury or death. -
Page 7: Mounting Pipe
Using enough staples will ensure the wires will not be snagged by mowers, people, or animals. Grass will quickly overgrow the radials and it will be virtually impossible to see them. An article describing this process is available the DX Engineering website www.dxengineering.com in the Tech Info section. -
Page 8: Assembly
Assembly The DXE-40/30 Meter Vertical Antenna shipping box contains the vertical tubing sections, an insulated U-channel, two 3/8" U-Bolts, saddles with hardware, a backing plate, a Tilt Base, stainless steel element clamps, a black vinyl cap, and stainless steel hardware. Carefully un-pack the antenna and separate the various parts. -
Page 9: Attaching Ground Radial Wires To The Radial Plate
Figure 2. Additional hardware kits are available (DXE-RADP-1HWK) that contain 20 sets of Radial Plate Hardware. There are optional DX Engineering Radial Wire Kits available. DXE-RADW-500K/BD contains a 500 foot spool of 14 gauge copper stranded wire with black PVC insulation, 20 Terminal Lugs and 100 Steel or Biodegradable Lawn Staples. -
Page 10: Tilt Base To Mounting Pipe
When fully assembled and you are standing in front of the antenna and can read the DX Engineering logo on the tilt plate, the antenna tilts to the right. Refer to Figure 9 or Figure 15 for a picture showing the front of the antenna. Tighten the clamps evenly so the length of the exposed threads is approximately equal. -
Page 11: Vertical Base Section
Vertical Base Section ® The base section is made up of an Extren insulated mounting channel with hardware, a mounting plate, two 3/8" U-Bolt assemblies and the base antenna element sections. Using Figure 4, attach the aluminum backing plate to the back of the insulated channel. The base hardware kit contains four 2"... - Page 12 Install the lower sections to the insulated channel using the 2 - 3/8" x 2" U-Bolts, 2 saddle clamps, 4 flat washers, 4 split washers, and 4 nuts as shown in Figure 7. The base section tube should extend 1-1/4" beyond the bottom of the U-bolt clamp. When tightening, observe the split washers. When they fully seat (flatten out), the clamp is tight enough.
-
Page 13: Base Section To Tilt Base
Base Section to Tilt Base Place the Lower Base Section into the holes of the Tilt Base and loosely install the Tilt Base mounting hardware shown in Figure 8. Figure - 8 - 12 -... - Page 14 Using a wrench or nut driver, securely tighten the two Nyloc nuts at the bottom of the Tilt Base. Then loosen them one-half turn each. This will allow proper movement of the Tilt Base while raising or lowering the antenna. It is not necessary to tighten these nuts more securely unless further tilt operation is no longer required.
-
Page 15: Assembling The Vertical Sections
Assembling the Vertical Sections ™ Note: JTL-12555 Jet-Lube SS-30 Anti-Oxidant should be used between all antenna element ™ sections. Jet-Lube SS-30 is an electrical joint compound to affect a substantial electrical connection between metal parts such as telescoping aluminum tubing or other antenna pieces. It ensures high conductivity at all voltage levels by displacing moisture and preventing ™... - Page 16 Assemble the vertical sections in an area that is flat and has sufficient room for the length of the antenna during assembly. Lay the tubing out in descending OD sizes. Orient the slits in the tubes as shown in Figure 11. Each element section is inserted into the next element section.
- Page 17 Figure 11 - Element Sections - 16 -...
- Page 18 Figure 12 - 30-40 Meter Vertical Antenna Element - 17 -...
-
Page 19: Mating The Vertical Sections To The Tilt Base
Mating the Vertical Sections to the Tilt Base CAUTION: Attempting final assembly without proper precaution can be dangerous. You should have someone help you steady the vertical antenna sections during mating with the base section. Note: A pair of sawhorses or ladders should be used to support the vertical sections during assembly with the Tilt Base and whenever the vertical is tilted down. -
Page 20: Assembling The Balun Shelf And Vfcc
Once the antenna is vertical, lift and slide the antenna to the left toward the Tilt Base mounting pipe to allow the two parts of the Tilt Base to line up and drop down into the slots. Lightly tighten the top flange nuts on the Tilt Base to hold the antenna. -
Page 21: Installation Of Vfcc To Antenna Mount
Installation of Vertical Feedline Choke Assembly to Antenna Mount The completed DXE-VFCC-H05-A Vertical Feedline Current Choke and Shelf assembly are mounted to the antenna mast pipe using the supplied DXE-SSVC-2P V-Camp assembly. Position the Balun Shelf Bracket approximately 1/4" above the Radial Plate mounting flange as shown in Figure 14. -
Page 22: Feedline Connections
1/2" long. Connect the longer 8-1/2" braid from the antenna feedpoint located on the base section of the antenna to the terminal on the DXE-VFCC-H05-A Vertical Feedline Current Choke closest in "DX Engineering" on the label as shown in Figure 15. "... - Page 23 Figure 15a - Completed Base Assembly for Reference - 22 -...
-
Page 24: Tuning The Vertical
Alternate Feedpoint Connection If not using the VFCC, the customer will have to make a secure and positive connection from the coax to the feedline connection on the antenna base and a connection to the Radial Plate. A DXE- ™ UHF-FDFB-KIT SecureMount double SO-239 Bulkhead Mount and a DXE-FP-WIRE-P Feedpoint Wire Connector Assembly should be used. -
Page 25: Optional Accessory Items
DXE-RADP-3 - Radial Plate (patented), Stainless Steel with 20 Sets of SS Radial Attachment Hardware The DX Engineering Radial Plate is meant for those of you that have or are building a quarter wave vertical antenna and who want an easy, neat and effective way to connect those essential radial wires and the coax to your vertical antenna for the lowest takeoff angle and strongest signals. - Page 26 Bulkhead Connector - Dual SO-239 ™ The DX Engineering Silver Plated Female SecureMount Bulkhead Connector is a high-quality silver-plated connector that provides a positive, permanently secure connection for your coaxial cable. The two-sided SO-239 female connector has a superior silver- ™...
- Page 27 DXE-T001 - DX Engineering SO-239 Connector Installation Tool Kit This DX Engineering SO-239 connector installation tool kit offers an easier installation of chassis or bulkhead mount SO-239 coaxial connectors. Having the right tools can make all of the difference in your shack, and this handy DXE tool provides you with a special dual-use stainless steel wrench, plus a multipurpose 6-in-1 screwdriver/nut driver tool.
-
Page 28: Technical Support And Warranty
Warranty All products manufactured by DX Engineering are warranted to be free from defects in material and workmanship for a period of one (1) year from date of shipment. DX Engineering’s sole obligation under these warranties shall be to issue credit, repair or replace any item or part thereof which is proved to be other than as warranted; no allowance shall be made for any labor charges of Buyer for replacement of parts, adjustment or repairs, or any other work, unless such charges are authorized in advance by DX Engineering.
