F6X53 Series
User Manual
F6X53 Series User Manual
The user manual is suitable for the following model:
Documentation No.
Product Name：
Model
F6453
F6553
TD-SCDMA GATEWAY
F6653
Xiamen Four-Faith Communication Technology Co., Ltd.
Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare
Park,XiaMen,China
Tel：+86 592-6300326 ，6300325，6300324
Fax:+86 592-5912735
http://www.fourfaith.com
Product Version
Product Type
WCDMA GATEWAY
EVDO GATEWAY
Zip Code:361008
Page
Total:
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Four-Faith F653 Series
Summary of Contents for Four-Faith F653 Series
- Page 1 F6X53 Series User Manual The user manual is suitable for the following model: Model Product Type F6453 WCDMA GATEWAY F6553 TD-SCDMA GATEWAY F6653 EVDO GATEWAY Xiamen Four-Faith Communication Technology Co., Ltd. Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare Park,XiaMen,China Zip Code:361008 Tel：+86 592-6300326 ，6300325，6300324 Fax:+86 592-5912735 http://www.fourfaith.com...
- Page 2 User Manual Files Revised Record Date Version Remark Author Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
- Page 3 Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
- Page 4 User Manual Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
-
Page 5: Table Of Contents
3.3.15 Misc ........................32 3.3.16 PPTP Client ......................32 3.3.17 L2TP Client ......................33 3.3.18 IPSEC Client ......................34 3.3.19 Dynamic DNS ...................... 34 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 5 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324... -
Page 6: Chapter 1 Brief Introduction Of Product
Support low-consumption mode, including sleep mode, scheduled online/offline mode, scheduled power-on/power-off mode(optional) Housing: iron, providing IP30 protection Power range: DC 5~35V Stability and Reliability Xiamen Four-Faith Communication Technology Co.,Ltd. Page 6 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：... -
Page 7: Working Principle
Support multi protocols, such as TCP/IP, UDP, ICMP, SMTP, HTTP, POP3, OICQ, TELNET, FTP, SNMP, etc. 1.3 Working Principle The principle chart of the GATEWAY is as following: Xiamen Four-Faith Communication Technology Co.,Ltd. Page 7 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... -
Page 8: Specifications
450MHz (optional) CDMA2000 1X RTT, IS-95 A/B WIFI Specification Item Content Standard IEEE802.11b/g IEEE802.11n (optional) Bandwidth IEEE802.11b/g: 54Mbps (max) Xiamen Four-Faith Communication Technology Co.,Ltd. Page 8 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735... - Page 9 Standard A type USB host interface (reserved) Power Input Item Content Standard Power DC 12V/1.5A Power Range DC 5~35V Xiamen Four-Faith Communication Technology Co.,Ltd. Page 9 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
- Page 10 Operating -25~+65º C（-13~+149℉） Temperature Extended -30~+75º C（-22~+167℉） Operating Temperature Storage -40~+85º C（-40~+185℉） Temperature Operating 95% ( Non-condensing) Humidity Xiamen Four-Faith Communication Technology Co.,Ltd. Page 10 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
-
Page 11: Chapter 2 Installation Introduction
Telephone cable Power adapter Manual CD Certification card Maintenance card 2.3 Installation and Cable Connection : (unit: mm) Dimension Xiamen Four-Faith Communication Technology Co.,Ltd. Page 11 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735... - Page 12 Insert one end of the network cable into the switch interface with sign “Local Network”, and insert the other end into the Ethernet interface of user’s device. The signal connection of network direct cable is as follows: RJ45-1 RJ45-2 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 12 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
-
Page 13: Power
The GATEWAY has a “Reset” button to restore it to its original factory default settings. When user press the “Reset” button for up to 15s, the GATEWAY will restore to its original factory default settings and restart automatically. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 13 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... -
Page 14: Chapter 3 Configuration And Management
Ethernet port is 192.168.1.1). It will prompt a login page. The default username and password are both “admin”. Please input the username and password login to access the configuration pages. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 14 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... -
Page 15: Configuration
This page is used to configure the Internet access parameters. WAN Wireless Note: Model Username and password Call center F6453 3gnet null *99# F6553 cmnet null *98*1# Xiamen Four-Faith Communication Technology Co.,Ltd. Page 15 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735... - Page 16 This function is used to detect whether the Internet connection is active, if you set it and when the router detect the connection is inactive ,it will redial to you ISP immediately to make the connection active. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 16 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
-
Page 17: Wifi Settings
Name(SSID): Service Set Identifier which is also known as the wireless network name, A value of up to 32 alphanumeric characters. Region: This item determines where to use the router, please choose the corresponding region you Xiamen Four-Faith Communication Technology Co.,Ltd. Page 17 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... - Page 18 WI-FI Protected Access Pre-Shared Key WPA/WPA2-PSK WI-FI Protected Access Pre-Shared Key Configure WEP Wireless Security When you choose WEP security options, the WEP configure page is as following: Xiamen Four-Faith Communication Technology Co.,Ltd. Page 18 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
-
Page 19: Lan Settings
WPA. For instructions on configuring wireless devices for WPA-PSK security, please consult the documentation for the product you are using. 3.3.4 LAN Settings Xiamen Four-Faith Communication Technology Co.,Ltd. Page 19 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... -
Page 20: Nat
Internet, This is done using the NAT (Network Address Translation). The NAT configuration page is as following: Add a NAT item Xiamen Four-Faith Communication Technology Co.,Ltd. Page 20 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... -
Page 21: Dmz
Instead of discarding traffic for services you have not defined, you can have it forwarded to one computer on your network. This computer is called the Default DMZ Xiamen Four-Faith Communication Technology Co.,Ltd. Page 21 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... -
Page 22: Filter
Discard The Following--Discard all packets matched the custom filter rules, Accept all other packets Only Accept The Following--Accept all packets matched the custom filter rules, Discard all other packets Add Filter Item Xiamen Four-Faith Communication Technology Co.,Ltd. Page 22 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：... - Page 23 Address ,the filter item could be configured as following: The following is the configured filter item: MAC Restrict This filter function is based on the Ethernet MAC address. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 23 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
-
Page 24: Static Routes
VPN tunnel or multiple IP subnets located on your local network. Press “Add” button to start add a custom static route: Xiamen Four-Faith Communication Technology Co.,Ltd. Page 24 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... -
Page 25: Router Status
This page displays the router’s status information. Account Name: The username to login the router. Firmware Version: Software version information Module Type: The wireless module used to get the Internet access Xiamen Four-Faith Communication Technology Co.,Ltd. Page 25 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... - Page 26 Interface: The interface name of the PPTP tunnel when the tunnel is up. Local Tunnel IP: The local tunnel IP Address when the tunnel is up. Remote Tunnel IP: the PPTP server’s tunnel IP Address when the tunnel is up. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 26 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
-
Page 27: Backup Settings
“Browse” button to browse to the file. When you have located it, click the “Restore” button to send the file to the router to restore configuration. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 27 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... -
Page 28: Load Default
“No” to give up. 3.3.12 Router Upgrade The software of the router is stored in FLASH memory, and can be upgraded as new software is released by Four-Faith. Upgrade files can be downloaded from the Four-Faith Web site( www.four-faith.com ). If the upgrade file is compressed (.ZIP file or .RAR), you must first extract the binary ( .IMG) file before sending it to the router. -
Page 29: Set Password
This function is used to debug the software, when there is some problem with the router, you can get the log information and send it to us to diagnose the problem. Normally this function should be disabled. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 29 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... - Page 30 Log Way: there are three log ways The log message is displayed on this web page. You can save the log message to a file by click “Save Log” button. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 30 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
- Page 31 When you configure the serial port settings , press “call” button ,The router log message will be displayed. You can capture the log message into a file: From the menu, choose “Transfer” ”capture text” Xiamen Four-Faith Communication Technology Co.,Ltd. Page 31 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
-
Page 32: Misc
IP Address and run a syslog server program on it. . 3.3.15 Misc Normally, the four-faith web config tool listens on port 80. If you want to change listening port, please configure “web config port” item. To reboot the router , press the “Reboot” button. -
Page 33: L2Tp Client
L2TP Server dynamically. You can also use the fixed local tunnel IP if the L2TP Server support User Name: Username to login the L2TP Server. Password: Password to login the L2TP Server. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 33 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... -
Page 34: Ipsec Client
DNS service, which will allow you to register your domain to their IP address, and will forward traffic directed at your domain to your frequently-changing IP address. The four-faith router currently support 88ip(www.88ip.net) and 3322(www.3322.org) Dynamic DNS provider. Xiamen Four-Faith Communication Technology Co.,Ltd. - Page 35 Service Provider: the DDNS service provider Host Name: The 3322 provider’s server hostname Customer Domain: Your custom 3322 domain name. User Name: Your 3322 account username Xiamen Four-Faith Communication Technology Co.,Ltd. Page 35 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
- Page 36 The “Show Status” button is used to display the current DDNS status. The above DDNS status page shows the domain name tomjerry555.3322.org now point to IP Address 10.95.207.236 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 36 of 36 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
