QUICKSERVER DESCRIPTION

QuickServer is a high performance, cost effective Building and Industrial Automation multi-protocol
gateway providing protocol translation between serial/Ethernet devices and networks.
NOTE: For troubleshooting assistance refer to
appendices in the related driver supplements. Check the
technical support resources and documentation that may be of assistance.
The QuickServer is cloud ready and connects with Sierra Monitor's SMC Cloud. See Section
further information.
2

CERTIFICATIONS

BTL Mark – BACnet
2.1
The BTL Mark is a symbol that indicates that a product has passed a series of
rigorous tests conducted by an independent laboratory which verifies that the
product correctly implements the BACnet features claimed in the listing. The mark is
a symbol of a high-quality BACnet product.
Go to
Laboratory. Click
3

SUPPLIED EQUIPMENT

QuickServer Gateway
•
Preloaded with two selected drivers. A sample configuration file is also loaded.
•
All instruction manuals, driver manuals, support utilities are available on the USB drive provided
in the optional accessory kit, or on the
Accessory kit (optional) (Part # FS-8915-38-QS) includes:
•
7-ft Cat-5 cable with RJ45 connectors at both ends
•
Power Supply -110/220V (p/n 69196)
•
Screwdriver for connecting to terminals
•
USB Flash drive loaded with:
o
QuickServer 2XX0 Start-up Guide
o
FieldServer Configuration Manual
o
All FieldServer Driver Manuals
o
Support Utilities
o
Any additional folders related to special files
configured for a specific QuickServer
o
Additional components as required - see driver manual supplement for details
1
BACnet is a registered trademark of ASHRAE.
Appendix
1
Testing Laboratory
www.BACnetInternational.net
here for the BACnet PIC
Sierra Monitor
Page 6 of 32
QuickServer Start-Up Guide
B, or any of the troubleshooting
Sierra Monitor website
for more information about the BACnet Testing
Statement.
website.
for
5.1.3
for
