- Page 1 Bee Ball Y022 Backboard Instruction Manual...
- Page 2 Tools Required Benötigtes Material / Accessoires / Herramientas Strumenti da lavoro / Benodigdheden Identifying Bolts Two pairs of hands Spanner and Socket Set Parts Included Unterteile / Liste des pièces / Lista de partes Elenco degli elementi / Onderdelen Bolt & Washer Bolt, Nut &...
- Page 3 Before Installation Check all parts are present! Our factory takes every effort to make sure everything is packed in its proper place. But just in case a small part has gone astray please make sure you check every piece is present before you begin installing - right down to the nuts and bolts. Assemble with Care Installation should be completed by two adults.
- Page 4 Assembling Your Backboard & Ring Attach Backboard Brackets You will need: 1 x Backboard (part 1) 4 x Bolts, Nuts & Washers A (M8 x 65mm) 2 x Board Brackets (parts 2) Attach the two Board Bracktes (parts 2) to the Backboard (part 1) using four Bolts, Nuts and Washers A (M8 x 65mm).
- Page 5 Attach Ring to Backboard Mark the Position of the Backboard You will need: Pre assembled Backboard (parts 1 + 2) Pencil Decide where you would like your backboard to be fixed and using the backboard frame as a template mark where you will drill the holes in the wall.
- Page 6 Fix Backboard to Wall Diagram 1...
- Page 7 Warning! Failure to comply with these warnings can lead to injury and/or damage of the basketball equipment. • If using a ladder during assembly, use extreme caution. • Do not allow children to hang from the hoop or any part of the system including the backboard, rim, support braces or net.
- Page 8 Not just Basketball... You may or may not be aware that Bee-Ball is exclusive to the retailer Big Game Hunters who not only have a huge range of high quality basketball equipment but are also owners of the UK’s leading sports ball retailer.
