- Page 1 Bee Ball Y024 Instruction Manual...
-
Page 2: Tools Required
Tools Required Benötigtes Material / Accessoires / Herramientas Strumenti da lavoro / Benodigdheden Two pairs of hands Spanner and Socket Set Parts Included Unterteile / Liste des pièces / Lista de partes Identifying Bolts Elenco degli elementi / Onderdelen Bolt, Nut & Bolt, Nut &... -
Page 3: Before Installation
Before Installation Check all parts are present! Our factory takes every effort to make sure everything is packed in its proper place. But just in case a small part has gone astray please make sure you check every piece is present before you begin installing - right down to the nuts and bolts. Assemble with Care Installation should be completed by two adults. - Page 4 Attach Ring to Backboard You will need: Hoop/Ring (part 2) 4 x Bolts, Nuts & Washers A (M10 x 40mm) Backboard (part 1) First, remove the metal case from the back of the ring using a crosshead screwdriver. Fix the Hoop/Ring (part 2) to the front of the Backboard (part 1) using four Bolts, Nuts & Washers A. The bolts go through the back of the backboard then through the ring and are fixed in place using the nuts.
- Page 5 Attach Backboard Brackets They should sit in this order once assembled: Bolt > Washer > Bracket > Backboard > Washer > Nut fixing joint Attach Backplate to Brackets You will need: Pre assembled parts from steps 2-3 (parts 1 + 2 + 4 + 5) Backplate (part 6) 4 x Bolts, Springs, Nuts &...
- Page 6 Attach Adjustment Pole and Handle Note: If there is not enough clearance for the bolt, wind the handle so it drops down. Attach Braces You will need: Pre assembled backboard from steps 1-5 (parts 1 + 2 + 4 + 5 + 6 + 9) Lower Braces (part 8) Upper Braces (part 7) 4 x Bolts, Nut &...
-
Page 7: Inspection And Maintenance
Fix Backboard to Wall Warning! Failure to comply with these warnings can lead to injury and/or damage of the basketball equipment. • If using a ladder during assembly, use extreme caution. • Do not allow children to hang from the hoop or any part of the system including the backboard, rim, support braces or net. - Page 8 Not just Basketball... You may or may not be aware that Bee-Ball is exclusive to the retailer Big Game Hunters who not only have a huge range of high quality basketball equipment but are also owners of the UK’s leading sports ball retailer.
