- Page 1 Bee Ball Y015 Backboard Instruction Manual...
- Page 2 Tools Required Benötigtes Material / Accessoires / Herramientas Strumenti da lavoro / Benodigdheden Identifying Bolts Two pairs of hands Spanner and Socket Set Parts Included Unterteile / Liste des pièces / Lista de partes Elenco degli elementi / Onderdelen Bolt & Washer Bolt, Nut &...
- Page 3 Before Installation Check all parts are present! Our factory takes every effort to make sure everything is packed in its proper place. But just in case a small part has gone astray please make sure you check every piece is present before you begin installing - right down to the nuts and bolts. Assemble with Care Installation should be completed by two adults.
- Page 4 Assembling Your Backboard & Ring Assemble the Frame You will need: 2 x Board Braces (parts 4) 2 x Bolts & Washers E (M12 x 150mm) 1 x Board Bracket (part 5) Attach the two Backboard Braces (parts 4) to the Backboard Bracket (part 5) using two Bolts, Nuts and Washers E. They should sit in this order once assembled: Bolt >...
- Page 5 Attach Backboard Braces You will need: Pre assembled parts from step 1 (parts 4 + 5) 2 x Bolts & Washers A (M8 x 16mm) 1 x Backboard Bend both struts of the Backboard Bracket (part 5) outwards and attach them to the backboard using two Bolts, Nuts and Washers A.
- Page 6 Fix Backboard to Wall You will need: Pre assembled backboard from steps 1-4 (parts 1 + 2 + 4 + 5) 4 x Bolts, Nut & Washers C (M8 x 80mm) Fix the backboard brackets to the wall using four wall anchor Bolts, Nuts and Washers C. Using an equal diameter drill bit to the wall anchor bolts drill the holes in your wall and insert the bolts with the nuts facing out.
- Page 7 Warning! Failure to comply with these warnings can lead to injury and/or damage of the basketball equipment. • If using a ladder during assembly, use extreme caution. • Do not allow children to hang from the hoop or any part of the system including the backboard, rim, support braces or net.
- Page 8 Not just Basketball... You may or may not be aware that Bee-Ball is exclusive to the retailer Big Game Hunters who not only have a huge range of high quality basketball equipment but are also owners of the UK’s leading sports ball retailer.
