TECHNICAL INDEX

ACCURACY SPECIFICATIONS

•
Accuracy: ± (% reading + counts) – the calibration period is 1 year.
•
Ambient temperature and humidity: 23°C±5°C: <80%RH.
•
Temperature coefficient: the accuracy assured temperature condition is 18°C-28°C, the
range of ambient temperature fluctuation is stable within ±1°C.
When the temperature is less than 18°C or over 28°C, the additional temperature
coefficient error is 0.1 x (specified accuracy)/°C.

DC CURRENT MEASUREMENT

RANGE RESOLUTION
40A 0.01 A
400A

AC CURRENT MEASUREMENT

RANGE RESOLUTION
40A 0.01 A
400A
CAUTION
•
When the measured current reaches the warning value, there will be an alarm sound.
•
With DC current DCA mode, the LCD may display non-zero value in open circuit state, users
can press "REL" button to clear display to zero before each measurement.

DC VOLTAGE MEASUREMENT

RANGE RESOLUTION
400mV 0.1mV
4V 0.001V
40V 0.01V
400V
600V
14
ACCURACY
±(2%+5)
0.1A
ACCURACY
±(2%+5)
0.1A
ACCURACY
± (0.7%+3)
± (0. 5%+2)
0.1V
1V
600V CLAMP METER
