C.A. Technologies CPR Product Information page 4

FLUID NOZZLE / AIR CAP SELECTION CHARTS
CPR HVLP/PRESSURE REDUCED SPRAY GUN
MATERIAL TYPE
Very Thin
less than 16 sec. Zahn #2
inks , dyes,
solvents, stains
Thin
16 to 20 sec. Zahn #2
lacquers, enamels,
primers, sealers
Medium
21 to 30 sec. Zahn #2
automotive base coat
enamels, primers
epoxies, urethanes
automotive clear coat
Heavy
over 30 sec. Zahn #2
heavy body primers
high solid enamels
high solid automotive coatings
adhesives
CPR Smart Pack Includes:
98-0104 3/8" Socket
98-0112 Ratchet Wrench
60-8001 Gun Wrench
98-0113 Gun Cleaning Brush
Air Caps and Needles Shown on Page 1
CPR-303R2 Includes:
51-303 1 QT Aluminum Pressure Cup
52-5R2 Pressure Cup Regulator
98-0104 3/8" Socket
98-0112 Ratchet Wrench
60-8001 Gun Wrench
98-0113 Gun Cleaning Brush
Air Caps and Needles Shown on Page 1
CPR-PPSR2 Includes:
91-460 950 mL 3M™ PPS™ Pressure Cup
91-462 Lids and Liners (Available in 25 Pack)
91-475 #18 PPS Adapter
52-5R2 Pressure Cup Regulator
98-0104 3/8" Socket
98-0112 Ratchet Wrench
60-8001 Gun Wrench
98-0113 Gun Cleaning Brush
Air Caps and Needles Shown on Page 1
Revised 11/17/15
CPR Series - Pressure Feed Guns
FLUID ORIFICE x
AIR CAP
0.8 mm x 2101 or 1301
1.0 mm x 2101 or 1301
1.2 mm x 2101 or 1301
1.3 mm x 2101 or 1301
1.3 mm x 2101 or 1301
1.4 mm x 2101 or 1301
1.5 mm x 2101 or 1301
1.7 mm x 2101 or 1301
1.7 mm x 2101 or 1301
1.9 mm x 1301
2.2 mm x 1301
CPR-303R2
MAXIMUM
PATTERN WIDTH
23-2101 13"
23-1301 12"
23-2101 13"
23-1301 12"
23-2101 13"
23-1301 12"
23-2101 13"
23-1301 12"
CPR
CPR-PPSR2
CFM
23-2101 11 CFM
23-1301 13.5 CFM
23-2101 11 CFM
23-1301 13.5 CFM
23-2101 11 CFM
23-1301 13.5 CFM
23-2101 11 CFM
23-1301 13.5 CFM
