HYPER / BACK EXTENSION BENCH

RMNCHAIRv2

400919

Operator's Manual

Read the Operator's Manual entirely. When you see this

symbol, the subsequent instructions and warnings are

serious follow without exception. Your life and the lives

of others depend on it!

Cover photo may show optional equipment not supplied

with standard unit. For an Operator's Manual and Decal

Kit in French or Spanish Language, please see your dealer.

Need help?

Do you have a question about the RMNCHAIRv2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Titan Fitness RMNCHAIRv2

Page 1 HYPER / BACK EXTENSION BENCH RMNCHAIRv2 400919 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it! Cover photo may show optional equipment not supplied with standard unit.
Page 2 PARTS DIAGRAM / EXPLODED VIEW...
Page 3 DESCRIPTION DESCRIPTION REAR SUPPORT FRAME (18) KNOB REAR BASE FRAME (19) LOCK PIN M10 FRONT BASE FRAME (20) 60X2-F50 SLEEVE PAD SUPPORT FRAME (21) PLUG Φ25*2 LEFT HANDLE (22) PLUG Φ32*1.5 RIGHT HANDLE (23) F50*2 PLUG FOAM BRACKET (24) F60*2 PLUG FRONT SUPPORT FRAME (25) BOLT M10*85...
Page 4 ASSEMBLY INSTRUCTIONS STEP 1: Connect REAR SUPPORT FRAME (1), REAR BASE FRAME (2), and FRONT BASE FRAME (3), using PIN (11), FLAT WASHER (31), and HEX BOLT M10*20 (28).
Page 5 ASSEMBLY INSTRUCTIONS STEP 2: Fix PAD (12) on PAD SUPPORT FRAME (4), using the FLAT WASHER (32), and BOLT M8*20 (29), then insert the PAD SUPPORT FRAME (4) into the REAR SUPPORT FRAME (1).
Page 6 ASSEMBLY INSTRUCTIONS STEP 3: Fix LEFT HANDLE (5) and RIGHT HANDLE (6) on PAD SUPPORT FRAME (4), using the FLAT WASHER (31), NUT M10 (33), and BOLT M10*70 (27).
Page 7 ASSEMBLY INSTRUCTIONS STEP 4: Fix FOAM BRACKET (7) on REAR SUPPORT FRAME (1), using PLATE (16), FLAT WASHER (31), NUT M10 (33), and BOLT M10*80 (26). Insert FOAM TUBE (9) into the FOAM BRACKET (7), then install the FOAM (13) on the FOAM TUBE (9).
Page 8 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
