- Page 1 INFINITY ROPE PULL SYSTEM RPLYSYSv3 401920 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
- Page 2 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION INFINITY ROPE PULLEY SYSTEM MAIN BODY COVER PLATE SPACER STEEL PLATE SPACER BUSH ROPE PLUM BLOSSOM KNOB HEX BOLT M16×160 HEX BOLT M16×110 (10) NYLON NUT M16 (11) FLAT WASHER Φ16 (12) HEX WRENCH (13) WRENCH...
-
Page 3: Pay Attention
ASSEMBLY INSTRUCTIONS STEP 1 Fix the Infinity Rope Pulley System Main Body (1) and Steel Plate(4) on the vertical or horizontal uprights, using Flat Washer Φ16(10), Nylon Nut M16(10), and Hex Bolt M16*110(9). PAY ATTENTION: 1. Infinity Rope Pulley System can be used with TITAN Series Power Racks. Please use Spacer Bush (5) according to your needs. - Page 4 STEP 2 Install Rope (6) as below picture showing.
- Page 5 STEP 3 Connect the Cover Plate (2) with Infinity Rope Pulley System Main Body(1), tighten with the Plum Blossom Knob(7).
- Page 6 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
- Page 7 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2024 Titan Brands...
