- Page 1 Outdoor Ice Maker OIM450SS Owner’s Manual For more information on other great EdgeStar products on the web, go to http://www.edgestar.com To use the EdgeStar self-diagnostic tool, go to https://support.edgestar.com V2.4-04082019...
- Page 2 Important Safety Information Improper handling can cause serious damage to the EdgeStar ice maker and/or injury to the user. This ice maker is designed for domestic use only. Do not use the unit for industrial or commercial use. Any other use may invalidate the warranty. Please review the ratings label located on the rear panel of the unit for electrical and other technical data related to this unit.
- Page 3 General Safety To prevent back and other types of injuries, use at least two people to move and install the ice maker. Install the ice maker in a well ventilated area where the ambient temperature is above 50° F and below 100°...
-
Page 4: Table Of Contents
................14 XTERIOR LEANING ..........14 IN AND ATER ROUGH LEANING ............... 14 ONDENSER LEANING ..........15 ATER ISTRIBUTION LEANING ............16 MAKING YSTEM LEANING TROUBLESHOOTING ..............17 TROUBLESHOOTING CONTINUED ..........18 SPECIFICATIONS ................19 EDGESTAR LIMITED WARRANTY ..........20... -
Page 5: Introduction
Introduction Thank you for purchasing this EdgeStar built in ice maker. We hope that this purchase will be the beginning of a lasting and rewarding relationship between you and EdgeStar. We will provide the customer support and exemplary products necessary to nurture that relationship. -
Page 6: Parts Identification
Parts Identification Front View Back View... -
Page 7: Installing The Ice Maker
Installing the Ice Maker Warning: Use two or more people to move and install the ice maker. Failure to do so can result in back or other injury. The ice maker should be installed by a licensed plumber in accordance with local electrical and plumbing code requirements. -
Page 8: Installation Clearance Requirements
Installation Clearance Requirements Note: This icemaker should be installed by a licensed plumber only. To ensure proper service access and ventilation, allow more than 2” of clearance at the rear and 1/4” at the top and at the sides. The installation should allow the icemaker to be pulled forward for servicing if necessary. -
Page 9: Electrical Requirements
Electrical Requirements Electrical Shock Hazard Plug into a grounded 3-prong outlet. Never remove the grounding prong from the plug. Never use an adapter. Never use an extension cord. Failure to follow these instructions can result in fire, electrical shock, or death Before you move your icemaker into its final location, it is important to make sure you have the proper electrical connection: A standard electrical supply (115 V, 60Hz.), properly grounded in accordance with the National... -
Page 10: Installation Of Casters
Installation of Casters Important: Use at least two or more people to properly install casters. Carefully have one person tilt the unit away from them while the other person helps to support it. Make sure to give yourself enough clearance to insert the caster and tightly screw in clockwise. Please follow the diagram pictured below. -
Page 11: Reversing The Door Swing
Reversing the Door Swing Tools needed: flathead screwdriver, Phillips screwdriver Important: Before you begin, unplug the ice maker or disconnect power. To Remove the Door from the Hinges 1. Remove the top hinge cover, then using a Phillips screwdriver, remove the screws and take off top hinge. -
Page 12: Water Supply Connections
Water Supply Connections The water supply should be ready at the point of installation. The water supply pressure should be a minimum of 15 psig with a static pressure not more than 80 psig. (A wall outlet directly behind the ice maker will make installation easier.) Important: 1. -
Page 13: Connecting The Drain Line
Connecting the Drain Line: Note: There is a drain outlet on the ice maker. Please drain water through the drain hose provided with the ice maker. 1. Locate the floor drain near the ice maker. The distance should be less than 4.5 feet since the length of the long drain hose provided with the ice maker is about 4.5 feet. -
Page 14: Operating Method
Operating Method 1. Turn on the water tap, let the water trough fill, and then switch the ICE/OFF/WASH switch on the front panel to the ICE position. The ice maker will start working automatically. 2. After three minutes, the machine will automatically go to the ice making stage, and the sound of flowing water will be heard. -
Page 15: How The Machine Uses The Water
How the Machine Uses the Water The ice maker begins with a fixed charge of water that is contained in the water trough. During the ice-making process, fresh water enters the water trough continuously as the water from the trough freezes on the evaporator. -
Page 16: Normal Sounds
4. Mode button: Mainly for service. When this button is pressed, the unit can change from Ice Making mode to Ice Harvest mode, or from Ice Harvest mode to Ice Making mode. The mode can be determined from the status of the green and yellow LEDs. Ice Size Adjust button: When this is pressed and held for 3 seconds, the unit will enter the Ice Size Adjustment mode. -
Page 17: Preparing The Icemaker For Long Storage
Preparing the Icemaker for Long Storage Important: Do not touch the power plug when your hands are wet. Never unplug the unit by pulling on the plug. If the icemaker will not be used for a long time, or is to be moved to another place, it will be necessary to drain the system of water. -
Page 18: Exterior Cleaning
Exterior Cleaning The door and cabinet may be cleaned with a mild detergent and warm water solution such as 1 oz of dishwashing liquid mixed with 2 gallons of warm water. Do not use solvent based or abrasive cleaners. Use a soft sponge and rinse with clean water. Wipe with a soft clean towel to prevent water spotting. -
Page 19: Water Distribution Tube Cleaning
4. Remove dirt and lint from condenser and the unit compartment with a brush attachment on a vacuum cleaner. 5. Reattach the front cover. 6. Plug in the icemaker or reconnect power. Warning: DO NOT touch the condenser fins. They are sharp and can be damaged easily. Water Distribution Tube Cleaning When you find that the ice cubes are incompletely formed or the output of ice cubes is low, the water distribution tube may be blocked. -
Page 20: Ice-Making System Cleaning
Ice-making System Cleaning Minerals that are removed from water during the freezing cycle will eventually form a hard scaly deposit in the water system. Cleaning the system regularly helps remove the mineral scale buildup. How often you need to clean the system depends upon how hard your water is or how effective your filtration may be. -
Page 21: Troubleshooting
Troubleshooting Before Calling for Service If the unit appears to be malfunctioning, read through the “Operation” section of this manual first. If the issue persists, check the troubleshooting section below. The issue could be solved by following the suggestions in the “Solution” column. Issue Possible Cause Solution... -
Page 22: Troubleshooting Continued
Troubleshooting Continued Issue Possible Cause Solution The icemaker stops suddenly The electricity is off. Reconnect the power supply while making ice. line. The room temperature is out of Make sure unit is installed with the stated range. correct clearances and within the stated ambient temperature range. -
Page 23: Specifications
Specifications Note: Technical data and performance information are provided for reference only. Description of product Outdoor Ice Maker Model OIM450SS Voltage / Frequency AC 115V~60Hz Ice-Making / Ice-Harvest rated current 3.0A / 4.0A Color Stainless Steel Ice Storage capacity 25 lbs. maximum Ice-making capability 45 lbs. -
Page 24: Edgestar Limited Warranty
WHAT IS COVERED: For a period of ONE (1) YEAR from the date of original retail purchase, EdgeStar will repair or replace any part free of charge including labor that fails due to a defect in materials or workmanship. Labor will be performed free of charge at an authorized EdgeStar repair facility and EdgeStar will supply new, rebuilt, or refurbished parts free of charge.
